Figure 1-1. SAM DA1 Xplained Pro Evaluation Kit Overview
CURRENT
MEASUREMENT
HEADER
TARGET USB
USER LED0
PCB VCC SEL.
HEADER
EXT. VCC. SEL.
HEADER
HIGH VOLTAGE IO
HEADER
PA3 SELECT
JUMPER
32kHz
CRYSTAL
ATA663231FAQW LIN
TRX
`
EXTENSION 3 HEADER
Atmel SAMDA1 Xplained Pro [USERGUIDE]
SW0 USER BUTTON
RESET BUTTON
DEBUG USB
POWER
HEADER
EXTENSION 1
HEADER
SAMDA1J16A-ABT
EXTENSION 2
HEADER
