- Page 1 RSC-IMX8M 3.5" NXP IMX8M SBC User’s Manual Ed – 17 May, 2023 Part No. E2047MX8M01R...
- Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
- Page 3 User’s Manual otherwise specified. Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification. Life Support Policy Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN...
- Page 4 (such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for warranty service. 5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. 4 RSC-IMX8M User’s Manual...
-
Page 5: Table Of Contents
Document Amendment History ................. 8 Manual Objectives ..................... 9 System Specifications ..................... 10 Hardware Configuration ................... 14 RSC-IMX8M Product Overview ................15 RSC-IMX8M Jumper and Connector List ..............16 Setting Jumpers & Connectors ................18 2.3.1 Boot Mode selector 1/2 (SW1) ....................... 18 2.3.2 MIPI CSI Screen connector 1 (J15) .................... - Page 6 RSC-IMX8M RSC-IMX8M-C Overview ..................34 RSC-IMX8M-C Jumper and Connector List ............35 Setting Jumpers & Connectors ................36 2.9.1 Serial port 1 in RS-232/485 mode select (J3) ................36 2.9.2 Serial port 2 in RS-232/485 mode select (J5) ................36 2.9.3...
-
Page 7: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x RSC-IMX8M ⚫ RSC-IMX8M User’s Manual 7... -
Page 8: Document Amendment History
RSC-IMX8M 1.3 Document Amendment History Revision Date Comment June 2021 Initial Release May 2023 Update System Specifications 8 RSC-IMX8M User’s Manual... -
Page 9: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to interface with RSC-IMX8M series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 10: System Specifications
1 x 1x5P Header 1 x 1x5P Header 1 x 1x5P Header 1 x 2230 M.2 for WiFi/BT (PCIe& USB Channel) 1 x 3042 M.2 for 3G/4G Module (USB Only) 1 x SIM Socket Extend 1 x 2x20P Header 10 RSC-IMX8M User’s Manual... - Page 11 12V~24V wide voltage DC input Power Connector DC Jack Type Industry Operating temperature：-40~85 Degree Operating Temp. Consumer Operating temperature：0~85 Degree(Default) Storage Temp. -40_85 Degree Operating Humidity Size (L x W) 3.5” (Please consult 146mm x 102mm product engineers for RSC-IMX8M User’s Manual 11...
- Page 12 Test Eb : Bump Test Android Version 10-kernel 5.4.70 (coming soon) OS Information Linux Yocto Version sumo 2.5-kernel 4.14.98 (Default and first) Expansion I/O board-1 Component RS232/485 4 x DB9 Connector Extend 1 x 2 x 20P Header 12 RSC-IMX8M User’s Manual...
- Page 13 Extend 1 x 2 x 20P Header Expansion I/O board-3 Component RS232/485 3 x DB9 Connector Isolate GPIO 1 x 1x8P DB9 Connector Extend 1 x 2x20P Header Note: Specifications are subject to change without notice. RSC-IMX8M User’s Manual 13...
-
Page 14: Hardware Configuration
RSC-IMX8M 2. Hardware Configuration 14 RSC-IMX8M User’s Manual... -
Page 15: Rsc-Imx8M Product Overview
User’s Manual 2.1 RSC-IMX8M Product Overview RSC-IMX8M User’s Manual 15... -
Page 16: Rsc-Imx8M Jumper And Connector List
RSC-IMX8M 2.2 RSC-IMX8M Jumper and Connector List You can configure your board to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. - Page 17 MIC IN connector 2 x 1 wafer, pitch 2.00mm Speaker connector 4 x 1 wafer, pitch 2.00mm SIM Card socket DC-IN power connector 4 x 1 wafer, pitch 2.00mm Extend connector 2 x 20 wafer, pitch 2.00mm RSC-IMX8M User’s Manual 17...
-
Page 18: Setting Jumpers & Connectors
RSC-IMX8M 2.3 Setting Jumpers & Connectors 2.3.1 Boot Mode selector 1/2 (SW1) Programming mode SW1: 01 SW4: XX X=don’t care eMMC boot SD boot 18 RSC-IMX8M User’s Manual... -
Page 19: Mipi Csi Screen Connector 1 (J15)
CSI1_ I2C_SCL CSI1_RST VCC28_DVP CSI1_PWDN AVDD28_DVP 2.3.3 MIPI CSI Screen connector 2 (J16) Signal PIN PIN Signal CSI2_CKN CSI2_DP0 CSI2_CKP CSI2_DN0 CSI2_DP1 CSI2_DP2 CSI2_DN1 CSI2_DN2 VCC18_DVP CSI2_DP3 CSI2_DN3 VCC1.5_DVP CSI2_I2C_SDA CSI2_MCLK CSI2_ I2C_SCL CSI2_RST VCC28_DVP CSI2_PWDN AVDD28_DVP RSC-IMX8M User’s Manual 19... -
Page 20: Front Panel Connector (J21)
RSC-IMX8M 2.3.4 Front Panel connector (J21) Signal PIN PIN Signal DCDC_5V FB0603 VOL_UP VOL_DN ON_OFF BR_UP BR_DN LED_GRN LED_ORG 2.3.5 LCD Backlight connector (J19) Signal VCC_12V BL_EN LCD_BL_PWM LCD_5V 20 RSC-IMX8M User’s Manual... -
Page 21: Lvds Connector (J18)
User’s Manual 2.3.6 LVDS connector (J18) Signal PIN PIN Signal +12V +12V LBCN_D8 LACN_D17 LBCP_D7 LACP_D16 LB3N_D6 LB2N_D9 LB3P_D5 LB2P_DCK LB1N_D11 LB0N_D13 LB1P_D10 LB0P_D12 LA3N_D15 LA2N_D19 LA3P_D14 LA2P_D18 LA1N_D21 LA0N_D23 LA1P_D20 LA0P_D22 LVDS_DDC_CLK LVDS_DDC_DAT +3.3V +3.3V RSC-IMX8M User’s Manual 21... -
Page 22: Mipi Dsi Connector (J17)
RSC-IMX8M 2.3.7 MIPI DSI connector (J17) Signal VLED+ VLED+ VLED- VLED- VLED- MIPI_DSI2_D3N MIPI_DSI2_D0N MIPI_DSI2_D3P MIPI_DSI2_D0P MIPI_DSI2_CN MIPI_DSI2_D1N MIPI_DSI2_CP MIPI_DSI2_D1P MIPI_DSI2_D2N MIPI_DSI2_D2P MIPI_RST MIPI_1V8 MIPI_1V8 LCD_3V3 LCD_3V3 LCD_3V3 22 RSC-IMX8M User’s Manual... -
Page 23: Touch Panel Connector (Con3)
User’s Manual 2.3.8 Touch Panel connector (CON3) Signal VDD_3V3 TP_INT TP_SCL TP_SDA TP_RST0 2.3.9 RTC connector (JRTC1) Signal DCDC_3V3 RSC-IMX8M User’s Manual 23... -
Page 24: Uart Debug Connector (J3)
RSC-IMX8M 2.3.10 UART Debug connector (J3) Signal UART1_RXD UART1_TXD VDD_3V3 2.3.11 UART Debug connector (J4) Signal UART2_RXD UART2_TXD VDD_3V3 24 RSC-IMX8M User’s Manual... -
Page 25: Dc-In Power Connector (J6)
User’s Manual 2.3.12 DC-IN power connector (J6) Signal VCC_12V 2.3.13 Power Button (CN4) Signal ONOFF_1 RSC-IMX8M User’s Manual 25... -
Page 26: Usb3.0 Connector (J8)
2.3.14 USB3.0 connector (J8) Signal PIN PIN Signal USB1_3.0_POWER USB3_HOST_RXN 19 USB1_3.0_POWER USB3_HOST_RXP 18 USB4_HOST_RXN 17 USB4_HOST_RXP USB3_HOST_TXN USB3_HOST_TXP 15 USB4_HOST_TXN 14 USB4_HOST_TXP USB3_HOST_DN USB3_HOST_DP 12 USB4_HOST_DN 11 USB4_HOST_DP 2.3.15 MIC IN connector (CN3) Signal MIC_IN_P 26 RSC-IMX8M User’s Manual... -
Page 27: Extend Connector (J22)
2.3.16 Extend connector (J22) Signal PIN PIN Signal DCDC_3V3 DCDC_5V I2C3_SDA DCDC_5V I2C3_SCL UART2_RXD UART1_RXD UART1_TXD UART2_TXD GPIO3.IO[10] UART2_CTS UART2_RTS UART1_CTS E_3V3 UART1_RTS ECSPI1_SCLK ECSPI1_MOSI GPIO4_IO21 ECSPI1_MISO ECSPI2_MISO ECSPI2_MOSI ECSPI1_SS0 GPIO4_IO20 ECSPI2_SCLK GPIO5_IO04 GPIO4_IO00 PWM1_OUT GPIO4_IO01 ECSPI2_SS0 GPIO4_IO11 RSC-IMX8M User’s Manual 27... -
Page 28: Dc-In Power Connector (J24)
RSC-IMX8M 2.3.17 DC-IN power connector (J24) Signal 12V_DCIN 2.3.18 Speaker connector (J23) Signal SPK_L+ SPK_L- SPK_R+ SPK_R- 28 RSC-IMX8M User’s Manual... -
Page 29: Expansion I/O Board-1 & Board-2 Product Overview
User’s Manual 2.4 Expansion I/O board-1 & board-2 Product Overview RSC-IMX8M User’s Manual 29... -
Page 30: Expansion I/O Board-1 & Board-2 Jumper And Connector List
3 x 1 header, pitch 2.00mm RS-232/485 mode select 3 x 1 header, pitch 2.00mm RS-232/485 mode select 3 x 1 header, pitch 2.00mm Connectors Label Function Note CON1/2 RS232/485 connector 1/2 CON3 CAN Bus connector CON4 GPIO connector 30 RSC-IMX8M User’s Manual... -
Page 31: Setting Jumpers
User’s Manual 2.6 Setting Jumpers 2.6.1 Serial port 1 in RS-232/485 mode select (J3) RS-485* RS-232 * Default 2.6.2 Serial port 2 in RS-232/485 mode select (J5) RS-485* RS-232 * Default RSC-IMX8M User’s Manual 31... -
Page 32: Rs-232/485 Mode Select (J10)
RSC-IMX8M 2.6.3 RS-232/485 mode select (J10) RS-232* RS-485 * Default 2.6.4 RS-232/485 mode select (J11) RS-232* RS-485 * Default 32 RSC-IMX8M User’s Manual... -
Page 33: Rs-232/485 Mode Select (J12)
User’s Manual 2.6.5 RS-232/485 mode select (J12) RS-485* RS-232 * Default 2.6.6 RS-232/485 mode select (J13) RS-485* RS-232 * Default RSC-IMX8M User’s Manual 33... -
Page 34: Rsc-Imx8M-C Overview
RSC-IMX8M 2.7 RSC-IMX8M-C Overview 34 RSC-IMX8M User’s Manual... -
Page 35: Rsc-Imx8M-C Jumper And Connector List
User’s Manual 2.8 RSC-IMX8M-C Jumper and Connector List The following tables list the function of each of the board’s connectors. Jumpers Label Function Note General purpose I/O connector 3 x 1 header, pitch 2.00mm Serial port 1 in RS-232/485 mode select 3 x 1 header, pitch 2.00mm Serial port 2 in RS-232/485 mode select 3 x 1 header, pitch 2.00mm... -
Page 36: Setting Jumpers & Connectors
RSC-IMX8M 2.9 Setting Jumpers & Connectors 2.9.1 Serial port 1 in RS-232/485 mode select (J3) RS-485* RS-232 * Default 2.9.2 Serial port 2 in RS-232/485 mode select (J5) RS-485* RS-232 * Default 36 RSC-IMX8M User’s Manual... -
Page 37: Serial Port 3 In Rs-232/485 Mode Select (J7)
User’s Manual 2.9.3 Serial port 3 in RS-232/485 mode select (J7) RS-485* RS-232 * Default 2.9.4 Serial port 4 in RS-232/485 mode select (J9) RS-485* RS-232 * Default RSC-IMX8M User’s Manual 37... -
Page 38: Rs-232/485 Mode Select (J10)
RSC-IMX8M 2.9.5 RS-232/485 mode select (J10) RS-485* RS-232 * Default 2.9.6 RS-232/485 mode select (J11) RS-485* RS-232 * Default 38 RSC-IMX8M User’s Manual... -
Page 39: Rs-232/485 Mode Select (J12)
User’s Manual 2.9.7 RS-232/485 mode select (J12) RS-485* RS-232 * Default 2.9.8 RS-232/485 mode select (J13) RS-485* RS-232 * Default RSC-IMX8M User’s Manual 39... -
Page 40: Rs-232/485 Mode Select (J14)
RSC-IMX8M 2.9.9 RS-232/485 mode select (J14) RS-485* RS-232 * Default 2.9.10 RS-232/485 mode select (J16) RS-485* RS-232 * Default 40 RSC-IMX8M User’s Manual... -
Page 41: Rs-232/485 Mode Select (J15)
User’s Manual 2.9.11 RS-232/485 mode select (J15) RS-485* RS-232 * Default 2.9.12 RS-232/485 mode select (J17) RS-485* RS-232 * Default RSC-IMX8M User’s Manual 41... -
Page 42: Serial Port Connector 1/2 (Con1/2)
RSC-IMX8M 2.9.13 Serial port connector 1/2 (CON1/2) CON1 Signal CON2 RS232_TX_OUT RS232_RX_OUT RS485_A 2.9.14 Serial port connector 3/4 (CON3/4) CON3 Signal RS485_A CON4 RS232_RX_OUT RS232_TX_OUT 42 RSC-IMX8M User’s Manual... -
Page 43: General Purpose I/O Connector (J2)
User’s Manual 2.9.15 General purpose I/O connector (J2) Signal GP4_IO21 GP4_IO20 GP1_IO01 GP5_IO05 GP5_IO04 GP4_IO00 GP4_IO11 GP5_IO26 EXT_5V RSC-IMX8M User’s Manual 43... -
Page 44: Extend Connector (J1)
2.9.16 Extend connector (J1) Signal PIN PIN Signal RS232_3V3 RS485_3V3 GPIO5_IO19 RS485_3V3 GPIO5_IO18 GPIO5_IO24 GPIO5_IO22 GPIO5_IO23 GPIO5_IO25 GPIO3_IO10 GPIO5_IO28 GPIO5_IO29 GPIO5_IO26 E_3V3 GPIO5_IO27 GPIO5_IO06 GPIO5_IO07 GPIO4_IO21 GPIO5_IO08 GPIO5_IO12 GPIO5_IO11 GPIO5_IO09 GPIO4_IO20 GPIO5_IO10 GPIO5_IO04 GPIO4_IO00 GPIO5_IO05 GPIO4_IO01 GPIO5_IO13 GPIO4_IO11 44 RSC-IMX8M User’s Manual... -
Page 45: Mechanical Drawing
User’s Manual 3. Mechanical Drawing RSC-IMX8M User’s Manual 45... - Page 46 RSC-IMX8M Unit: mm Unit: mm 46 RSC-IMX8M User’s Manual...
- Page 47 User’s Manual Unit: mm Unit: mm RSC-IMX8M User’s Manual 47...
- Page 48 RSC-IMX8M RSC-IMX8M-C Unit: mm 48 RSC-IMX8M User’s Manual...
