  • Page 1 RSC-IMX8M 3.5" NXP IMX8M SBC User’s Manual Ed – 07 June, 2021 Part No. E2047MX8M00R...
  • Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
  • Page 3 User’s Manual otherwise specified. Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification. Life Support Policy Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN...
  • Page 4 (such as your sales receipt) in a shippable container. A product returned without proof of the purchase date is not eligible for warranty service. 5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. 4 RSC-IMX8M User’s Manual...
  • Page 5: Table Of Contents

    System Specifications ..................... 10 Architecture Overview – Block Diagram ..............14 Hardware Configuration ................... 16 RSC-IMX8M Product Overview ................17 RSC-IMX8M Jumper and Connector List ..............18 Setting Jumpers & Connectors ................20 2.3.1 Boot Mode selector 1/2 (SW1/SW4) ....................20 2.3.2...
  • Page 6 RSC-IMX8M 2.6.5 RS-232/485 mode select (J12) ...................... 35 2.6.6 RS-232/485 mode select (J13) ...................... 35 3. Linux User Guid ......................36 3.1 Flash Yocto 2.5 to RSC-IMX8M ................... 37 4. Mechanical Drawing ....................42 6 RSC-IMX8M User’s Manual...
  • Page 7: Getting Started

    1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x RSC-IMX8M  RSC-IMX8M User’s Manual 7...
  • Page 8: Document Amendment History

    RSC-IMX8M 1.3 Document Amendment History Revision Date Comment June 2021 Initial Release 8 RSC-IMX8M User’s Manual...
  • Page 9: Manual Objectives

    We strongly recommend that you study this manual carefully before attempting to interface with RSC-IMX8M series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance.
  • Page 10: System Specifications

    1 x 1 x 5P Header 1 x M.2 Key E for WiFi/BT (PCIe& USB Channel) 1 x M.2 Key B for LTE Module (USB Only) 1 x SIM Socket Extend 1 x 2 x 20P Header 10 RSC-IMX8M User’s Manual...
  • Page 11 Environmental Power Type 12V~24V wide voltage DC input 1 x 1 x 2P connector with lock Header Power Connector Type Operating Industry Operating temperature:-40~85 Degree (Default) Temperature Consumer Operating temperature:0~60 Degree Storage -40 ~ 85 degree RSC-IMX8M User’s Manual 11...
  • Page 12 4. No. of Shock:Z axis 1000 times Bump Test 5. Test Axis: Z axis 6. Operation mode 7. Reference IEC 60068-2-29 Testing procedures Test Eb : Bump Test Android 10 OS Information Linux Yocto sumo 2.5 (Default) Expansion I/O board-1 Component 12 RSC-IMX8M User’s Manual...
  • Page 13 2 x DB9 Connector Isolate GPIO 1 x 1 x 8P DB9 Connector CAN Bus 1 x 1 x 4P DB9 Connector Extend 1 x 2 x 20P Header Note: Specifications are subject to change without notice. RSC-IMX8M User’s Manual 13...
  • Page 14: Architecture Overview - Block Diagram

    RSC-IMX8M 1.6 Architecture Overview – Block Diagram The following block diagram shows the architecture and main components of RSC-IMX8M. 14 RSC-IMX8M User’s Manual...
  • Page 15 User’s Manual The following block diagram shows the architecture and main components of Expansion I/O board. RSC-IMX8M User’s Manual 15...
  • Page 16: Hardware Configuration

    RSC-IMX8M 2. Hardware Configuration 16 RSC-IMX8M User’s Manual...
  • Page 17: Rsc-Imx8M Product Overview

    User’s Manual 2.1 RSC-IMX8M Product Overview RSC-IMX8M User’s Manual 17...
  • Page 18: Rsc-Imx8M Jumper And Connector List

    RSC-IMX8M 2.2 RSC-IMX8M Jumper and Connector List You can configure your board to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.
  • Page 19 2 x RJ-45 Ethernet HDMI-A connector Extend connector 2 x 20 wafer, pitch 2.00mm HP Jack connector MIC IN connector 2 x 1 wafer, pitch 2.00mm CON2 LINE OUT connector 3 x 1 wafer, pitch 2.00mm SIM Card socket RSC-IMX8M User’s Manual 19...
  • Page 20: Setting Jumpers & Connectors

    RSC-IMX8M 2.3 Setting Jumpers & Connectors 2.3.1 Boot Mode selector 1/2 (SW1/SW4) Programming mode SW1: 01 SW4: XX X=don’t care eMMC boot SD boot 20 RSC-IMX8M User’s Manual...
  • Page 21: Speaker L Connector (Cn1)

    User’s Manual 2.3.2 Speaker L connector (CN1) Signal SPK_L+ SPK_L- 2.3.3 Speaker R connector (CN2) Signal SPK_R+ SPK_R- RSC-IMX8M User’s Manual 21...
  • Page 22: Mipi Csi Screen Connector 1 (J15)

    CSI1_ I2C_SCL CSI1_RST VCC28_DVP CSI1_PWDN AVDD28_DVP 2.3.5 MIPI CSI Screen connector 2 (J16) Signal PIN PIN Signal CSI2_CKN CSI2_DP0 CSI2_CKP CSI2_DN0 CSI2_DP1 CSI2_DP2 CSI2_DN1 CSI2_DN2 VCC18_DVP CSI2_DP3 CSI2_DN3 VCC1.5_DVP CSI2_I2C_SDA CSI2_MCLK CSI2_ I2C_SCL CSI2_RST VCC28_DVP CSI2_PWDN AVDD28_DVP 22 RSC-IMX8M User’s Manual...
  • Page 23: Front Panel Connector (J21)

    User’s Manual 2.3.6 Front Panel connector (J21) Signal PIN PIN Signal DCDC_5V FB0603 VOL_UP VOL_DN ON_OFF BR_UP BR_DN LED_GRN LED_ORG 2.3.7 LCD Backlight connector (J19) Signal VCC_12V BL_EN LCD_BL_PWM LCD_5V RSC-IMX8M User’s Manual 23...
  • Page 24: Lvds Connector (J18)

    RSC-IMX8M 2.3.8 LVDS connector (J18) Signal PIN PIN Signal +12V +12V LBCN_D8 LACN_D17 LBCP_D7 LACP_D16 LB3N_D6 LB2N_D9 LB3P_D5 LB2P_DCK LB1N_D11 LB0N_D13 LB1P_D10 LB0P_D12 LA3N_D15 LA2N_D19 LA3P_D14 LA2P_D18 LA1N_D21 LA0N_D23 LA1P_D20 LA0P_D22 LVDS_DDC_CLK LVDS_DDC_DAT +3.3V +3.3V 24 RSC-IMX8M User’s Manual...
  • Page 25: Mipi Dsi Connector (J17)

    User’s Manual 2.3.9 MIPI DSI connector (J17) Signal VLED+ VLED+ VLED- VLED- VLED- MIPI_DSI2_D3N MIPI_DSI2_D0N MIPI_DSI2_D3P MIPI_DSI2_D0P MIPI_DSI2_CN MIPI_DSI2_D1N MIPI_DSI2_CP MIPI_DSI2_D1P MIPI_DSI2_D2N MIPI_DSI2_D2P MIPI_RST MIPI_1V8 MIPI_1V8 LCD_3V3 LCD_3V3 LCD_3V3 RSC-IMX8M User’s Manual 25...
  • Page 26: Touch Panel Connector (Con3)

    RSC-IMX8M 2.3.10 Touch Panel connector (CON3) Signal VDD_3V3 TP_INT TP_SCL TP_SDA TP_RST0 2.3.11 RTC connector (JRTC1) Signal DCDC_3V3 26 RSC-IMX8M User’s Manual...
  • Page 27: Uart Debug Connector (J3)

    User’s Manual 2.3.12 UART Debug connector (J3) Signal UART1_RXD UART1_TXD VDD_3V3 2.3.13 UART Debug connector (J4) Signal UART2_RXD UART2_TXD VDD_3V3 RSC-IMX8M User’s Manual 27...
  • Page 28: Dc-In Power Connector (J6)

    RSC-IMX8M 2.3.14 DC-IN power connector (J6) Signal VCC_12V 2.3.15 Power Button (CN4) Signal ONOFF_1 28 RSC-IMX8M User’s Manual...
  • Page 29: Usb3.0 Connector (J8)

    2.3.16 USB3.0 connector (J8) Signal PIN PIN Signal USB1_3.0_POWER USB3_HOST_RXN 19 USB1_3.0_POWER USB3_HOST_RXP 18 USB4_HOST_RXN 17 USB4_HOST_RXP USB3_HOST_TXN USB3_HOST_TXP 15 USB4_HOST_TXN 14 USB4_HOST_TXP USB3_HOST_DN USB3_HOST_DP 12 USB4_HOST_DN 11 USB4_HOST_DP 2.3.17 MIC IN connector (CN3) Signal MIC_IN_P RSC-IMX8M User’s Manual 29...
  • Page 30: Line Out Connector (Con2)

    2.3.19 Extend connector (J22) Signal PIN PIN Signal DCDC_3V3 DCDC_5V I2C3_SDA DCDC_5V I2C3_SCL UART2_RXD UART1_RXD UART1_TXD UART2_TXD GPIO3.IO[10] UART2_CTS UART2_RTS UART1_CTS E_3V3 UART1_RTS ECSPI1_SCLK ECSPI1_MOSI GPIO4_IO21 ECSPI1_MISO ECSPI2_MISO ECSPI2_MOSI ECSPI1_SS0 GPIO4_IO20 ECSPI2_SCLK GPIO5_IO04 GPIO4_IO00 PWM1_OUT GPIO4_IO01 ECSPI2_SS0 GPIO4_IO11 30 RSC-IMX8M User’s Manual...
  • Page 31: Expansion I/O Board-1 & Board-2 Product Overview

    User’s Manual 2.4 Expansion I/O board-1 & board-2 Product Overview RSC-IMX8M User’s Manual 31...
  • Page 32: Expansion I/O Board-1 & Board-2 Jumper And Connector List

    RS-232/485 mode select 3 x 1 header, pitch 2.00mm RS-232/485 mode select 3 x 1 header, pitch 2.00mm RS-232/485 mode select 3 x 1 header, pitch 2.00mm Connectors Label Function Note Serial port 1/2/3/4 connector CON1/2/3/4 32 RSC-IMX8M User’s Manual...
  • Page 33: Setting Jumpers

    User’s Manual 2.6 Setting Jumpers 2.6.1 Serial port 1 in RS-232/485 mode select (J3) RS-485* RS-232 * Default 2.6.2 Serial port 2 in RS-232/485 mode select (J3) RS-485* RS-232 * Default RSC-IMX8M User’s Manual 33...
  • Page 34: Rs-232/485 Mode Select (J10)

    RSC-IMX8M 2.6.3 RS-232/485 mode select (J10) RS-232* RS-485 * Default 2.6.4 RS-232/485 mode select (J11) RS-232* RS-485 * Default 34 RSC-IMX8M User’s Manual...
  • Page 35: Rs-232/485 Mode Select (J12)

    User’s Manual 2.6.5 RS-232/485 mode select (J12) RS-485* RS-232 * Default 2.6.6 RS-232/485 mode select (J13) RS-485* RS-232 * Default RSC-IMX8M User’s Manual 35...
  • Page 36: Linux User Guid

    RSC-IMX8M 3. Linux User Guid 36 RSC-IMX8M User’s Manual...
  • Page 37: Flash Yocto 2.5 To Rsc-Imx8M

    User’s Manual 3.1 Flash Yocto 2.5 to RSC-IMX8M 1. Connect your RSC-IMX8M to computer via type C USB cable. RSC-IMX8M User’s Manual 37...
  • Page 38 RSC-IMX8M 2. Download Yocto 2.5 image. Please connect Avalue FAE to get download link. 3. Set the jumper to OTG mode. 38 RSC-IMX8M User’s Manual...
  • Page 39 User’s Manual SW1: Set to 01 RSC-IMX8M User’s Manual 39...
  • Page 40 4. Connect 12V power supplier to power on the device. Execute “flash.bat” start to flash image. 5. In c case that the following situation happens, it needs to install the drvier to RSC-IMX8M in Windows 7. (skip step 5 if this pronlem does not occur in your device) ...
  • Page 41 User’s Manual 6. After flash image finish, disable power supplier. 7. Set the jumper to boot mode and eMMC. SW1: 10 SW4: 10 8. Power on and start to boot to Yocto 2.5. RSC-IMX8M User’s Manual 41...
  • Page 42: Mechanical Drawing

    RSC-IMX8M 4. Mechanical Drawing 42 RSC-IMX8M User’s Manual...
  • Page 43 User’s Manual Unit: mm RSC-IMX8M User’s Manual 43...
  • Page 44 RSC-IMX8M Unit: mm 44 RSC-IMX8M User’s Manual...
