PCM-23U1DG-CE
USB Slot /w Lock for USB Dongle
Startup Manual
Packing List
Before installation, please make sure that you have:
• 1 x USB dongle I/O Plate with wired cable
• 1 x Startup manual
• 1 x Warranty card
• 1 x USB dongle half-size mPCIe (PCM-23U1DG-CE)
• 1 x Full/Half-size mPCIe adapter kit (PCM-23U1DG-CE)
If any of the above items are missing or damaged, please
contact your distributor or sales representative immediately.
Installation
Please follow the steps as below.
1. Assemble half-size mini-PCIe card and bracket with
screws.
For more information on this and other Advantech
products, please visit our website at:
https://www.advantech.com/
For technical support and service:
https://support.advantech.com/support/new_de-
fault.aspx
This startup manual is for PCM-23U1DG-CE.
Part No. 204323U100
Installation (Cont.)
2. Install USB device into PCM Module.
3. Insert the PCM Module through the blanking plate hole
and secure the screws. Attach the PCM Module to the
mini-PCIe card with the cable.
Documentation/Software Support Guide
The support documentation and drivers can be accessed
from Advantech website.
• Documentation
- Datasheet
Edition 1
April 2019
PCM-23U1DG-CE Startup Manual 1
