UltraFlo ® 2000 SERIES
Ultrasonic Flow Meter

Installation Instructions

Note : The housing of UltraFlo is labeled with an arrow symbolizing the direction of the flow measurement. The flow meter has to be
installed in a way so that the flowthrough is in the same direction as the arrow symbol.
The housing of Flowmeter is labeled with an arrow symbolizing the direction of the flow. The flowmeter must be installed in direction of
the flow.
For fastest possible bubble detection it is important to keep the pipe distance to UltraFlo as short as possible. Accurate measurement can
only be assured, if the pipe is completely filled and the liquid does not outgas.
Notwithstanding it may be advantageous for dosing applications to install the UltraFlo
soft pipes change the cross-section depending on the system pressure. This may lead to repeatable differences.
Note : Insure that no cavitation dissolve from the measured liquid. Depending on the measured liquid it can be helpful to have enough
back pressure on the outlet of UltraFlo
Particles present in the flow stream may result in measuring errors!
When using pumps, UltraFlo
maximum pressure rating of UltraFlo
For correct volume flow measurements straight and unobstructed inflow and outflow distances have to be observed. Starting from the
connection thread these straight and unobstructed flow zones must be:
Nominal Diameter
Inflow Distance
Outflow Distance
DOWN - Inlet
Fig. 2: Installation position of Flowmeter
®
2000 to avoid cavitation. Insure all mechanical connections are tight.
®
2000 must be installed in flow direction on the pressure side, in order to ensure sufficient pressure. The
®
2000 has to be considered.
2"
40cm
20cm
TOP - Outlet
0% 50% 100%
Flow
[GPM]
400.0
Total [GAL]
5496
®
2000 as close as possible to the dosing valve, as
