EAN: 5060514913123 (BLACK)
2
EAN: 5060514913130 (GOLD)
EAN: 5060514913116 (SILVER)
OUTDOOR PANEL
BI-02/04/08/12FB

Device description

The unique multi-apartment outdoor panel has a stylish design. Calling panels are available
in gold, silver and black colors. They are equipped with a wide-angle camera and support
BAS-IP UKEY mobile access. Using these panels, you can make direct calls to both the
internal monitors and the concierge. The device fits perfectly into the interior of a small
office or cottage.
The panel has a unique feature — face recognition. This identifying technology is integrated
into the BAS-IP panels and uses the camera of the outdoor panel and infrared sensors for
its operation.
Appearance
Apt 1 Apt 7
Apt 2 Apt 8
Apt 3 Apt 9
Apt 4 Apt 10
Apt 5 Apt 11
Apt 6 Apt 12
CONCIERGE
EAN: 5060514913147 (BLACK)
EAN: 5060514913154 (GOLD)
EAN: 5060514913161 (SILVER)

Main features

Panel type: Multi-apartment.
Display: No.
Keypad: Backlight mechanical buttons.
Camera: 1/4".
Angle: 90° horizontal x 62° vertical.
Resolution: 1.3 Мp.
Output video: HD (1280 × 720), H.264 Main Profile.
Night backlight: 6 LEDs.
Light sensitivity: 0,01 LuX.
Protection class: IP65.
Working temperature: -40 — +65 °С.
Power consumption: 6,5 W, in standby — 3,6 W.
Power supply: PoE + 12 V DC.
Body: Aluminium alloy.
Colors: Silver, Gold, Black.
Dimensions for installation: 141 × 359 × 58 mm.
Size of the panel: 158 × 379 × 49 mm.
Installation: Flush, surface with BR-AA12 Bracket.
1
2
3
4
5
6
EAN: 5060514913178 (BLACK) EAN: 5060514913208 (BLACK)
EAN: 5060514913185 (GOLD) EAN: 5060514913215 (GOLD)
EAN: 5060514913192 (SILVER) EAN: 5060514913222 (SILVER)
1 - Backlight. 4
2 - Camera. 5
3 - Loudspeaker. 6
Full User Manual
wiki.bas-ip.com
- Keypad.
- Concierge.
- Reader.
