Main Features; Entrance Panel; Device Description - BAS-IP AA-12FB User Manual

ENTRANCE PANEL

AA-12FB

Device description

Modern design and well-thought out functionality of this panel makes it an
ideal solution for business and elite buildings. AA-12FB is available in gold,
silver, and black, and also it supports BAS-IP UKEY mobile access.
There is a separate button to call concierge or emergency services.
Appearance
1
2
3
4
1 2 3
i
5
4 5 6
7 8 9
x 0
6

Main features

• Panel type: Multi-apartment.
• Display: 4.3'' TFT, color with backlight.
• Keypad: Backlight piezo buttons.
• Camera: 1/4".
• Resolution: 2 Мp.
• Сamera angle: 110° (horizontal).
• Output video: Full HD (1920 × 1080), H.264 Main Profile.
• Night backlight: 6 LEDs.
• Light sensitivity: 0,01 LuX.
• Protection class: IP65.
• IK-Code: IK07.
• Working temperature: -40 — +65 °С.
• Power consumption: 6,5 W, in standby — 3,6 W.
• Power supply: +12 V DC.
• Body: Aluminum.
• Colors: Silver, Gold, Black.
• Dimensions for installation: 142 × 358 × 58 mm.
• Size of the panel: 161 × 382 × 49 mm.
• Installation: Flush, surface with BR-AA12 bracket.
1 - Backlight.
2 - Camera.
3 - Loudspeaker.
4 - 4.3'' Display.
5 - Keypad.
6 - Reader.
Full User Manual
wiki.bas-ip.com
