Main Features; Device Description - BAS-IP AV-04SD User Manual

2
EAN: 5060514913468 (SILVER)
INDIVIDUAL ENTRANCE PANEL
AV-04SD

Device description

BAS-IP AV-04SD — stylish vandal-proof panel with installation by the wall
mount method.
There is also the possibility of individual text or logo appliance on the panel
(through in the service center).
Appearance

Main features

Panel type: Individual.
Display: No.
Camera: 1/4".
Angle: 90° horizontal x 60° vertical.
Resolution: 1 Мp.
Output video: Half-HD (1280 × 720), H.264 Main Profile.
Night backlight: 6 LEDs.
Light sensitivity: 0,01 Lux.
Protection class: IP64.
Working temperature: -40 — +65 °С.
Power consumption: 6,5 W, in standby — 3,6 W.
Power supply: PoE, +12 V DC.
Body: Metal.
Colors: Silver.
Dimensions: 84 x 169 x 34 mm.
Installation: Surface mount.
1
2
3
4
5
1 - Backlight. 4
2 - Camera. 5
3 - Loudspeaker.
Full User Manual
wiki.bas-ip.com
- Mechanical call button.
- Microphone.
