ENTRANCE PANEL
AV-03BD

Device description

BAS-IP AV-03BD is a stylish panel that will surely fit perfectly into the interior
of any office center. The panel is made of high quality plastic and can be used
in almost any room.
Appearance

Main features

• Panel type: Individual.
• Camera: 1/4".
• Resolution: 2 Мp.
• Сamera angle: 90° (horizontal).
• Output video: HD (1280 × 720), H.264 Main Profile.
• Night backlight: 6 LEDs.
• Light sensitivity: 0,01 LuX.
• Protection class: IP64.
• IK-Code: IK06.
• Working temperature: -40 — +65 °С.
• Power consumption: 6,5 W, in standby — 2,5 W.
• Power supply: +12 V DC, PoE 802.3af.
• Body: ABS plastic.
• Colors: Black, Silver.
• Size of the panel: 102 × 160 × 46 mm.
• Installation: Surface mount with and without a hood
(brackets included).
1
2
3
4
5
6
1 - Microphone.
2 - Camera.
3 - Backlight.
Full User Manual
wiki.bas-ip.com
4 - Reader.
5 - Loudspeaker.
6 - Sensor call button.
