- Page 1 I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L GAS GRIDDLE RANGES ELECTRIC OVEN GPE 5 06 GPE 5 6 GPE 5 08 GPE 5 8 232432-8...
- Page 2 800 263 1455 (Toll Free) NEW ZEALAND Moffat Limited Web: www.moffat.co.nz E.Mail: sales@moffat.co.nz Main Office: (tel): 0800 663328 UNITED KINGDOM Blue Seal Web: www.blue-seal.co.uk E.Mail: sales@blue-seal.co.uk Sales: (tel): +44 121 327 5575 (fax): +44 121 327 9711 Spares: (tel): +44 121 322 6640...
- Page 3 GPE506 Gas Griddle Range, Electric Static Oven - 900mm. GPE56 Gas Griddle Range, Electric Convection Oven - 900mm. GPE508 Gas Griddle Range, Electric Static Oven - 1200mm. GPE58 Gas Griddle Range, Electric Convection Oven - 1200mm. Model Numbers Covered in this Specification...
- Page 4 We are confident that you will be delighted with your BLUE SEAL Gas Griddle Range - Electric Oven and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Blue Seal appliance, there are two important things you can do.
-
Page 5: Input Rating
GPE506 Gas Griddle Range, Electric Static Oven - 900mm. GPE56 Gas Griddle Range, Electric Convection Oven - 900mm. GPE508 Gas Griddle Range, Electric Static Oven - 1200mm. GPE58 Gas Griddle Range, Electric Convection Oven - 1200mm. (*) NOTE: GPE506/ GPE508/... - Page 6 6.5 kW, 6.5 kW L2 - 9.2 Amps GPE508 26.6 Amps @ 235 V L3 - 9.2 Amps L1 - 9.5 Amps GPE56 6.8 kW, 6.8 kW L2 - 9.2 Amps GPE58 27.9 Amps @ 235 V L3 - 9.2 Amps...
- Page 7 GPE506 / GPE56 GPE508 / GPE58...
-
Page 8: Combustion Air Requirements
Blue Seal Gas Griddles / Electric Oven Ranges are designed to provide years of satisfactory service and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. - Page 9 NOTE: Only non-combustible materials can be used in close proximity to this appliance. Left / Right Hand Side 50mm Rear 50mm NOTE: All Models are delivered completely assembled. No further assembly is required. Refer to the information below for assembly instructions. ...
- Page 10 NOTE: A Manual Isolation Valve must be fitted to the individual appliance supply line. Correctly locate the appliance into its final operating position and using a spirit level, adjust the legs so that the unit is level and at the correct height. Connect the gas supply to the appliance.
-
Page 11: Installation
Check the Oven Heating. Check the Oven Thermostat Operation. Check the Oven Fan Operation (GPE56 and GPE58 Ovens Only). Ensure that the operator has been instructed in the areas of correct lighting, operation, and shutdown procedure for the appliance. - Page 12 Piezo Igniters Ignites the Griddle Pilot Burners. Gas Griddle Controls OFF Position PILOT Burner Temperature Gradient Oven Top Heat Control ๐ OFF Position Position Position Position Heating Indicator Position Lamps (Amber) for Top & Position Bottom Elements HIGH Position Power Indicator Lamp (White) Oven Thermostat Control...
- Page 13 350°C URFACE TEMPERATURE OF THE GRIDDLE PLATE CAN REACH OVER WHEN THE APPLIANCE IS OPERATED AT FULL HEAT SETTING These griddles are fitted with a pilot as a standard option and Flame Failure Protection, which is incorporated by way of a thermo-electric system for each main burner. Flame Failure Protection will shut ‘Off’...
- Page 14 DO NOT USE aluminium foil or trays directly on the cast iron sole plate(s). NEVER block or cover the openings on each side of the sole plate(s). (GPE56 / 58) are fitted with a circulation fan. NOTE: The Thermostat on the static oven provides overall control of the temperature within the oven by controlling both elements, whereas the Oven Top Heat Control provides a means of balancing the distribution of heat between the top and bottom of the oven.
- Page 15 Clean the range regularly. A clean range looks better, will last longer and will perform better. Carbonised grease on the surface or on the griddle plate will hinder the transfer of heat from the cooking surface to the food. This will result in loss of cooking efficiency. NOTE: Each Heavy Duty Griddle is supplied with a scraper tool and a pack of blades for cleaning the griddle surface.
- Page 16 The grease drawer should be checked and emptied frequently to prevent overflow and spillage. Remove the grease drawer while still warm so that the grease is in a liquid state. Empty any grease from the drawer and wash thoroughly in the same manner as any cooking utensil. Clean the Control Panel with a damp cloth lightly moistened with a solution of mild detergent and water.
-
Page 17: Stainless Steel Surfaces
Griddle - Chrome Plate Stainless Steel Surfaces a. Clean the exterior surfaces of the range with hot water, a mild detergent solution and a soft scrubbing brush. Note that the gas control knobs are a push fit onto the gas control valve spindles and can be removed to allow cleaning of the front control panel. - Page 18 This section provides an easy reference guide to the more common problems that may occur during the operation of your appliance. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section.
- Page 21 Wiring Layout for Static Oven Wiring Layout for Convection Oven...
-
Page 22: Main Burner Injectors
NOTE: Gas conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance. Adjustment of components that have adjustments / settings sealed (e.g. paint sealed) can only be adjusted in accordance with the following instructions and shall be re-sealed before re-commissioning this appliance. - Page 23 NOTE, Pin rotated for Natural Gas NOTE: Gas regulator supplied convertible between Natural Gas and LP Gas, but it’s outlet pressure is fixed ex-factory and NOTE, Pin rotated is NOT to be adjusted. for LPG - Town Gas Only. Remove slotted cap from regulator. Cap Nut Turn ‘On’...
- Page 24 1.80mm 1.65mm 5.50mm 3.00mm GPE506/GPE56 Main Burner 1.70mm 1.55mm 5.20mm 2.85mm GPE508/GPE58 Pilot Injector 0.41 0.25 0.75 Low Fire Adjustment 1 Full Turn Counter Clockwise from the 'Fully In' Position. High Fire Adjustment Maximum Flow Screw. Fully In c.w. Burner Aeration Setting...
-
Page 25: Replacement Parts List
229885 Thermocouple Interruped - Leaded (If Overtemp Fitted). 019218 Thermocouple (If no Overtemp Fitted). 032300 Main Injector (Nat Gas) 3.00mm (GPE506 / GPE56). 032285 Main Injector (Nat Gas) 2.85mm (GPE508 / GPE58). 032180 Main Injector (LPG) 1.80mm (GPE506 / GPE56). -
Page 26: Gas Regulators
228531 ¾” BSP F/F Convertible. Butane Town Gas 230185 ¾” BSP F/F Adjustable. - UK Only 232033 232032 232034 232035 GPE506 / GPE56 232037 232036 232038 232039 GPE508 / GPE58 232033 232032 GPE506 / GPE56 GPE508 / GPE58 232037 232036...
