S e r v i c e M a n u a l
Blue Seal Evolution Series E43 / E44 Electric Fryers
Service Manual
© Copyright Moffat Ltd. June 2016.
Amendment 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Evolution Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Blue Seal Evolution Series

Summary of Contents for Blue Seal Evolution Series

  • Page 1 Electric Frye rs E43 / E43E and E44 / E44E S e r v i c e M a n u a l Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016.
  • Page 2 ALL INSTALLATION AND SERVICE REPAIR WORK MUST BE CARRIED OUT BY QUALIFIED PERSONS WARNING: ONLY. IMPORTANT: MAKING ALTERATIONS MAY VOID WARRANTIES AND APPROVALS. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 3: Table Of Contents

    E44E - Double Tank Fryer - Electronic Control Wiring Diagrams ........................45 Service Contacts ........................49 Appendix A: Controller Programming ..................... 50 Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 4 Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 5: Specifications

    Specifications External Dimensions: E43 Fryer LEGEND - Electrical connection entry point Dimensions shown in millimetres. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 6 Specifications External Dimensions: E44 Fryer LEGEND - Electrical connection entry point Dimensions shown in millimetres. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 7 Specifications External Dimensions: E43E Fryer LEGEND - Electrical connection entry point Dimensions shown in millimetres. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 8 Specifications External Dimensions: E44E Fryer LEGEND - Electrical connection entry point Dimensions shown in millimetres. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 9 10kg (per tank) Useable internal dimensions of tank 365mm x 380mm 175mm x 380mm (width x length) Useable depth of oil 95mm 95mm Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 10: Installation

    NOTE: It is most important that this appliance is installed correctly and that operation is correct before use. Installation shall comply with local electrical and health and safety requirements. Blue Seal Deep Fryers are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation.
  • Page 11  Make sure that the electrical supply is turned off before any service or maintenance work is carried out. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 12: Operation

    Switches to operate). Mains Isolation Turns power ‘ON’ and ‘OFF’ to the Switch unit. (Green LED Indicator illuminates when switched ‘ON’). Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 13 - Temperature Display Mode Setting (Temp display or prompt display). - Programming the Melt Cycle. - Setting the Temperature Units (either °C or °F). Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016.

  • Page 14: Maintenance

    Name (print): Title: Customers signature: Date: It is recommended that this form is photocopied and kept on file for continued use. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 15: Fault Finding Guide

    Adjust spring tension. lifted for cleaning. (Refer Service Section 6.3.3). Element tensioning spring broken. Replace element tensioning spring. (Refer Service Section 6.2.12). Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 16 Adjust spring tension. lifted for cleaning. (Refer Service Section 6.3.3). Element tensioning spring broken. Replace element tensioning spring. (Refer Service Section 6.2.12). Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 17 Spring tension incorrectly adjusted. Adjust spring tension. (Refer Service lifted for cleaning Section 6.3.3). Spring broken. Replace spring. (Refer Service Section 6.2.12). Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 18 Spring tension incorrectly adjusted. Adjust spring tension. (Refer Service lifted for cleaning Section 6.3.3). Spring broken. Replace spring. (Refer Service Section 6.2.12). Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 19: Fault Diagnosis

    If there is no voltage (and the oil is below 150°C, requires recalibration. with the reset button not tripped) then the overtemp is faulty - replace. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 20 With power isolated from the unit, check for continuity through the poles of the heating contactor. If there is continuity then the contactor is faulty - replace. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016.

  • Page 21: Service Procedures

    ALL INSTALLATION AND SERVICE REPAIR WORK MUST BE CARRIED OUT BY QUALIFIED PERSONS ONLY. WARNING: ENSURE SUPPLY IS SWITCHED OFF BEFORE SERVICING ALWAYS TEST AFTER SERVICE REPAIRS Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 22: Access

    Remove panel from fryer. The panel will now hinge down to allow access to the over- temp. Two screws Figure 6.1.2 Figure 6.1.4 Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 23: Replacement

    Figure 6.2.1b Remove all wires from thermostat and separate thermostat from switch by pulling thermostat away from switch. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 24: Controller & Overlay (E Models)

    Replace with new probe. Ensure that probe hole in the Fuse element mounting panel is sealed with silicon and the wire are fitted correctly. Figure 6.2.4 Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 25: Overtemp Thermostat

    Remove wires from overtemp thermostat and withdraw it from the fryer. Replace the overtemp thermostat and re-assemble in re- verse order. On / Off Switch Figure 6.2.8 Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 26: Contactor

    Refit contactor access panel. Relay Element Nuts Figure 6.2.11b Withdraw the faulty element from the fryer. Replace and Figure 6.2.10 re-assemble in reverse order. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 27: Element Spring

    Undo two screws securing the transformer and remove from fryer. Transformer Spring Adjustment Nut Figure 6.2.12b Transformer Wires Figure 6.2.14 Fit new transformer and connect wiring. Re-assemble fryer. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 28: Adjustment / Calibration

    Adjustment Nut clockwise. Adjustment of the calibration nut by 1° angular will alter oven temperature by approximately 2°C (3.6°F). Figure 6.2.13 Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 29: Accessories

    To Cooktop Griddle To Chargrill To Griddle To Griddle Toaster To Cooktop Electric-Griddle LH (Part No. 228896) RH (Part No. 228897) Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 30: Replacement Parts

    8.4.1 Main Assembly ..............................41 8.4.2 Main Assembly ..............................42 8.4.3 Element Tilt Assembly ............................43 8.4.4 Electrical Assembly ..............................44 Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 31: E43 - Single Tank Fryer - Manual Control

    227972 ELECTRIC FRYER TANK 228414 TOP PIVOT STUD 045411 M5 SPRING WASHER 5-10 044015 3/16 BSW NUT 10-50 239961 ELEMENT SHROUD Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 32: Main Assembly

    BALL VALVE 227852 LEG PLATE 227850 LEG 150mm (FLUSH STUD) 5-10 229674 REAR ROLLER ASSY 10-50 229671 LEG RING PLATE THREADED Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 33: Element Tilt Assembly

    MICROSWITCH LINK ARM 227975 ELEMENT PIVOT BUSH 228539 ELEMENT SWITCH CRANK 5-10 228544 CRANK MTG BRACKET 10-50 228563 MICROSWITCH ACTUATOR ARM Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 34: Electrical Assembly

    MICROSWITCH INSULATOR 024802 DOOR MICROSWITCH E32/G32 228375 ACTUATOR ON/OFF RED/YELLOW 5-10 228374 LOAD SWITCH ON/OFF 32A 3 POLE 10-50 229582 NEUTRAL TERMINAL Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 35: E43E - Single Tank Fryer - Digital

    227972 ELECTRIC FRYER TANK 228414 TOP PIVOT STUD 045411 M5 SPRING WASHER 5-10 044015 3/16 BSW NUT 10-50 239961 ELEMENT SHROUD Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 36: Main Assembly

    BALL VALVE 227852 LEG PLATE 227850 LEG 150mm (FLUSH STUD) 5-10 229674 REAR ROLLER ASSY 10-50 229671 LEG RING PLATE THREADED Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 37: Element Tilt Assembly

    MICROSWITCH LINK ARM 227975 ELEMENT PIVOT BUSH 228539 ELEMENT SWITCH CRANK 5-10 228544 CRANK MTG BRACKET 10-50 228563 MICROSWITCH ACTUATOR ARM Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 38: Electrical Assembly

    ACTUATOR ON / OFF RED/YELLOW 228374 LOAD SWITCH ON/OFF 32A 3 POLE 229582 NEUTRAL TERMINAL 5-10 020532 RELAY BASE 10-50 020256 RESET RELAY 24V AC Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 39: E44 - Twin Tank Fryer - Manual

    227973 ELECTRIC FRYER TANK 228414 TOP PIVOT STUD 5-10 045411 M5 SPRING WASHER 044015 3/16 BSW NUT 10-50 239961 ELEMENT SHROUD Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 40: Main Assembly

    BALL VALVE 227852 LEG PLATE 227850 LEG 150mm (FLUSH STUD) 5-10 229674 REAR ROLLER ASSY 10-50 229671 LEG RING PLATE THREADED Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 41: Element Tilt Assembly

    MICROSWITCH LINK ARM 227975 ELEMENT PIVOT BUSH 228539 ELEMENT SWITCH CRANK 5-10 228544 CRANK MTG BRACKET 10-50 228563 MICROSWITCH ACTUATOR ARM Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 42: Electrical Assembly

    013977 MICROSWITCH INSULATOR 021965 LABEL - RESET 228375 ACTUATOR ON/OFF RED/YELLOW 228374 LOAD SWITCH ON/OFF 32A 3 POLE 229582 NEUTRAL TERMINAL Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 43: E44E Twin Tank Fryer - Digital

    227973 ELECTRIC FRYER TANK 228414 TOP PIVOT STUD 5-10 045411 M5 SPRING WASHER 044015 3/16 BSW NUT 10-50 239961 ELEMENT SHROUD Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 44: Main Assembly

    BALL VALVE 227852 LEG PLATE 5-10 227850 LEG 150mm (FLUSH STUD) 229674 REAR ROLLER ASSY 10-50 229671 LEG RING PLATE THREADED Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 45: Element Tilt Assembly

    MICROSWITCH LINK ARM 227975 ELEMENT PIVOT BUSH 5-10 228539 ELEMENT SWITCH CRANK 10-50 228544 CRANK MTG BRACKET 228563 MICROSWITCH ACTUATOR ARM Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 46: Electrical Assembly

    ACTUATOR ON/OFF RED/YELLOW 228374 LOAD SWITCH ON/OFF 32A 3 POLE 229582 NEUTRAL TERMINAL 5-10 020532 RELAY BASE 10-50 020256 RESET RELAY 24V AC Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 47: Wiring Diagrams

    Wiring Diagrams E43 - Single Tank Fryer Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 48 Wiring Diagrams E43E - Single Tank Fryer Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 49 Wiring Diagrams E44 - Twin Tank Fryer Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 50 Wiring Diagrams E44E - Twin Tank Fryer Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 51: Service Contacts

    1800 551 8795 +1 336 661 9546 NATIONAL COVERAGE FOR SERVICE OR MAINTENANCE DIAL FREE CALL 866 673 7937 (USA ONLY). Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...

  • Page 52: Appendix A: Controller Programming

    ‘ULoc’ (No password protection). Press the Programme Key ‘P’, the change will be accepted and the display will step on to the next parameter. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016.
  • Page 53 'Timer 2’ behaves the same as 'Timer 1’ shown above. 'Timer (3)'. 'Timer (3)’ behaves the same as the 'Timer 1’ shown above. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016.
  • Page 54 Programme Key ’P’ for approximately 3 seconds, or do not press any key for 2 minutes. The display will revert to the ‘Idle Mode’. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016.
  • Page 55 Cook time can be automatically adjusted to compensate for load size being cooked. Select the option required by pressing the 'Program' key. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
  • Page 56 Pressing and holding the Programming Key for approximately 3 seconds (Or not pressing any keys for 2 minutes) the appliance will exit the Advanced Programming Mode and return to the ‘Idle Mode’. Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016.
  • Page 57 °C Number of Product Timers Timing Mode S.t (Straight) Temperature Offset 0° Temperature Display Mode t. -0 = 'HEAt' or 'droP' Blue Seal Evolution Series E43 / E44 Electric Fryers Service Manual © Copyright Moffat Ltd. June 2016. Amendment 7...
