I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L
GAS COOKTOP
Se ri e s
G5 1 2
G5 1 4
G5 1 5
G5 1 6
G5 1 8
229363-20

Advertisement

loading
Need help?

Need help?

Do you have a question about the G512 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Blue Seal G512 Series

Summary of Contents for Blue Seal G512 Series

  • Page 1 I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L GAS COOKTOP Se ri e s G5 1 2 G5 1 4 G5 1 5 G5 1 6 G5 1 8...
  • Page 2 800 263 1455 (Toll Free) NEW ZEALAND Moffat Limited Web: www.moffat.co.nz E.Mail: sales@moffat.co.nz Main Office: (tel): 0800 663328 UNITED KINGDOM Blue Seal Web: www.blue-seal.co.uk E.Mail: sales@blue-seal.co.uk Sales: (tel): +44 121 327 5575 (fax): +44 121 327 9711 Spares: (tel): +44 121 322 6640...
  • Page 3 Blue Seal Gas Cooktops G512 Gas Cooktop 300mm wide. G514 Gas Cooktop 600mm wide. G515 Gas Cooktop 750mm wide. G516 Gas Cooktop 900mm wide. G518 Gas Cooktop 1200mm wide. Model Numbers Covered in this Specification General Gas Supply Requirements Gas Connection...
  • Page 4 We are confident that you will be delighted with your BLUE SEAL COOKTOP, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new BLUE SEAL COOKTOP, there are two important things you can do.
  • Page 5 - With Pilot and Flame Failure Protection. [2] - Base Stand Options; - Bench Mount. - Cabinet Base (excluding G512 series). - Leg Stand (excluding G512 series). - Refrigerated Base (G516 and G518 series only). A heavy duty, high efficiency Cooktop for modular kitchens. It has a high option Cooktop / Griddle arrangement and is available either on industrial adjustable feet or on robust rollers.
  • Page 6 - Australia Input Rate (N.H.G.C.) 28 MJ/hr 28 MJ/hr - each Open Burner - each 300mm Griddle Section 21 MJ/hr 21 MJ/hr 1.13 - 3.40 kPa 2.75 - 4.50 kPa Supply Pressure 0.95 kPa 2.6 kPa Burner Operating Pressure (*) See ‘Gas Connection’...
  • Page 7 - All Other Markets Input Rate (N.H.G.C.) 28 MJ/hr 28 MJ/hr - each Open Burner - each 300mm Griddle Section 21 MJ/hr 21 MJ/hr 1.13 - 3.40 kPa 0.75 - 1.50 kPa Supply Pressure 0.95 kPa 0.63 kPa Burner Operating Pressure (*) See ‘Gas Connection’...
  • Page 8 = Rating Plate Location for this option. Refer to Page 9 for Cooktop Options...
  • Page 9 G512 models - not available in Cabinet Base option. = Rating Plate Location for this option. Refer to Page 9 for Cooktop Options...
  • Page 10 G512 models - not available in Leg Stand Base option. = Rating Plate Location for this option. Refer to Page 9 for Cooktop Options...
  • Page 11 G512 and G514 models - not available in Refrigerated Base option. = Rating Plate Location for this option. Refer to Page 9 for Cooktop Options...
  • Page 12 NOTE:  G512 models are only available in Bench Model (-B) option.  G514 models are available in Bench Model (-B), Cabinet Base (-CB), or Leg Stand (-LS) model options.  G516 and G518 models are available in Bench Model (-B), Cabinet Base (-CB), Leg Stand (-LS), or Refrigeration Base (-RB) model options.

  • Page 13: Combustion Air Requirements

    Blue Seal Cooktops are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. This appliance must be installed in accordance with National installation codes and in addition, in accordance with relevant National / Local codes covering gas and fire safety.
  • Page 14 NOTE: Only non-combustible materials can be used in close proximity to this appliance. Left / Right hand side 250mm (*) Rear 50mm Side clearances can be 50mm when adjacent surface is at least 100mm below cooking surface. NOTE:  All Models are delivered completely assembled. No further assembly is required, with exception of all Leg Stand Models (G514-LS, G516-LS G518-LS), these will require assembly.
  • Page 15 NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A QUALIFIED PERSON. Blue Seal Cooktops do not require electrical connection, as they function totally on the gas supply. It is essential that gas supply is correct for Cooktop being installed and that adequate supply pressure and volume are available.

  • Page 16: Installation

    Before leaving the new installation; Check the following functions in accordance with operating instructions specified in ‘Operation’ section of this manual.  Lighting the Griddle.  Light the Open Burners. (F - Option).  Light the Open Burners. (PF - Option). ...
  • Page 17 Blue Seal appliances have been designed to provide simplicity of operation and 100% safety protection. Improper operation is almost impossible, however bad operation practices can reduce the life of the appliance and produce a poor quality product. To use this appliance correctly please read the following sections carefully:- ...
  • Page 18 Lighting the Open Burners Flame Failure Protection is incorporated for each burner by way of a thermo-electric system which will shut off gas supply to that burner in the event that burner goes out, so that un-burnt gas is not expelled.

  • Page 19: Lighting The Griddle

    ! IMPORTANT Always ensure that the grease tray is emptied regularly and never allow the grease tray to overflow. Lighting the Griddle a. Depress gas control knob and rotate anti-clockwise to ‘PILOT’ position. b. Hold gas control knob depressed, press piezo ignition button to ignite pilot burner. Repeat Items 1 to 2 until pilot is lit.
  • Page 20 NOTE:  Allow appliance to cool before commencing cleaning.  DO NOT use abrasive or strong caustic detergents as they could corrode or damage the Cooktop.  Ensure that any detergent or cleaning material has been completely removed after each cleaning.
  • Page 21 1. Remove pot stands, burner caps, burner bowls and pot stand supports from top of cooktop. Wash with hot soapy water, using a soft HE BLADES FITTED TO THE SCRAPER TOOL ARE EXTREMELY SHARP bristled brush. Dry thoroughly with a dry cloth. AND ARE TO BE USED WITH CARE Any baked-on deposits can be scraped off using a scraper tool.
  • Page 22 This section provides an easy reference guide to the more common problems that may occur during operation of your equipment. This fault finding guide is intended to help you accurately diagnose and correct problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section.
  • Page 23 NOTE:  These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance.  Adjustment of components that have adjustments / settings sealed (e.g. paint sealed) can only be adjusted in accordance with the following instructions and shall be re-sealed before re-commissioning this appliance.
  • Page 24 Piezo Igniter Pilot Supply Tube Carry out the following:-  Remove griddle plate section and heat shield.  Remove main burner.  Disconnect piezo igniter from mounting bracket. (For access purposes). Pilot Burner  Disconnect pilot supply tube from pilot burner to access pilot injector.
  • Page 25 NOTE, Pin rotated - NAT Gas / LPG / Butane Only. for Natural Gas NOTE: The gas regulator supplied is convertible between Natural Gas and LP Gas, but it’s outlet NOTE, Pin rotated pressure is fixed ex-factory and for LPG is NOT to be adjusted.
  • Page 26 - Australia Main Burner Ø 2.45mm Ø 1.50mm Open Burner Pilot Burner ('PF' Models Only) 0.30 0.20 Main Burner Ø 2.10mm Ø 1.30mm Pilot Burner 0.35 0.23 Griddle Burner Aeration Setting Fully open Fully open Supply Pressure 1.13 - 3-40 kPa 2.75 - 3-40 kPa Burner Operating Pressure (*) 0.95 kPa...
  • Page 27 - All Other Markets Main Burner Ø 2.45mm Ø 4.50mm Open Burner Pilot Burner ('PF' Models only) 0.30 0.60 Main Burner Ø 2.10mm Ø 3.40mm Griddle Pilot Burner 0.35 0.60 Burner Aeration Setting Fully open Fully open Supply Pressure 1.13 - 3-4 kPa 0.75 - 1.5 kPa Burner Operating Pressure (*) 0.95 kPa...

  • Page 28: Replacement Parts List

    Replacement Parts List ! IMPORTANT When ordering replacement parts, please quote part number and description as listed below. If part required is not listed below, request part by description and quote model number and serial number of equipment, which is shown on rating plate. Cooktops Open Burners 235678...
  • Page 29 General 227014 Pot Stand. 230286 Spill Tray (G512 Series). 230277 Spill Tray (G514 Series). 233515 Spill Tray (G516 Series). 233517 Spill Tray LH (G518 Series). 233518 Spill Tray RH (G518 Series). 227855 Adjustable Legs (84mm - Bench Models). 227850 Adjustable Legs (Flush Stud) (150mm - CB / RB Models).
