Page 1: Electric Oven
I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L GAS GRIDDLE RANGES ELECTRIC OVEN GPE506 GPE56 GPE508 GPE58 232432-8... - Page 2 800 263 1455 (Toll Free) NEW ZEALAND Moffat Limited Web: www.moffat.co.nz E.Mail: sales@moffat.co.nz Main Office: (tel): 0800 663328 UNITED KINGDOM Blue Seal Web: www.blue-seal.co.uk E.Mail: sales@blue-seal.co.uk Sales: (tel): +44 121 327 5575 (fax): +44 121 327 9711 Spares: (tel): +44 121 322 6640...
-
Page 3: Table Of Contents
Contents Blue Seal Gas Griddle Ranges - Electric Oven GPE506 Gas Griddle Range, Electric Static Oven - 900mm. GPE56 Gas Griddle Range, Electric Convection Oven - 900mm. GPE508 Gas Griddle Range, Electric Static Oven - 1200mm. GPE58 Gas Griddle Range, Electric Convection Oven - 1200mm. -
Page 4: Introduction
Introduction We are confident that you will be delighted with your BLUE SEAL Gas Griddle Range - Electric Oven and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Blue Seal appliance, there are two important things you can do. -
Page 5: Specifications
Specifications Model Numbers Covered in this Specification GPE506 Gas Griddle Range, Electric Static Oven - 900mm. GPE56 Gas Griddle Range, Electric Convection Oven - 900mm. GPE508 Gas Griddle Range, Electric Static Oven - 1200mm. GPE58 Gas Griddle Range, Electric Convection Oven - 1200mm. -
Page 6: Electrical Supply Requirements
Electrical Supply Requirements 1-Phase Connection 3-Phase Connection MODEL 1P+N+E 3P+N+E 230-240V 400-415V L1 - 8.2 Amps GPE506 6.5 kW, 6.5 kW L2 - 9.2 Amps GPE508 26.6 Amps @ 235 V L3 - 9.2 Amps L1 - 9.5 Amps GPE56 6.8 kW,... -
Page 7: Dimensions
Dimensions GPE506 / GPE56 GPE508 / GPE58... -
Page 8: Installation
Blue Seal Gas Griddles / Electric Oven Ranges are designed to provide years of satisfactory service and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. -
Page 9: Clearances
Installation Clearances NOTE: Only non-combustible materials can be used in close proximity to this appliance. Combustible Surface Non Combustible Surface Left / Right Hand Side 50mm Rear 50mm Assembly NOTE: All Models are delivered completely assembled. No further assembly is required. Refer to the information below for assembly instructions. -
Page 10: Electrical Connection
Installation NOTE: A Manual Isolation Valve must be fitted to the individual appliance supply line. Correctly locate the appliance into its final operating position and using a spirit level, adjust the legs so that the unit is level and at the correct height. Connect the gas supply to the appliance. -
Page 11: Commissioning
Installation Caution Changing supply from 3 phase to single phase will increase electrical current loading on supply cable. Ensure supply cable used is of a sufficient size for current loading, refer to 'Electrical Supply Requirements' table. Connect neutral and earth conductors to neutral stud and earth stud respectively. For all connections ensure that conductors are secure and appropriately terminated. -
Page 12: Operation
Components having adjustments protected (e.g. paint sealed) manufacturer should not be adjusted by the user / operator. Description of Controls (GPE506 Model Shown) Piezo Igniters Ignites the Griddle Pilot Burners. Gas Griddle Controls OFF Position PILOT Burner Temperature Gradient Oven Top Heat Control ๐... -
Page 13: Lighting The Griddle - Pilots
Operation Lighting the Griddle - Pilots Warning 350°C URFACE TEMPERATURE OF THE GRIDDLE PLATE CAN REACH OVER WHEN THE APPLIANCE IS OPERATED AT FULL HEAT SETTING These griddles are fitted with a pilot as a standard option and Flame Failure Protection, which is incorporated by way of a thermo-electric system for each main burner. -
Page 14: Turning 'Off' The Griddle Main Burner / Pilot
Operation Turning 'Off' the Griddle Main Burner / Pilot Turn the gas control knob clockwise to the pilot position. The main burner will extinguish and the pilot burner will remain alight. To turn 'OFF' the appliance completely, turn the gas control knob fully clockwise to the 'O' position, the pilot burner will extinguish. -
Page 15: Cleaning And Maintenance
Cleaning and Maintenance General Caution Always turn ‘Off’ the gas and electrical supply before cleaning the range. This appliance is not water proof. Do not use water jet spray to clean interior or exterior of this appliance. Clean the range regularly. A clean range looks better, will last longer and will perform better. Carbonised grease on the surface or on the griddle plate will hinder the transfer of heat from the cooking surface to the food. -
Page 16: Daily Cleaning
Cleaning and Maintenance Daily Cleaning The grease drawer should be checked and emptied frequently to prevent overflow and spillage. Remove the grease drawer while still warm so that the grease is in a liquid state. Empty any grease from the drawer and wash thoroughly in the same manner as any cooking utensil. Clean the Control Panel with a damp cloth lightly moistened with a solution of mild detergent and water. -
Page 17: Periodic Maintenance
Cleaning and Maintenance Griddle - Chrome Plate Stainless Steel Surfaces a. Clean the exterior surfaces of the range with hot water, a mild detergent solution and a soft Caution scrubbing brush. Note that the gas control knobs are a push fit onto the gas control valve Always apply even pressure over whole surface of the scraper tool when using spindles and can be removed to allow cleaning of the front control panel. -
Page 18: Fault Finding
Fault Finding This section provides an easy reference guide to the more common problems that may occur during the operation of your appliance. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. -
Page 19: Wiring Schematics
Wiring Schematics Static Ovens (GPE506 and GPE508) - Page 20 Wiring Schematics Convection Ovens (GPE56 and GPE58)
-
Page 21: Wiring Schematics
Wiring Schematics Wiring Layout for Static Oven Wiring Layout for Convection Oven... -
Page 22: Gas Conversion And Specifications
Gas Conversion and Specifications Conversion Procedure Caution Ensure Appliance is isolated from gas supply before commencing servicing. NOTE: Gas conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance. ... -
Page 23: Gas Regulator
Gas Conversion and Specifications Gas Regulator NOTE, Pin rotated for Natural Gas NOTE: Gas regulator supplied convertible between Natural Gas and LP Gas, but it’s outlet pressure is fixed ex-factory and NOTE, Pin rotated is NOT to be adjusted. for LPG - Town Gas Only. -
Page 24: Gas Specifications
Gas Conversion and Specifications Gas Specifications Natural Gas Butane Town Gas 1.80mm 1.65mm 5.50mm 3.00mm GPE506/GPE56 Main Burner 1.70mm 1.55mm 5.20mm 2.85mm GPE508/GPE58 Pilot Injector 0.41 0.25 0.75 Low Fire Adjustment 1 Full Turn Counter Clockwise from the 'Fully In' Position. -
Page 25: Replacement Parts List
229885 Thermocouple Interruped - Leaded (If Overtemp Fitted). 019218 Thermocouple (If no Overtemp Fitted). 032300 Main Injector (Nat Gas) 3.00mm (GPE506 / GPE56). 032285 Main Injector (Nat Gas) 2.85mm (GPE508 / GPE58). 032180 Main Injector (LPG) 1.80mm (GPE506 / GPE56). - Page 26 - Australia / New Zealand Only Gas Type to Convert to Models Nat. Gas Butane Town Gas 232033 232032 232034 232035 GPE506 / GPE56 232037 232036 232038 232039 GPE508 / GPE58 - UK Only Gas Type to Convert to Models Nat. Gas...
