I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L GAS BRATT PAN G5 8 0 -8 G58 0 -8 E G5 8 0 -1 2 G58 0 -1 2 E 229365-15...
Page 2
800 263 1455 (Toll Free) NEW ZEALAND Moffat Limited Web: www.moffat.co.nz E.Mail: sales@moffat.co.nz Main Office: (tel): 0800 663328 UNITED KINGDOM Blue Seal Web: www.blue-seal.co.uk E.Mail: sales@blue-seal.co.uk Sales: (tel): +44 121 327 5575 (fax): +44 121 327 9711 Spares: (tel): +44 121 322 6640...
Page 3
Description of Controls Lighting Pilot Burner Lighting Main Burner Setting the Temperature Operating the Water Supply Valve Tilting the Pan - G580-8 / G580-12 Tilting the Pan - G580-8E / G580-12E Turning off the Bratt Pan (All Models) General After Each Use...
Page 4
We are confident that you will be delighted with your WALDORF GAS BRATT PAN, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Waldorf GAS BRATT PAN, there are two important things you can do.
Page 5
G580-12 / G580-12E - Gas Bratt Pan, Manual / Electric Tilt - 1200mm wide (120ltr). G580-8 /G580-8E (80 ltr) Gas Bratt Pan. A commercial heavy duty, gas fired Bratt Pan fitted with an 80 ltr capacity pan, of full stainless steel pan construction, with a single 6 bar chrome plated steel gas burner and electric piezo ignition giving even heat distribution.
Page 6
- Australia: G580-8 / 8E G580-12 / 12E G580-8 / 8E G580-12 / 12E Input Rating (N.H.G.C.) 72MJ/hr 90MJ/hr 72MJ/hr 90MJ/hr Supply Pressure 1.13 - 3.40kPa 2.75 - 4.50kPa Burner Operating Pressure (*) 0.76kPa 0.60kPa 2.5kPa 2.4kPa Gas Connection ¾” BSP Male...
Page 7
305mm from rear, 122mm from floor and is reached from beneath appliance. (Refer to ‘Dimensions’ section). Connection is ¾" BSP male thread. G580-8 / G580-12 - 220-240V a.c, 50 / 60Hz, 0.1kW, 1P+N+E. G580-8E / G580-12E - 220-240V a.c, 50 / 60Hz, 0.35kW, 1P+N+E.
Page 8
FRONT G580-8 SIDE G580-8 PLAN G580-8 Electrical Connection Point. Gas Connection Point. Water Connection Point.
Page 9
FRONT G580-8E SIDE G580-8E PLAN G580-8E Electrical Connection Point. Gas Connection Point. Water Connection Point.
Page 10
FRONT G580-12 SIDE G580-12 PLAN G580-12 Electrical Connection Point. Gas Connection Point. Water Connection Point.
Page 11
FRONT G580-12E SIDE G580-12E PLAN G580-12E Electrical Connection Point. Gas Connection Point. Water Connection Point.
Page 12
Installation shall comply with local gas, electrical and health and safety requirements. Blue Seal Bratt Pans are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation.
Page 13
The following minimum installation clearances are to be adhered to: Left / Right hand side 50mm Rear 50mm NOTE: Only non-combustible materials can be used in close proximity to this appliance. NOTE: This appliance must only be installed on adjustable feet supplied. It must not be fitted with rollers or castors as this appliance is intended for stationary installations only.
Page 14
Correctly locate appliance into its final operating position and using a spirit level, adjust legs so that unit is level and at correct height. Connect gas supply to appliance. A suitable joining compound which resists breakdown action of LPG must be used on every gas line connection, unless compression fittings are used. Check all gas connections for leakages using soapy water or other gas detecting equipment.
Before leaving the new installation; Check the following functions in accordance with operating instructions shown in ‘Operation’ section of this manual. Ensure all water pipework has been thoroughly flushed through prior to using bratt pan. Light Pilot Burners. ...
Page 16
Blue Seal bratt pans have been designed to provide simplicity of operation and 100% safety protection. Improper operation is almost impossible, however bad operation practices can reduce life of bratt pan and produce a poor quality product. To use this bratt pan correctly please carefully read the following sections.
Page 17
Manual Tilt Handwheel G580-8 / G580-12 Models. (8 &12 Models only) Water Flow Control Valve (All Models) OFF Position Graduated Flow Gas Control Knobs (All Models) Pilot Burner Heating Indicator Lamp (Amber) Graduations from 1 to 10 for heat control.
Page 18
Ensure mains power and gas supply is turned ‘On’ at mains supply. Push-in gas control knob and rotate anti-clockwise to PILOT position. Power indicator light (Green) should illuminate and ignitor should be heard operating. Hold gas control knob depressed, igniter will continue to operate until pilot is alight. Once pilot is lit (view through viewing port at front of bratt pan), continue holding ‘IN’...
Page 19
To turn bratt pan to ‘PILOT’ burner position, set gas control knob to ‘PILOT’ position. Main burner will turn ‘OFF’ and pilot burner will remain lit. To turn bratt pan ‘OFF’ completely, rotate gas control knob to ‘OFF’ position by depressing and turning gas control knob clockwise.
Page 20
Clean bratt pan regularly. A clean bratt pan looks better, will last longer and will perform better. A dirty bratt pan will hinder transfer of heat from cooking surface to food. This will result in loss of cooking efficiency. NOTE: ...
Page 21
NOTE: If bratt pan usage is very high, we recommend that weekly cleaning procedure is carried out more frequently. Ensure that protective gloves are worn during cleaning. DO NOT use harsh abrasive detergents, strong solvents, sharp scrapers or caustic detergents as they will damage surface of bratt pan.
Page 22
This section provides an easy reference guide to the more common problems that may occur during operation of your equipment. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section.
Page 23
Over-temperature thermostat cuts Over-temperature thermostat If main burners cut out and faulty. power indicator light also drops below 320ºC, replace over- temperature thermostat. Control thermostat not Check continuity through maintaining set temperature. thermostat leads, on a. Thermostat out of temperature rise. If circuit does calibration.
Page 26
Remove front control panel. Remove large front right hand cover panel. Refit hand wheel to allow pan to be raised / lowered during gas conversion procedure. (G580-8 & G580-12 models only). Remove main burner injectors and replace with correct size Aeration Sleeve injectors as shown in ‘Gas Specification Tables’...
Page 27
NOTE: Gas regulator supplied NOTE, Pin rotated convertible between Natural for Natural Gas Gas and LP Gas, but it’s outlet pressure is fixed ex-factory and is NOT to be adjusted. NOTE, Pin rotated for LPG On completion of gas conversion, replace gas type labels located at:- - Rear of unit, above gas connection.
Page 28
- Australia: G580-8 / 8E G580-12 / 12E G580-8 / 8E G580-12 / 12E Main Burner Injector Ø 4.30mm Ø 5.20mm Ø 2.50mm Ø 2.80mm Pilot Burner Injector 0.35 0.20 Aeration Clearance (H) 30mm 30mm Burner Operating Pressure (*) 0.76kPa 0.60kPa...
Page 29
- All Other Markets: G580-8 / 8E G580-12 / 12E G580-8 / 8E G580-12 / 12E G580-8 / 8E G580-12 / 12E Main Burner Ø 4.30mm Ø 5.20mm Ø 2.50mm Ø 2.80mm Ø 2.40mm Ø 2.60mm Pilot Burner 0.35 0.20 0.20...
Microswitch (Water Valve). 242085 Water Valve Kit (incl. Valve, Lever and Bracket) 020851 Water Solenoid Valve. 227841 Lid Handle - 650mm (G580-8 / G580-8E Models Only). 227847 Lid Handle - 830mm (G580-12 / G580-12E Models Only). 228716 Lid Hinge Spring Kit. 227521 Tensioner Barrel.
Page 31
Gas Conversion Kits G580-8 / 8E 232041 232040 232042 232041 232040 G580-12 / 12E 232045 232044 232046 232045 232044 Accessories 228798 Plinth Kit 900mm. 228802 Plinth Kit 1200mm.
