RG-SS6910 3C Series Switch Hardware Installation and Reference Guide
Power
Static power: 760 W, typical power: 1092 W, power with full load: 2046 W
Consumption
Refer to Appendix B
Optical Module
SFP28 Port Unsupported
QSFP28 Port Supported. The number of ports depends on the expansion module.
10GBASE-T Port Unsupported
Temperature
Support temperature warning and over-heating protection.
Warning
EMC Standards GB9254-2008 CLASS A
Safety Standards GB4943-2011
Working
0 ° C to 40 ° C (32 ° F to 104 ° F)
Temperature
Storage
-40 ° C to 70 ° C (-40 ° F to 158 ° F)
Temperature
Working Humidity 10% to 90% RH (non-condensing)
Weight Net weight: 42 kg (92.60 lbs, with 6 fan modules , 4 power modules and 3
Dimensions
442 mm x 735 mm x 173.6 mm, 4RU (17.40 in. x 28.93 in. x 6.83 in.)
(W x D x H)
RG-S6910-3C switch is a class A product. In a domestic environment, this product may cause radio interference in
which case the user may be required to take adequate measures.
The 100G Ethernet port of the RG-S6910-3C switch supports DAC. For a detailed model and specification, refer to
Appendix B.
Product Appearance
The hardware of the RG-S6910-3C includes the chassis, the power supply system and the heat dissipation system.

The power supply system: Provides four power supply slots, which support 2+2 power supply redundancy. It is
recommended users configure power supply redundancy.

The heat dissipation system: Provides six fan module slots, which support 5+1 fan redundancy. It is recommended
users configure all fans redundancy.
Figure 1-1 Appearance of the RG-S6910-3C
The supported modules update at any time, contact Ruijie Networks for details .
Product Overview
M6900-32CQ modules)
