RG-SS6910 3C Series Switch Hardware Installation and Reference Guide

1 Product Overview

RG-S6910-3C series switches are data center oriented high density 100G core switches, providing 100G access, low
latency, and complete data center features . RG-S6910-3C series switches provide 96 100G ports and can be used with
other aggregation switches to compose a high-performance and high-reliability data center network.
100G QSFP28
Model
Ethernet Port
RG-
-
S6910-3C
M6900-
32
32CQ
A QSFP28 port supports 100G/40G mode and 4x25G/4x10G mode.
1.1 RG-S6910-3C
Specifications
Model RG-S6910-3C
CPU Quad-core eight-thread CPU processer, 2.2 GHz, Intel Xeon D-1527
L2 Cache 16 MB
eMMC 64 GB
SDRAM DDR4 16 GB
MAC Cache 16 GB
Expansion
3
Module Slot
Expansion
M6900-32CQ
Module
Fan Slot 6 (support 5+1 redundancy, configure at least 5 fan modules in one switch)
Fan Module M2EFAN I-F
Power Supply
4 (support 2+2 redundancy)
Slot
Power Module RG-PA1200I-F
AC input
Rated voltage range: 100 VAC to 127 VAC
Frequency: 50 Hz to 60 Hz
Power Supply
Rated current: 12 A
Input
Rated voltage range: 200 VAC to 240 VAC
Frequency: 50 Hz to 60 Hz
Rated current: 9.6 A Max
25G/10G SFP28 10GBase-
Ethernet Port T
-
-
Expansion
Module Slot
- 3
- -
High voltage direct current (HVDC) input:
Input voltage range: 192 VDC to 288 VDC
Input current range: 6 A
Product Overview
Redundant Redundant
Fan Power Supply
5+1 2+2
- -
