RG-SS6910 3C Series Switch Hardware Installation and Reference Guide
Front Panel
Figure 1-2 Front Panel of the RG-S6910-3C
Notes: 1. Engine Slot
2. USB Port
3. MGMT Port
4. MGMT Indicator
5. Console Port
Rear Panel
Figure 1-3 Rear Panel of the S6910-3C
6. System Status Indicator
7. FIND Status Indicator
8. Expansion Module Slot
9. Mounting Bracket
Product Overview
