- Page 1 KIEN1026 Industrial Ethernet Switch Hardware Installation Manual Publication Data: Dec. 2013 Version: V1.1 No.: 1.12.02.1052-0...
- Page 2 KIEN1026 Industrial Ethernet Switch Hardware Installation Manual Disclaimer: Kyland Technology Co., Ltd. tries to keep the content of this manual as accurate and as updated as possible. This document is not guaranteed to be error-free, and we reserve the right to amend it without notice to users.
- Page 3 Before using the device, read this notice carefully for personal and equipment safety. Please keep the manual for further reference. Kyland is not liable to any personal or equipment damage caused by violation of this notice.
- Page 4 ● Dispose of the device in accordance with relevant national provisions, preventing environmental pollution. In the following cases, please immediately shut down your power supply and contact your Kyland represen- tative: ● Water gets into the equipment. ● Equipment damage or shell damage.
-
Page 5: Table Of Contents
Contents 1 Product Overview 2 Structure and Interface 2.1 Front Panel 2.2 Rear Panel 3 Mounting 3.1 Dimension Drawing 3.2 Mounting Modes and Steps 4 Connection 4.1 10/100Base-T(X) Ethernet Port 4.2 100Base-FX Ethernet Port 4.3 Grounding 4.4 Power Terminal Block 5 LEDs 6 Basic Features and Specifications... -
Page 6: Product Overview
EMC protection for power input, and sound EMC protection of RJ45 ports. KIEN1026 supports 19 inch 1U rack mounting. It provides up to twenty-four 10/100Base-T(X) Ethernet ports and two 100Base-FX Ethernet ports. For details, see the following table. -
Page 7: Structure And Interface
Structure and Interface 2 Structure and Interface Caution: It is recommended to purchase the port dustproof shield (optional) to keep ports clean and ensure switch performance. 2.1 Front Panel (2)(3) (1)(4) Figure 1 Front Panel Table 2 Description of the Front Panel... -
Page 8: Rear Panel
Structure and Interface 2.2 Rear Panel Figure 2 Rear Panel Table 3 Description of the Rear Panel PWR1 PWR2 +/L -/N -/N +/L... -
Page 9: Mounting
Mounting 3 Mounting 3.1 Dimension Drawing 482.6 Figure 3 Dimension Drawing (unit: mm) Caution: As part of the heat dissipation system, the switch housing becomes hot during operation. Please use caution when coming in contact and avoid covering the switch housing when the switch is running. -
Page 10: Mounting Modes And Steps
Mounting 3.2 Mounting Modes and Steps The series switches support rack mounting by the front/rear panel. The following uses mounting by front panel as an example to describe mounting steps. The steps for mounting by rear panel are similar to those for mounting by front panel. Before installation, make sure that the following requirements are met. - Page 11 Mounting You can select the screw holes for front or rear panel mounting to install the mounting brackets. If there are screws inserted in the screw holes, remove the screws and keep them for future use. As shown in the following figure, use three screws to secure two mounting brackets to the switch respectively.
- Page 12 Mounting Mounting Step 1: Select the mounting position for the switch and guarantee adequate space and heat dissipation (dimensions: 440mm×44mm×245mm). Step 2: Move the switch in direction 1 until the screw holes for securing the mounting brackets to rack posts are in alignment with the corresponding holes in the rack posts.
-
Page 13: Connection
Connection 4 Connection 4.1 10/100Base-T(X) Ethernet Port 10/100Base-T(X) Ethernet port is equipped with RJ45 connector. The port is self-adaptive. It can automatically configure itself to work in 10M or 100M state, full or half duplex mode. The port can also adapt to MDI or MDI-X connection automatically. - Page 14 Connection Wiring Sequence RJ45 connector RJ45 connector Straight-through cable Wiring sequence Cross-over cable Wiring sequence Figure 8 Connection Using Straight-through/Cross-over Cable Note: The color of the cable for RJ45 connector meets the 568B standard: 1-orange and white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8-brown.
-
Page 15: 100Base-Fx Ethernet Port
Connection 4.2 100Base-FX Ethernet Port 100Base-FX Ethernet port is equipped with FC/ST/SC connector, and each port consists of TX (transmit) port and RX (receive) port. To enable data transmission between Device A and Device B, connect the TX port of Device A to the RX port of Device B, and the RX port of Device A to the TX port of Device B. -
Page 16: Grounding
Connection 4.3 Grounding Grounding protects the switch from lightning and interference. There- fore, you must ground the switch properly. You need to ground the switch before it is powered on and disconnect the grounding cable after the switch is powered off. The switch provides a grounding screw on the rear panel for chassis grounding. -
Page 17: Power Terminal Block
Connection 4.4 Power Terminal Block There is a power terminal block on the rear panel of the device. You need to connect the power wires to the terminal block to provide power to the device. The device supports single (PWR1) and redun- dant (PWR1 and PWR2) power supply with a 5-pin 5.08mm-spacing plug-in terminal block. - Page 18 Connection The following table lists the pin definitions of the 5-pin 5.08mm- spacing plug-in terminal block. Table 5 Pin Definitions of 5-Pin 5.08mm-Spacing Plug-in Terminal Block Wiring and Mounting Step 1: Ground the device properly according to section 4.3. Step 2: Remove the power terminal block from the device. Step 3: Insert the power wires into the power terminal block according to Table 5 and secure the wires.
- Page 19 Connection PGND Power2:-/N Power1:-/N Power1:+/L Power2:+/L Plug Socket Figure 12 Connection of 5-Pin 5.08mm-Spacing Plug-in Terminal Block Caution: The switch supports 220AC/DCW and 24DC power input. Before connecting the device to power supply, make sure that the power input meets the power requirement. If connected to an incorrect power input, the device may be damaged.
-
Page 20: Leds
LEDs 5 LEDs Table 6 Front Panel LEDs... - Page 21 LEDs Table 7 Rear Panel LEDs Speed (yellow) Connection status (green)
-
Page 22: Basic Features And Specifications
Basic Features and Specifications 6 Basic Features and Specifications... - Page 24 FAX: +86-10-88796678 Website: http://www.kyland.com Email: support@kyland.com For more information about KYLAND products, please visit our website: http://www.kyland.com...
