  • Page 1 IMBM-H110A...
  • Page 2 E15316 Revised Edition v2 March 2019 Copyright Notice This document is copyrighted, 2019. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer.

  • Page 3: Table Of Contents

    Contents Chapter 1 Product overview Package contents................. 1-1 Features ..................1-1 Specifications ................1-2 Chapter 2 Motherboard information Before you proceed ..............2-1 Motherboard layout ..............2-2 Screw size ..................2-4 2.3.1 Component side .............. 2-4 2.3.2 Solder side ..............2-5 Central Processing Unit (CPU) ...........
  • Page 4 3.3.6 SIO Configuration ............3-6 3.3.7 NCT6791D HW Monitor ..........3-8 3.3.8 USB Configuration ............3-13 3.3.9 Digital IO Port Configuration ......... 3-13 3.3.10 Power Management ............3-13 Chipset menu ................3-15 3.4.1 System Agent (SA) Configuration ......... 3-15 PCH-IO Configuration ..............3-15 Security menu ................3-16 3.5.1 Administrator Password ..........3-16 3.5.2 User Password ..............

  • Page 5: Chapter 1 Product Overview

    Chapter 1 Product overview Package contents Check your industrial motherboard package for the following items. 1 x Industrial Motherboard 1 x SATA 6.0 Gb/s cable (2 in 1 pack) 1 x I/O Shield 1 x Support DVD 1 x COM port cable If any of the above items is damaged or missing, contact your distributor or sales representative immediately.

  • Page 6: Specifications

    1 x 8-pin (2x4) ATX 12V Power connector Form factor Micro-ATX Form Factor, 9.6”x9.6” (244mmx244mm) Gross weight 1.76 lb (0.8 Kg) Operating F~140 F (0 C~60 temperature Storage temperature F~185 F (-40 C~85 Operating humidity 0%~90% relative humidity, non-condensing Certificate CE/FCC (continued on the next page) IMBM-H110A...
  • Page 7 DISPLAY Chipset Intel Graphics Media Accelerator, VGA support via RTD2168 ® Up to 1920 x 1200 @60Hz (via RTD2168) for VGA Resolution Up to 1920 x 1200 @60Hz for DVI-D Up to 4096 x 2304 @24Hz for HDMI Output interface VGA + DVI-D + 2 * HDMI 5 x SATA III (6.0Gb/s) ports (1 port via ASM1061;...
  • Page 8 IMBM-H110A...

  • Page 9: Chapter 2 Motherboard Information

    Chapter 2 Motherboard information Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. CAUTION! • Unplug the power cord from the wall socket before touching any component. • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity. • Hold components by the edges to avoid touching the ICs on them. • Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component.

  • Page 10: Motherboard Layout

    Place this side 1442K towards the rear LGA1151 of the chassis 2168 LAN1_USB3_12 CHA_FAN1 LAN_USB3_34 Intel I211AT M2_HOLD_42 AUDIO1 PCIEX16_1 BUZZER1 Intel I211AT IMBM-H110A LED_5VSB LED_5V PCIEX1_2 Intel ® 128Mb Super BIOS H110 SPI_1 1083 PCIEX1_1 SATA6G_1 SATA6G_2 SATA6G_3 PCI1...
  • Page 11 Connectors/Jumpers/LEDs Page COM1 RS422/RS485 terminator (2-pin J1/J2/J3/J4) 2-15 ATX power connectors (24-pin EATXPWR1, 8-pin EATX_PWR2) 2-19 COM1 Ring/+5V/+12V selection (COM1_V1) 2-14 CPU and system fan connectors (4-pin CPU_FAN1, 4-pin CHA_FAN1~2) 2-20 Intel LGA1151 CPU socket ® M.2 M-key 2242 socket 2-22 DIMM memory slots 2-11 Serial port connectors (10-1 pin COM2~6) 2-22 Standby power LEDs (LED_5V, LED_5VSB) 2-16 10. BIOS programmable connector (8-pin SPI_1) 2-19 11. Chassis intrusion connector (4-1 pin CHASSIS) 2-14 12. Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1~5) 2-23 13. System panel connector (10-pin F_PANEL) 2-21 14. USB 2.0 connector (10-1 pin USB56, USB78 and USB910) 2-23 15. Clear RTC RAM (CLRTC) 2-13 16. AT/ATX mode jumper (3-pin ATMODE) 2-15 17.

  • Page 12: Screw Size

    218.97 211.06 201.95 199.24 194.04 178.44 179.94 177.67 173.23 163.20 149.23 147.07 140.97 138.81 126.81 127.13 126.24 103.38 86.87 72.01 77.85 68.15 59.94 45.45 44.58 43.75 40.77 41.28 38.10 33.30 18.74 16.68 10.75 8.50 10.49 7.36 7.14 0.00 35.02 IMBM-H110A...

  • Page 13: Solder Side

    2.3.2 Solder side 243.84 237.49 237.49 165.10 165.10 164.31 144.81 126.81 108.81 89.31 33.02 10.16 0.00 Chapter 2: Motherboard information...

  • Page 14: Central Processing Unit (Cpu)

    Central Processing Unit (CPU) The motherboard comes with a surface mount LGA1151 socket designed for the Intel® 7th/ 6th Generation(Kaby Lake-S/ Skylake-S) Core™ i7 / Core™ i5 / Core™ i3, Pentium® and Celeron® 14nm processors. IMBM-H110A IMBM-H110A CPU socket LGA1151 IMPORTANT: Unplug all power cables before installing the CPU. CAUTION! • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. The manufacturer will shoulder the cost of repair only if the damage is shipment/transit-related. • Keep the cap after installing the motherboard. The manufacturer will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1151 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/ incorrect removal of the PnP cap. IMBM-H110A...

  • Page 15: Installing The Cpu

    2.4.1 Installing the CPU CAUTION! Ensure that you install the correct CPU designed for LGA 1151 only. DO NOT install a CPU designed for LGA1155 and LGA1156 sockets on the LGA1151 socket. Chapter 2: Motherboard information...
  • Page 16 IMBM-H110A...

  • Page 17: Cpu Heatsink And Fan Assembly Installation

    2.4.2 CPU heatsink and fan assembly installation CAUTION! Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary. To install the CPU heatsink and fan assembly Chapter 2: Motherboard information...
  • Page 18 To uninstall the CPU heatsink and fan assembly IMBM-H110A 2-10...

  • Page 19: System Memory

    System memory This motherboard comes with two Double Data Rate 4 (DDR4) Dual Inline Memory Module (DIMM) sockets. A DDR4 module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot. According to Intel CPU spec, DIMM voltage below 1.2 V is recommended to protect the ® CPU. IMBM-H110A IMBM-H110A 288-pin DDR4 DIMM sockets Chapter 2: Motherboard information 2-11...

  • Page 20: Installing A Dimm

    2.5.1 Installing a DIMM To remove a DIMM IMBM-H110A 2-12...

  • Page 21: Jumpers

    Clear RTC RAM (CLRTC) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords. CLRTC IMBM-H110A Normal Clear RTC (Default) IMBM-H110A Clear RTC RAM To erase the RTC RAM: 1. Turn OFF the computer and unplug the power cord. 2. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3 for about 5~10 seconds, then move the cap back to pins 1-2. 3. Plug the power cord and turn ON the computer. 4. Hold down the <Del> key during the boot process and enter BIOS setup to reenter data. CAUTION! Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default position. Removing the cap will cause system boot failure! NOTES: •...
  • Page 22 This connector is for a chassis-mounted intrusion detection sensor or switch. Connect one end of the chassis intrusion sensor or switch cable to this connector. The chassis intrusion sensor or switch sends a high-level signal to this connector when a chassis component is removed or replaced. The signal is then generated as a chassis intrusion event. By default, the pin labeled “Chassis Signal” and “Ground” are shorted with a jumper cap. Remove the jumper caps only when you intend to use the chassis intrusion detection feature. CHASSIS1 IMBM-H110A IMBM-H110A Chassis intrusion connector COM1 Ring/+5V/+12V selector (6-pin COM1_V1) COM1_V1 +12V Ring (Default) IMBM-H110A IMBM-H110A COM1 Ring/+5V/+12V Selection Setting Pins...
  • Page 23 Terminator (J1 J2 J3 J4) AT Mode selection (2-pin ATMODE) AT_ATX IMBM-H110A ATX mode AT mode (Default) IMBM-H110A H/W AT/ATX mode selection Pins 1-2 (Default) ATX mode AT mode NOTE: Jumper setting of AT_ATX should be consistent with the setting of AT/ATX Power Type in BIOS. Refer to section 3.3.10 Power Management in Chapter 3.

  • Page 24: Onboard Leds

    Onboard LEDs Standby Power LED The motherboard comes with two standby power LEDs that light up to indicate that the system is ON, in sleep mode or in soft-off mode. This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LEDs. LED_5VSB LED_5V IMBM-H110A Main Power Off Standby Power Powered Off Main Power IMBM-H110A Onboard LEDs IMBM-H110A 2-16...

  • Page 25: Connectors

    Connectors 2.8.1 Rear panel connectors PS/2 Mouse port (green). This port is for a PS/2 mouse. Serial ports (COM1). These ports connect a modem, or other devices that conform with serial specification. Int. Serial Port Connector for Int. Serial Port Connector for ( COM1 / RS485 ) ( COM1 / RS422 ) RS422 RX (B) RS422 RX(A) RS422 TX (A) RS485 D+ (A) RS485 D- (B) RS422 TX(B)
  • Page 26 Microphone port (pink). This port connects a microphone. USB 3.0 ports (USB3). These 9-pin Universal Serial Bus (USB) ports connect to USB 3.0/2.0 devices. NOTES: • The XHCI (USB3.0) controller is not natively supported under Windows® 7 OS. Use a P/S2 or SATA device during OS installation. • Due to USB 3.0 controller limitations, USB 3.0 devices can only be used under a Windows OS environment and after USB 3.0 driver installation. ® • USB 3.0 devices can only be used for data storage. • We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster and better performance for your USB 3.0 devices. DVI-D port. This port is for any DVI-D compatible device. DVI-D can’t be converted to output RGB Signal to CRT and is not compatible with DVI-I. HDMI port. This port is for a High-Definition Multimedia Interface (HDMI) connector, and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected content 11. PS/2 Keyboard port (purple). This port is for a PS/2 keyboard. IMBM-H110A 2-18...

  • Page 27: Internal Connectors

    -5 Volts Power OK PIN 1 +5 Volts +5 Volts PSON# IMBM-H110A +3 Volts -12 Volts +3 Volts +3 Volts PIN 1 IMBM-H110A ATX power connectors IMPORTANT: • For a fully configured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12 V Specification 2.0 (or later version) and provides a minimum power of 330W. • We recommend that you use a PSU with higher power output when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. BIOS programmable connector (8-pin SPI) Use this connector to flash the BIOS ROM.
  • Page 28 IMBM-H110A Fan connectors CAUTION: Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! Do not place jumper caps on the fan connectors! NOTE: The CPU_FAN connector supports a CPU fan of maximum 12V/2A fan rating. Digital I/O connector (10-pin DIO1) This connector includes 8 I/O lines (In/Out programmable). All of the Digital I/O lines are programmable and each I/O pin can be individually programmed to support various devices. DIO1 IMBM-H110A PIN 1 IMBM-H110A Digitial I/O connector IMBM-H110A 2-20...
  • Page 29 System panel connector (10-pin F_PANEL1) This connector supports several chassis-mounted functions. F_PANEL1 +PWR LED PWR BTN PIN 1 IMBM-H110A +HDD_LED RESET IMBM-H110A Front panel connector • System power LED (2-pin PWR_LED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. • Hard disk drive activity LED (2-pin HDD_LED) This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable to this connector. The HDD LED lights up or flashes when data is read from or written to the HDD. • ATX power button/soft-off button (2-pin PWR_BTN) This 2-pin connector is for the system power button.
  • Page 30 COM3 PIN 1 COM4 COM2 PIN 1 PIN 1 COM5 PIN 1 COM6 IMBM-H110A PIN 1 IMBM-H110A Serial port (COM) connectors NOTE: The COM module is purchased separately. M.2 M-key 2242 socket This socket allows you to install an M.2 (NGFF) SSD module. M2_M M2_HOLD_42 IMBM-H110A IMBM-H110A M.2 (M-key socket) IMBM-H110A 2-22...
  • Page 31 USB 2.0 connector (10-pin USB56, USB78, USB910) This USB connectors complies with USB 2.0 specifications. USB2_56~910 PIN 1 IMBM-H110A IMBM-H110A USB2.0 connectors Never connect a 1394 cable to the USB connector. Doing so will damage the motherboard. 10. Serial ATA 6.0Gb/s connector (7-pin SATA6G_1~5) These connectors connect to Serial ATA 6.0 Gb/s hard disk drives via Serial ATA 6.0 Gb/s signal cables. SATA6G_1 SATA6G_2 SATA6G_3 SATA6G_4 SATA6G_5 IMBM-H110A IMBM-H110A Intel SATA 6 Gb/s connectors ® NOTES: •...
  • Page 32 11. Audio amplfier connector (4-pin AMP_CON)  This connector is for an internal stereo amplifier speakers support (2W/4 via WtoB header). AMP_CON PIN 1 IMBM-H110A IMBM-H110A Audio Stere. Output with Amp connector IMBM-H110A 2-24...

  • Page 33: Chapter 3 Bios Setup

    Chapter 3 BIOS setup BIOS setup program Use the BIOS Setup program to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief online help to guide you in using the BIOS Setup program. Entering BIOS Setup at startup To enter BIOS Setup at startup: Press <Delete>...

  • Page 34: Bios Menu Screen

    The Main menu provides you an overview of the basic system information, and allows you to set the system date, time, language, and security settings. 3.2.1 System Date [Day MM/DD/YYYY] Allows you to set the system date. 3.2.2 System Time [HH:MM:SS] Allows you to set the system time. IMBM-H110A...

  • Page 35: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. Case Open Warning [Disabled] Allows you to enable or disable the case open detecting function.
  • Page 36 Selects to tell operating system to support PPI S pec Version 1.2 or 1.3. Some HCK tests might not support 1.3. Configuration options: [1.2] [1.3] Device Select [Auto] Allows you to select the TPM device. Configuration options: [Auto] [TPM1.2] [TPM2.0] IMBM-H110A...

  • Page 37: Sata Configuration

    3.3.3 SATA Configuration The BIOS automatically detects the presence of SATA devices. The Serial ATA Ports listed will display Empty if there are no Serial devices connected to the ports. SATA Controller(s) [Enabled] Configuration options: [Enabled] [Disabled]. The following items appear only when you set SATA Controller(s) to [Enabled]. SATA Mode Selection [AHCI] Allows you to set the SATA configuration.

  • Page 38: Pch-Fw Configuration

    Mode [RS-232] Allows you to select the Serial Port mode. Configuration options: [RS-232] [RS-422] [RS-485 (Receiver Half Duplex)] [*Active*] Serial Port 2 Use this device [Enabled] Allows you to enable or disable this logical device. Configuration options: [Enabled] [Disabled] IMBM-H110A...
  • Page 39 Possible [Use Automatic Settings] This item appears only when you set Use this device to [Enabled] and allows you to select an optimal setting for Super I/O devices. Configuration options: [Use Automatic Settings] [IO=2F8h; IRQ=3] [IO=3F8h; IRQ=4;] [*Active*] Serial Port 3 Use this device [Enabled] Allows you to enable or disable this logical device.

  • Page 40: Nct6791D Hw Monitor

    Tolerance of Temperature [0] Input value range: [0~7] Fan Out Start-Up Value [127] Input value range: [0~255] Fan Stop Duty [To Fan Out Stop Value] Selects fan stop duty mode. Configuration options: [Down to 0] [To Fan Out Stop Value] IMBM-H110A...
  • Page 41 Fan Out Stop Value [100] The Fan Out value decreases to this value if the temperature reaches below the lowest temperature limit. Input value range: [0~255] Fan Out Stop Time [60] Determines the amount of time it takes for the Fan Out value to fall from the stop value to zero.
  • Page 42 [Enabled]. Fan Control Mode [SMART FAN IV Mode ] Configuration options: [Manual Mode] [Thermal Cruise Mode] [Speed Cruise Mode] [SMART FAN IV Mode] The following items appear only when you set Fan Control Mode to [Manual Mode]. IMBM-H110A 3-10...
  • Page 43 PWM/DC Voltage Output [255] This item appears only when you set the previous item to [Manual Mode] and allows you to set the voltage allocated for Fan Control. Input value range: [0~255] The following items appear only when you set Fan Control Mode to [Thermal Cruise Mode].
  • Page 44 Tolerance of Temperature [0] Input value range: [0~7] Critical Temperature [75] Input value range: [0~255] Critical Temp Tolerance [0] Input value range: [0~7] Fan Count Step Up [5] Input value range: [0~15] Fan Count Step Down [5] Input value range: [0~15] IMBM-H110A 3-12...

  • Page 45: Usb Configuration

    Fan Out Step Up Time [10] Determines the amount of time Fan Out takes to increase its value by one step. Input value range: [0~255] Fan Out Step Down Time [10] Determines the amount of time Fan Out takes to decrease its value by one step in intervals of 0.1 seconds.
  • Page 46 Specify the values for day/hour/minute/second. The following item appears when Wake System with Dynamic Time is enabled. Wake up minute increase [1] Specify the number of minutes added to the current time before waking up system. Input value range: [1~5] IMBM-H110A 3-14...

  • Page 47: Chipset Menu

    Chipset menu The Chipset menu items allow you to change the settings for the chipset. 3.4.1 System Agent (SA) Configuration Max TOLUD [Dynamic] Configures the maximum value of TOLUD. Dynamic assignment will adjust TOLUD automatically based on the largest MMIO length of installed graphics controller. Configuration options: [Dynamic] [1GB] [1.25GB] ~ [3.5GB] Graphics Configuration Primary Display [Auto]...

  • Page 48: Security Menu

    Installed. After you set a password, this item shows Installed. To set a user password: Select the User Password item and press <Enter>. From the Create New Password box, key in a password, then press <Enter>. Confirm the password when prompted. IMBM-H110A 3-16...

  • Page 49: Boot Menu

    To change a user password: Select the User Password item and press <Enter>. From the Enter Current Password box, key in the current password, then press <Enter>. From the Create New Password box, key in a new password, then press <Enter>.

  • Page 50: Save & Exit Menu

    This option allows you to exit the Setup program without saving your changes. When you select this option or if you press <Esc>, a confirmation window appears. Select Yes to discard changes and exit. Restore Defaults This option allows you to restore/load default values for all setup options. IMBM-H110A 3-18...

  • Page 51: Appendix

    Check local regulations for disposal of electronic products. DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste. IMBM-H110A...
  • Page 52 印 刷 電 路 板 及 其 × ○ ○ ○ ○ ○ 電子組件 外 部 信 號 連 接 頭 × ○ ○ ○ ○ ○ 及線材 ○： 表示該有毒有害物質在該部件所有均質材料中的含量均在 SJ/T 11363- 2006 標准規定的限量要求以下。 ×： 表示該有毒有害物質至少在該部件的某一均質材料中的含量超出 SJ/T 11363-2006 標准規定的限量要求，然該部件仍符合歐盟指令 2002/95/ EC 的規范。 備註：此產品所標示之環保使用期限，係指在一般正常使用狀況下。 IMBM-H110A...
