  • Page 1 IMBA-H61A...
  • Page 2 E7929 First Edition February 2013 Copyright Notice This document is copyrighted, 2013. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer.

  • Page 3: Table Of Contents

    Contents Chapter 1 Product overview Package contents ................. 1-1 Features ..................1-1 1.3 Specifications ................1-2 Chapter 2 Motherboard information Before you proceed ..............2-1 Motherboard layout ..............2-2 Screw size ..................2-4 2.3.1 Component side .............. 2-4 2.3.2 Solder side ..............2-5 Central Processing Unit (CPU) ...........
  • Page 4 Contents Advanced menu ................3-6 3.4.1 Trusted Computing ............3-6 3.4.2 CPU Configuration ............3-7 3.4.3 PCH Configuration ............3-8 3.4.4 SATA Configuration ............3-8 3.4.5 System Agent Configuration ........... 3-9 3.4.6 USB Configuration ............3-10 3.4.7 SIO GPIO ..............3-10 3.4.8 Onboard Devices Configuration ........3-11 3.4.9 APM ................3-11 3.4.10 Network Stack ...............

  • Page 5: Product Overview

    Chapter 1 Product overview Package contents Check your industrial motherboard package for the following items. 1 x Industrial Motherboard 2 x Serial ATA 3.0Gb/s cables 1 x I/O Shield 1 x Support DVD (Drivers and manual) 1 x COM Port cable If any of the above items is damaged or missing, contact your distributor or sales representative immediately.

  • Page 6: Specifications

    1.45 lb (0.66 Kg) Operating F~140 F (0 C~60 temperature Storage temperature F~176 F (-40 C~80 Operating humidity 0%~90% relative humidity, non-condensing Power compliance Compliant with Eup/ErP AT/ATX power mode support CE (include CE-LVD), FCC (continued on the next page) IMBA-H61A...
  • Page 7 DISPLAY Chipset Intel Graphics Media Accelerator ® Resolution Up to 1920x1200@60Hz for VGA Up to 1920x1200@60Hz for DVI Output interface 1 x VGA port 1 x DVI port Storage 4 x SATA 3.0Gb/s ports Serial port 1 x RS232 DB-9 connector (COM1) 1 x RS232/422/485 on rear I/O (COM2) 4 x RS232 box header (COM3~COM6) 9 x USB2.0 ports (5 ports at mid-board, 4 ports at rear panel)
  • Page 8 IMBA-H61A...

  • Page 9: Motherboard Information

    The illustration below shows the location of the onboard LED. SB_PWR1 Standby Power Standby Power Off SB_PWR2 Main Power Main Power Off IMBA-H61A Onboard LED Chapter 2: Motherboard information...

  • Page 10: Motherboard Layout

    8111F LAN1_USB12 8111F CPU_FAN1 AUDIO PCIEX16_1 PCIEX1_1 Intel ® PCIEX1_1 1083 PCI1 Lithium Cell CMOS Power PCI2 CLRTC1 SB_PWR1 Super CHASSIS1 PCI3 SB_PWR2 DRCT1 ATMODE PCI4 DIO1 CHA_FAN2 SATA3G_1 SATA3G_2 SATA3G_3 SATA3G_4 USB89 USB45 LPT1 TPM1 USB10 F_PANEL1 IMBA-H61A...
  • Page 11 Connectors/Jumpers/Slots Page Serial port connectors (10-1 pin COMBH2, COM3~6) COM2_V1 Ring/+5V/+12V selection (6-pin) CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN) ATX power connectors (24-pin EATXPWR, 4-pin EATX12V) Intel LGA1155 CPU socket ® DDR3 DIMM slots Standby Power LEDs (SB_PWR1/2) Clear RTC RAM (3-pin CLRTC) Chassis intrusion connector (4-1 pin CHASSIS1) 10.

  • Page 12: Screw Size

    Screw size 2.3.1 Component side IMBA-H61A...

  • Page 13: Solder Side

    2.3.2 Solder side Chapter 2: Motherboard information...

  • Page 14: Central Processing Unit (Cpu)

    ® ® ® processors. IMBA-H61A CPU socket LGA1155 Unplug all power cables before installing the CPU. • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components.

  • Page 15: Installing The Cpu

    2.4.1 Installing the CPU The LGA1156 CPU is incompatible with the LGA1155 socket. DO NOT install a LGA1156 CPU on the LGA1155 socket. Chapter 2: Motherboard information...
  • Page 16 IMBA-H61A...

  • Page 17: Cpu Heatsink And Fan Assembly Installation

    2.4.2 CPU heatsink and fan assembly installation Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary. To install the CPU heatsink and fan assembly Chapter 2: Motherboard information...
  • Page 18 To uninstall the CPU heatsink and fan assembly IMBA-H61A 2-10...

  • Page 19: System Memory

    System memory Installing a DIMM To remove a DIMM Chapter 2: Motherboard information 2-11...

  • Page 20: Jumpers

    You do not need to clear the RTC when the system hangs due to overclocking. For system failure due to overclocking, use the CPU Parameter Recall (C.P.R) feature. Shut down and reboot the system so the BIOS can automatically reset parameter settings to default values. IMBA-H61A 2-12...
  • Page 21 COM2_V Ring/+5V/+12V selection (6-pin) Ring +12V (Default) IMBM-H61A COM2_V1 Ring/+5V/+12V Selection Setting Pins +12V Ring (Default) AT Mode selection (3-pin) ATMODE IMBA-H61A ATMODE setting Setting Pins AT mode ATX mode (Default) Chapter 2: Motherboard information 2-13...

  • Page 22: Connectors

    LED indications. LAN port LED indications Speed Activity ACT/LINK LED SPEED LED Link LED Status Description Status Description No link 10 Mbps connection ORANGE Linked ORANGE 100 Mbps connection BLINKING Data activity GREEN 1 Gbps connection LAN port IMBA-H61A 2-14...
  • Page 23 Line In port (light blue). This port connects to the tape, CD, DVD player, or other audio sources. Line Out port (lime). This port connects to a headphone or a speaker. In the 4, 6, and 8-channel configurations, the function of this port becomes Front Speaker Out. Microphone port (pink). This port connects to a microphone. To configure an 8-channel audio output: Use a chassis with HD audio module in the front panel to support an 8-channel audio output.

  • Page 24: Internal Connectors

    DO NOT forget to connect the 4-pin ATX +12V power plug. Otherwise, the system will not boot up. • We recommend that you use a PSU with higher power output when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. IMBA-H61A 2-16...
  • Page 25 LPT connector (26-1 pin LPT) The LPT (Line Printing Terminal) connector supports devices such as a printer. LPT is standardized as IEEE 1284, which is the parallel port interface on IBM PC-compatible computers. LPT1 IMBA-H61A Parallel Port Connector Chapter 2: Motherboard information 2-17...
  • Page 26 PWR BTN PIN 1 +HD_LED RESET IMBA-H61A System panel connector • System power LED (2-pin PLED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode.
  • Page 27 TPM connector (20-1 pin TPM1) This connector supports a Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. TPM1 PIN 1 IMBA-H61A TPM Connector Chapter 2: Motherboard information 2-19...
  • Page 28 USB45 PIN 1 PIN 1 PIN 1 IMBA-H61A Front USB 2.0 Header connectors Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB module cable is purchased separately. Chassis intrusion connector (4-1 pin CHASSIS1) This connector is for a chassis-mounted intrusion detection sensor or switch.
  • Page 29 10. Digital I/O connector (10-pin DIO1) This connector includes 8 I/O lines. All of the Digital I/O lines are programmable and each I/O pin can be individually programmed to support various devices. DIO1 PIN 1 IMBA-H61A DIO connector Chapter 2: Motherboard information 2-21...
  • Page 30 Direct connector (2-pin DRCT) This connector is for the chassis-mounted button that supports the DirectKey function. Connect the button cable that supports DirectKey from the chassis to this connector on the motherboard. DRCT1 PIN 1 IMBA-H61A DRCT connector IMBA-H61A 2-22...

  • Page 31: Bios Setup

    Chapter 3 BIOS setup BIOS setup program Use the BIOS Setup program to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief online help to guide you in using the BIOS Setup program. Entering BIOS Setup at startup To enter BIOS Setup at startup: • Press <Delete> during the Power-On Self Test (POST). If you do not press <Delete>, POST continues with its routines.

  • Page 32: Bios Menu Screen

    Navigation keys Menu bar The menu bar on top of the screen has the following main items: Main For changing the basic system configuration. Advanced For changing the advanced system settings. Boot For changing the system boot configuration. Tool For configuring options for special functions. Exit For selecting the exit options and loading default settings. IMBA-H61A...
  • Page 33 Menu items The highlighted item on the menu bar displays the specific items for that menu. For example, selecting Main shows the Main menu items. The other items (Ai Tweaker, Advanced, Monitor, Boot, Tool, and Exit) on the menu bar have their respective menu items. Back button This button appears when entering a submenu. Press <Esc> or use the USB mouse to click this button to return to the previous menu screen.

  • Page 34: Main Menu

    Clock (RTC) RAM to clear the BIOS password. See section 2.6 Jumpers for information on how to erase the RTC RAM. The Administrator or User Password items on top of the screen show • the default Not Installed. After you set a password, these items show Installed. IMBA-H61A...
  • Page 35 Administrator Password If you have set an administrator password, we recommend that you enter the administrator password for accessing the system. Otherwise, you might be able to see or change only selected fields in the BIOS setup program. To set an administrator password: Select the Administrator Password item and press <Enter>. From the Create New Password box, key in a password, then press <Enter>.

  • Page 36: Advanced Menu

    Be cautious when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. 3.4.1 Trusted Computing This item appears only when a TPM module is connected to the motherboard and allows you to change TPM settings. TPM Support [Disabled] Allows you to enable or disable TPM support. Configuration options: [Disabled] [Enabled] IMBA-H61A...

  • Page 37: Cpu Configuration

    3.4.2 CPU Configuration The items in this menu show the CPU-related information that the BIOS automatically detects. The items shown in submenu may be different due to the CPU you installed. Intel Adaptive Thermal Monitor [Enabled] ® [Enabled] Enables the overheated CPU to throttle its clock speed to cool down.

  • Page 38: Pch Configuration

    Set to [AHCI] when you want the SATA hard disk drives to use the AHCI (Advanced Host Controller Interface). The AHCI allows the onboard storage driver to enable advanced Serial ATA features that increases storage performance on random workloads by allowing the drive to internally optimize the order of commands. IMBA-H61A...

  • Page 39: System Agent Configuration

    S.M.A.R.T. Status Check [Enabled] S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitor system. When read/write of your hard disk errors occur, this feature allows the hard disk to report warning messages during the POST. Configuration options: [Enabled] [Disabled] Hot Plug [Disabled] This item only appears when you set the SATA Mode Selection item to [AHCI] and allows you to enable or disable the hot-plug support for each SATA port.

  • Page 40: Usb Configuration

    USB device is detected, the legacy USB support is disabled. EHCI Hand-off [Disabled] [Enabled] Enables the support for operating systems without an EHCI hand-off feature. [Disabled] Disables the function. 3.4.7 SIO GPIO GPIO 1~8 [Input] Allows you to configure the digital signal of the GPIO (General Purpose Input/ Output) pins 1~8. Configuration options: [Input] [Output High] [Output Low] IMBA-H61A 3-10...

  • Page 41: Onboard Devices Configuration

    3.4.8 Onboard Devices Configuration HD Audio Controller [Enabled] [Enabled] Enables the High Definition Audio Controller. [Disabled] Disables the controller. Realtek LAN1 Controller [Enabled] [Enabled] Enables the Realtek LAN controller 1. [Disabled] Disables the controller. Realtek LAN1 PXE OPROM [Disabled] This item appears only when you set the Realtek LAN1 Controller item to [Enabled] and allows you to enable or disable the PXE OptionRom of the Realtek LAN controller 1. Configuration options: [Enabled] [Disabled] Realtek LAN2 Controller [Enabled]...

  • Page 42: Network Stack

    This item appears only when you set the Network Stack item to [Enabled]. When this item is disabled, the IPV4 PXE boot option will not be created. Configuration options: [Disabled] [Enabled] Ipv6 PXE Support [Enabled] This item appears only when you set the Network Stack item to [Enabled]. When this item is disabled, the IPV6 PXE boot option will not be created. Configuration options: [Disabled] [Enabled] IMBA-H61A 3-12...

  • Page 43: Monitor Menu

    Monitor menu The Monitor menu displays the system temperature/power status, and allows you to change the fan settings. 3.5.1 CPU Temperature / MB Temperature [xxxºC/xxxºF] The onboard hardware monitor automatically detects and displays the CPU and motherboard temperatures. Select Ignore if you do not wish to display the detected temperatures.

  • Page 44: Cpu Q-Fan Control [Enabled]

    Sets to [Turbo] to achieve maximum chassis fan speed. 3.5.5 CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage The onboard hardware monitor automatically detects the voltage output through the onboard voltage regulators. Select Ignore if you do not want to detect this item. IMBA-H61A 3-14...

  • Page 45: Boot Menu

    Boot menu The Boot menu items allow you to change the system boot options. 3.6.1 Full Screen Logo [Enabled] [Enabled] Enables the full screen logo display feature. [Disabled] Disables the full screen logo display feature. Post Report [5 sec] This item appears only when the Full Screen Logo item is set to [Disabled] and allows you to set the waiting time for the system to display the post report.

  • Page 46: Wait For 'F1' If Error [Disabled]

    Disable the CSM to fully support the Windows Security Update and Security Boot. The following four items appear only when you set Launch CSM to [Enabled]. Boot Device Control [UEFI and Legacy OpRom] Configuration option: [UEFI and Legacy OpRom] [Legacy OpRom only] [UEFI only] Boot from Network Devices [Legacy OpRom first] Configuration option: [Legacy OpRom first] [UEFI driver first] [Ignore] Boot from Storage Devices [Legacy OpRom first] Configuration option: [Both, Legacy OpRom first] [Both, UEFI first] [Legacy OpRom first] [UEFI driver first] [Ignore] Boot from PCIe/PCI Expansion Devices [Legacy OpRom first] Configuration option: [Legacy OpRom first] [UEFI driver first] IMBA-H61A 3-16...

  • Page 47: Boot Option Priorities

    3.6.7 Boot Option Priorities These items specify the boot device priority sequence from the available devices. The number of device items that appears on the screen depends on the number of devices installed in the system. • To select boot device during system startup, press <F8> after the first screen appears. •...

  • Page 48: Exit Menu

    When you select this option or if you press <F10>, a confirmation window appears. Select Yes to save changes and exit. Discard Changes & Exit This option allows you to exit the Setup program without saving your changes. When you select this option or if you press <Esc>, a confirmation window appears. Select Yes to discard changes and exit. Launch EFI Shell from filesystem device This option allows you to attempt to launch the EFI Shell application (shellx64.efi) from one of the available devices that have a filesystem. IMBA-H61A 3-18...

  • Page 49: Appendix

    Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. IMBA-H61A...
  • Page 50 ○： 表 示 該 有 毒 有 害 物 質 在 該 部 件 所 有 均 質 材 料 中 的 含 量 均 在  S J / T 11363-2006標准規定的限量要求以下。 ×： 表 示該有毒有害物質至少在該部件的某一均質材料中的含量超出 S J/T 11363-2006標准規定的限量要求，然該部件仍符合歐盟指令2002/95/ EC的規范。 備註：此產品所標示之環保使用期限，係指在一般正常使用狀況下。 IMBA-H61A...
