5000-080 – 5" EXTENSION KIT
INSTALLATION INSTRUCTION
PART IDENTIFICATION
2565-961_REV_B – 08/2020
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Yetter 5000-080
Summary of Contents for Yetter 5000-080
- Page 1 STALK DEVASTATOR ACCESSORIES 5000-080 – 5” EXTENSION KIT 5000-081 – JD HEAD EXTENSION KIT (2012-NEWER) 5000-082 – DEVASTATOR LIFT KIT 5000-083 – DEVASTATOR LOCK UP KIT (6 ROW) 5000-084 – DEVASTATOR LOCK UP KIT ( 8/12 ROW) INSTALLATION INSTRUCTION PART IDENTIFICATION 2565-961_REV_B –...
-
Page 2: Table Of Contents
E-mail: info@yetterco.com WARRANTY Yetter Manufacturing warrants all products manufactured & sold by it against defects in material. This warranty being expressly limited to replacement at the factory of such parts or products as shall appear to be defective after inspection. This warranty does not obligate the Company to bear cost of labor in replacement of parts. It is the policy of the Company to make improvements without incurring obligations to add them to any unit already sold. -
Page 3: Safety
BE ALERT! YOUR SAFETY IS INVOLVED WATCH FOR THIS SYMBOL. IT POINTS OUT IMPORTANT SAFETY PRECAUTIONS. IT MEANS “ATTENTION – BE ALERT!” It is your responsibility as an owner, operator, or supervision to know and instruct everyone using this machine at the time of initial assignment and at least annually thereafter, of the proper operation, precautions, and work hazards which exist in the operation of the machine in accordance with OSHA regulations. - Page 4 PLEASE READ, VERY IMPORTANT SECURE CORN HEADER AGAINST UNWANTED LOWERING BY APPLYING THE LOCKING MECHANISM ON THE HYDRAULIC CYLINDERS! 1. Attach head to combine, lock head to combine 2. Raise the head off the ground and engage safety stop on the feeder house cylinder. 3.
- Page 5 PLEASE READ, VERY IMPORTANT Subject to the size and weight of the corn header, one or two additional hydraulic cylinders may be required. The combine manufacturer generally keeps corresponding kits readily available for dealers. Subject to the design of the corn header and the carrying capacity of different combines, the steering axle may require the fitting of additional weights and the rear tires be filled with ballast.
-
Page 6: 5000-080 Assembly Instructions
*Tools Needed: Impact Wrench, ¾ Impact Socket, and ¾ Wrench **If adding the Extension Kit to an already installed Devastator, start at Step 1. ***If installing new Devastator & Extension Kit, start at Step 3. 5000-080 BOM (per kit ordered) TOOLS NEEDED IMPACT ¾... - Page 7 5000-080 INSTALLATION CONT’D Step 2: Unbolt the roller mount tube from the Devastator pivot arms. Step 3: Attach the Devastator extension plates to the existing pivot arms using the 2) 2502-363 ½”-13 X 4 ½” & 5000-394 shorter spacer through the front holes of the 5000-393 extension plate. Install the 2) 2502-365 ½”-13 X 3 ¾”...
- Page 8 5000-080 INSTALLATION CONT’D Step 4: Place the roller mount tube inside of the extension brackets similar to how the mount tube was originally installed into the Devastator pivot arm mount. Use the original bolts & bushings that were removed from the Devastator mount arms in Step 2.
-
Page 9: 5000-081 Assembly Instructions
5000-081 INSTALLATION NOTE: THE HEAD EXTENSION KIT IS ONLY COMPATIBLE WITH JD HEADS 2012-NEWER! STEP 1: Place the extension bracket up against the bottom plate of the header stand with the welded in pivot bushing on the back side of the stand. STEP 2: Install each mount plate over the pivot bushing. -
Page 10: 5000-082 Assembly Instructions
5000-082 INSTALLATION STEP 1: Remove the ¾” Lock nut from the pushrod to release the spring tension. Remove the shoulder bolt then rotate the pivot arm up so the lockup pin can be inserted. STEP 2: Install the 5000-409 Connector pin and (2) extender plates on the pushrod and secure the extender plates to the pivot arm with the shoulder bolt and lock nut. -
Page 11: 5000-084 Assembly Instructions
5000-083 (6 ROW) & 5000-084 (8/12 ROW) INSTALLATION NOTE: 5000-083 IS NOT COMPATIBLE WITH THE 5000-080 5” EXTENSION KIT STEP 1: On 6 row heads, install the clamp plate & lock plate on the 3” X 4” frame, centered on the head to fit between the roller mount tubes. -
Page 12: Part Identification
5000-080 PARTS IDENTIFICATION ITEM PART NUMBER DESCRIPTION QUANTITY ½ – 13 X 4 ½ HHCS GR 5 ZP 2502-363 2502-365 ½ - 13 x 3 ¾ HHCS GR 5 ZP 2520-357 ½ - 13 LOCK HEX NUT, GR A, ZP... - Page 13 5000-081 PARTS IDENTIFICATION ITEM PART # DESCRIPTION 2502-291 ½ - 13 X 7 ½ HHFS GR 8 ZP 2520-368 ½ - 13 HEX FLANGE NUT GR 3 ZP 2570-446 .125 HAIRPIN COTTER ZP 5000-265 EXTENSION BRACKET 5000-404 MOUNT PLATE 5000-407 L PIN 5000-082 PARTS IDENTIFICATION ITEM...
- Page 14 5000-083 & 5000-084 PARTS IDENTIFICATION 5000-083 5000-084 ITEM PART # DESCRIPTION ITEM PART # DESCRIPTION 2502-363 ½ - 13 X 4 ½ HHCS GR 5 ZP 2502-291 ½ - 13 X 4 ½ HHCS GR 5 ZP 2520-361 ½-13 FLANGE WHIZLOCK NUT GR 5 ZP 2520-368 ½-13 FLANGE WHIZLOCK NUT GR 5 ZP 5000-276...
-
Page 15: Photos
5000-080 5” Set Back Kit Photos 5000-081 JD Head Stand Extension Photo... - Page 16 5000-082 2” Lift Kit Photo 5000-083 & 5000-084 Photo...
-
Page 17: Operation
OPERATION CORN HEAD ANGLE NEEDS TO BE ADJUSTED BETWEEN 23 – 25° FOR OPTIMUM DEVASTATATOR PERFORMANCE. USE THE 5000-455 TO CHECK CORN HEAD ANGLE: - Put the combine on a level surface. Lower the Corn head to your normal working head height. - Place the magnetic protractor on the stripper plate to get the angle. -
Page 18: Storage/Transport
STORAGE/TRANSPORT - Head cart may need adjusted to fit the head with devastator correctly. E.g. raising or fore/aft adjustment of saddles/top rail on the head cart. - If head cart does not have these adjustments, adding a tube extension to top rail or adding extension to saddle/corn head may be required. - Side to side tilt may need used to clear taller head cart tires or locking the devastator up. - Page 19 NOTES...
- Page 20 2565-961_REV_B – 08/2020...
