Yetter 5000 Series Operator's Manual

Stalk devastator, corn stalk roller
Hide thumbs Also See for 5000 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
5000-029B, 5000-030B, 5000-032B, 5000-036, 5000-038
CASE IH 4400 6, 8, & 12 ROW MODELS, 30" NONCHOPPING
YETTER MANUFACTURING CO.
Founded 1930
Colchester, IL 62326
Toll Free: (800)447-5777
Fax: (309)776-3222
Website: yetterco.com
E-mail: info@yetterco.com
5000 SERIES
STALK DEVASTATOR
CORN STALK ROLLER
*PATENTED*
OPERATOR'S MANUAL
PART IDENTIFICATION
2565-792_Rev_E – 09/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yetter 5000 Series

Summary of Contents for Yetter 5000 Series

  • Page 1 5000 SERIES STALK DEVASTATOR CORN STALK ROLLER *PATENTED* 5000-029B, 5000-030B, 5000-032B, 5000-036, 5000-038 CASE IH 4400 6, 8, & 12 ROW MODELS, 30” NONCHOPPING OPERATOR’S MANUAL PART IDENTIFICATION 2565-792_Rev_E – 09/2020 YETTER MANUFACTURING CO. Founded 1930 Colchester, IL 62326 Toll Free: (800)447-5777 Fax: (309)776-3222 Website: yetterco.com...

  • Page 2: Table Of Contents

    Important will WARRANTY Yetter Manufacturing warrants all products manufactured and sold by it against defects in material. This warranty being expressly limited to replacement at the factory of such parts or products as shall appear to be defective after inspection.

  • Page 3: Operation Checklist / Safety Information

    DEVASTATOR OPERATION CHECKLIST Please fill this out after the Yetter Stalk Devastator has been installed. DATE____/____/____ YETTER KIT # - 5000-____ CORN HEAD MAKE/MODEL___________________ COMBINE MAKE/MODEL__________________ FRONT TIRE SIZE______________ REAR TIRE SIZE______________ REAR AXLE POSITION______________ SNAPPING ROLLS USING______________ CHOPPING BLADES YES / NO DECK PLATE ANGLE_____°...
  • Page 4 PLEASE READ, VERY IMPORTANT SECURE THE CORN HEADER AGAINST UNWANTED LOWERING BY APPLYING THE LOCKING MECHANISM ON HYDRAULIC CYLINDERS! 1. Attach head to combine, lock head to combine 2. Raise the head off the ground and engage safety stop on the feeder house cylinder 3.

  • Page 5: Bolt Torque / Tools Required

    BOLT TORQUE Important: Over tightening hardware can cause as much damage as when under tightening. Tightening hardware beyond the recommended range can reduce its shock load capacity. All hardware on the 5000 Devastator is either Grade 5 or Grade 8, unless otherwise noted. Grade 5 cap screws are marked with three radial lines on the head.

  • Page 6: Pictorial Part List / Bill Of Materials

    PICTORIAL PART LIST 5000-203B -48” 5000-211B -76” 5000-261 – Long 5000-260 5000-254 – 80” 5000-255- 52” 5000-256 (LH) 5000-259 (RH) 5000-263 5000-136 5000-138 OPTIONAL ONLY USED ON 4412 Rigid 5000-155 (L plate Hardware bag) 5000-152 5000-142 5000-355 2550-059 5000-080 BEFORE INSTALLATION BEGINS, PLEASE CHECK THAT ALL PARTS WERE RECEIVED BY GOING THROUGH THE CRATE AND SORTING THE PARTS!!! Bill of Materials: 5000-029B –...
  • Page 7 PICTORIAL PART LIST – 5000-136 Hardware Bag  2502-325 - 5/8-11 X 3 HHCS GR 5 ZP – QTY 1 2502-353 – ½-13 x 2 ½, HHCS, GR8, ZP – QTY 3   2510-121 - 5/8 DIA. SHLDR, 2-1/4 L SHLDR, ½-13 QTY 1 2520-357 - 1/2-13 LOCK HEX NUT, GR A, ZP –...

  • Page 8: Assembly Instructions

    ASSEMBLY INSTRUCTIONS On some models, the hydraulic cylinder for adjusting the deck plate or stripper plate will need to be relocated. Follow the steps below for relocating the cylinder. See the Devastator mount bracket locations on pages 9 – 10 that match the model of your corn head to see if this applies to you. Step 1: Remove the hyd.
  • Page 9 ASSEMBLY INSTRUCTIONS Step 1: Attach the 5000-260 mount brackets to the frame using 5/8” X 6 bolts, clamp straps, & 5/8” lock hex nuts. 4408 Folding corn heads will use 4) 5000-288 double mount brackets. Between rows 1-2 & 7-8, 5000-460 spacer blocks, 5/8” X 8” bolts will be used.
  • Page 10 ASSEMBLY INSTRUCTIONS 5000-038 – 4408 (2019 & NEWER) 5000-036 – 4408 FOLDING 5000-032B – 4412 RIGID 5000-032B – 4412 FOLDING...
  • Page 11 ASSEMBLY INSTRUCTIONS Step 2: Install the 5000-323 lock-up pin in the storage location on the mount brackets. Secure with the supplied hairpin clips. Step 3: Attach the pivot arms to the mount brackets using the 5/8 X 3 bolts, pivot bushings, & lock hex nuts. Fully tighten all hardware.
  • Page 12 ASSEMBLY INSTRUCTIONS Step 5: Attach the roller mount to the pivot arms using ½ X 3-3/4 bolts, spacers, & lock nuts. NOTE: Make sure the bearing support tabs are on the backside of the bearing mounting plate. Slide the roller mount side-to-side to clear the end of the corn head. DO NOT tighten hardware. On 4412 models, the roller mount that is longer in length is to be used between rows 4 –...
  • Page 13 ASSEMBLY INSTRUCTIONS Step 6: Install the shims & bearings onto the rollers. Attach the bearing/roller assembly to the roller mount using the ½ X 2 ½” bolts & lock nuts. Slide the roller mount side to side as need to center the traction bar on the row. 2 row & 3 row roller assemble the same, a 3 row roller is shown below.

  • Page 14: Operation / Storage / Transport / Maintenance / Lock Up

    OPERATION CORN HEAD ANGLE NEEDS TO BE ADJUSTED BETWEEN 22 – 25° FOR OPTIMUM DEVASTATATOR PERFORMANCE. USE THE 5000-455 TO CHECK CORN HEAD ANGLE: - Put the combine on a level surface. Lower corn head to your normal working head height. - Place the magnetic protractor on the stripper plate to get the angle.
  • Page 15 & use a pry bar to move back to position. Wobble the bearing around to help work the lubricant into the outer race of the bearing. LOCKING UP THE 5000 SERIES STALK DEVASTATOR...

  • Page 16: Part Identification

    5000-029B PART IDENTIFICATION - 4406 ITEM PART # DESCRIPTION QUANTITY 2502-325 5/8” – 11 X 3” HHCS GR 5 ZP 2502-352 5/8” – 11 X 6” HHCS GR 8 ZP 2502-353 ½” – 13 X 2 ½” HHCS GR 5 ZP 2502-365 ½”...

  • Page 17: 5000-030B

    5000-030B PART IDENTIFICATION – 4408 (2018 – OLDER) ITEM PART # DESCRIPTION QUANTITY 2502-325 5/8” – 11 X 3” HHCS GR 5 ZP 2502-352 5/8” – 11 X 6” HHCS GR 8 ZP 2502-353 ½” – 13 X 2 ½” HHCS GR 5 ZP 2502-365 ½”...

  • Page 18: 5000-032B

    5000-032B PART IDENTIFICATION 4412 FOLDING OR RIGID ITEM PART # DESCRIPTION QUANTITY 2502-325 5/8” – 11 X 3” HHCS GR 5 ZP 2502-352 5/8” – 11 X 6” HHCS GR 5 ZP 2502-353 ½” – 13 X 2 ½” HHCS GR 5 ZP 2502-365 ½”...
  • Page 19 5000-036 PART IDENTIFICATION 4408 FOLDING ITEM PART # DESCRIPTION QUANTITY 2502-325 5/8” – 11 X 3” HHCS GR 5 ZP 2502-342 5/8” – 11 X 8” HHCS GR 8 ZP 2502-353 ½” – 13 X 2 ½” HHCS GR 5 ZP 2502-365 ½”...
  • Page 20 5000-038 PART IDENTIFICATION 4408 (2019 – NEWER) ITEM PART # DESCRIPTION QUANTITY 2502-325 5/8” – 11 X 3” HHCS GR 5 ZP 2502-352 5/8” – 11 X 6” HHCS GR 8 ZP 2502-353 ½” – 13 X 2 ½” HHCS GR 5 ZP 2502-365 ½”...

  • Page 21: Misc. Part Id

    PART IDENTIFICATION...
  • Page 22 PARTS IDENTIFICATION...

  • Page 23: Troubleshooting

    TROUBLSHOOTING ISSUE CAUSE CORRECTIVE ACTION 1. Adjust head angle to 23 – 25 degrees (see page 14) Residue Plugging 1. Incorrect Head Angle 2. Roller Mount Tube incorrectly 2. Make sure the Bearing Support Tab is on the backside of installed the Roller Mount Tube 3.
  • Page 24 2565-792_Rev_E  09/2020...
