Yetter 5000-023C Operator's Manual

Stalk devastator corn stalk roller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
5000 SERIES STALK DEVASTATOR
5000-023C / 5000-024C / 5000-035A / 5000-039
AGCO/Gleaner 3000, 3308 & 3312 Hugger 630/830,
MF 3000 (1988 & Newer), Challenger CH630 & CH830
YETTER MANUFACTURING CO.
FOUNDED 1930
Colchester, IL 62326-0358
Toll free: 800/447-5777
309/776-3222 (Fax)
Website:
www.yetterco.com
E-mail:
info@yetterco.com
CORN STALK ROLLER
*PATENTED*
OPERATOR'S MANUAL
PART IDENTIFICATION
2565-784_REV_E – 01/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5000-023C and is the answer not in the manual?

Questions and answers

Related Manuals for Yetter 5000-023C

Summary of Contents for Yetter 5000-023C

  • Page 1 5000 SERIES STALK DEVASTATOR CORN STALK ROLLER *PATENTED* 5000-023C / 5000-024C / 5000-035A / 5000-039 AGCO/Gleaner 3000, 3308 & 3312 Hugger 630/830, MF 3000 (1988 & Newer), Challenger CH630 & CH830 OPERATOR’S MANUAL PART IDENTIFICATION 2565-784_REV_E – 01/2024 YETTER MANUFACTURING CO.

  • Page 2: Operation Checklist / Foreward / Warranty

    No warranty is made or authorized to be made, other than herein set forth. This warranty is in effect for one year after purchase. DEALER: ________________________________________ Yetter Manufacturing warrants its own products only & cannot be responsible for damages to equipment on which mounted.

  • Page 3: Safety Information

    BE ALERT! YOUR SAFETY IS INVOLVED. WATCH FOR THIS SYMBOL. IT POINTS OUT IMPORTANT SAFETY PRECAUTIONS. IT MEANS “ATTENTION---BECOME ALERT!” It is your responsibility as an owner, operator, or supervisor to know and instruct everyone using this machine at the time of initial assignment and at least annually thereafter, of the proper operation, precautions, and work hazards which exist in the operation of the machine in accordance with OSHA regulations.
  • Page 4 PLEASE READ, VERY IMPORTANT SECURE THE CORN HEADER AGAINST UNWANTED LOWERING BY APPLYING THE LOCKING MECHANISM ON HYDRAULIC CYLINDERS! 1. Attach head to combine, lock head to combine 2. Raise the head off the ground and engage safety stop on the feeder house cylinder 3.

  • Page 5: Table Of Contents

    OPERATION CHECKLIST / FOREWARD / WARRANTY.....2 SAFETY INFORMATION…………………………………...3 – 4 TABLE OF CONTENTS………………………………………...5 TORQUE / TOOLS REQUIRED.………………………………..5 ASSEMBLY INSTRUCTIONS 5000-023C & 5000-024C ....……........6 – 9 5000-035A..…...…...…..………........10 – 13 5000-039…………………………………………………………..14 - 17 OPERATION / STORAGE / ……………..……………………..18 BEARING REPLACEMENT / LOCKUP / TROUBLESHOOTING...19 PARTS IDENTIFICATON 5000-023C…………………………...…...……….....20 - 21...

  • Page 6: 5000-023C & 5000-024C

    5000-023C & 5000-024C ASSEMBLY INSTRUCTION GLEANER 3000 / HUGGER 630 & 830 / MF 3000 / CHALLENER CH630 & CH 830 STEP 1. Attach the 5000-248 Extension Mount to the 5000-247 Plate using 5/8” X 2” Bolts & 5/8” Lock Hex Nuts.
  • Page 7 5000-023C & 5000-024C ASSEMBLY INSTRUCTION STEP 3: Attach the 5000-135 Arm Mounts to the Extension Mount Bracket using ½” X 2” Bolts, ½” Washers, & ½” Lock Hex Nuts. STEP 4: Install the 5000-323 Lock Up Pin in the storage location on the mount arms, secure with Hair Pin Clips.
  • Page 8 5000-023C & 5000-024C ASSEMBLY INSTRUCTION STEP 6: Install the push rods into the mount brackets & attach to the pivot arms using the 5/8” Shoulder Bolts. 5/8” Washers, & ½” Jam Nuts. Use the lower hole on the arm. The washers are to be installed on each side of the “Eye”...
  • Page 9 5000-023C & 5000-024C ASSEMBLY INSTRUCTION Step 8: Insert the shim washer over the shaft on each end of the roller. Install the bearing over the shaft on each end of the roller so that the side of the casting that has the bearing protruding past the housing surface is towards the roller barrel & shim washer.

  • Page 10: 5000-035A

    5000-035A ASSEMBLY INSTRUCTION AGCO GLEANER 3308 STEP 1: Install the Mount Assemblies on the Corn Head Frame using 5/8” X 7” Bolts, Mount Straps, Clamp Brackets/Straps, 5/8” Washers, & 5/8” Lock Hex Nut. Place Mounts, Mount Straps, & Brackets as shown. The Double Mount goes between rows 4 &...
  • Page 11 5000-035A ASSEMBLY INSTRUCTION STEP 3: Attach 1) 5000-135 Arm Mount on each Offset Mount using ½” X 1 ¾” Bolts, ½” Washers, & ½” Lock Hex Nuts. Attach 2 Arm Mounts to the Double Offset on rows 4 & 5. STEP 4: Install a 5000-323 Lock Up Pin in the storage location on the Mount Arms &...
  • Page 12 5000-035A ASSEMBLY INSTRUCTION STEP 6: Install each Push Rods into the Mount Bracket & attach to the Pivot Arms using 5/8” Shoulder Bolts, 5/8” Washers, & ½” Jam Lock Hex Nuts. Use the lower hole on the arm. The washers are to be installed on each side of the “EYE”...
  • Page 13 5000-035A ASSEMBLY INSTRUCTION Step 8: Insert the shim washer over the shaft on each end of the roller. Install the bearing over the shaft on each end of the roller so that the side of the casting that has the bearing protruding past the housing surface is towards the roller barrel & shim washer.
  • Page 14 5000-039 ASSEMBLY INSTRUCTION AGCO GLEANER 3312 STEP 1: Install the Mount Assemblies on the Corn Head Frame using 5/8” X 7” Bolts, Mount Straps, Clamp Brackets/Straps, 5/8” Washers, & 5/8” Lock Hex Nut. Place Mounts, Mount Straps, & Brackets as shown. The 5000-246 Double Mount brackets will be installed between rows 3-4, 6-7, 9-10.
  • Page 15 5000-039 ASSEMBLY INSTRUCTION AGCO GLEANER 3312 STEP 2: Attach the 5000-309 Support Straps to the 5000-246, 5000-251, & 5000-252 Offset Mounts using the ½” X 1 ¾” Bolts & ½” Flange Lock Hex Nuts. STEP 3: Attach 1) 5000-135 Arm Mount on each Offset Mount using ½” X 1 ¾” Bolts, ½” Washers, & ½” Lock Hex Nuts.
  • Page 16 5000-039 ASSEMBLY INSTRUCTION AGCO GLEANER 3312 STEP 5: Attach the 5000-256 & 5000-259 Overbearing Arms to the Mount Brackets using 5/8” X 3” Bolts, Pivot Bushings, & 5/8” Lock Hex Nuts using the upper hole on the arms. Fully tighten all hardware at this time.
  • Page 17 5000-039 ASSEMBLY INSTRUCTION AGCO GLEANER 3312 STEP 7: Attach the Roller Mounts to the Overbearing Arms, & then install the ½” X 3 ¾” Bolts, Spacers, & ½” Lock hex Nuts. Slide the Roller Mount Tubes side to side as needed to clear the end of the Corn Head. NOTE: Make sure the Bearing Support Tab in on the backside of the Bearing Mounting Plate.

  • Page 18: Operation / Storage

    OPERATION CORN HEAD ANGLE NEEDS TO BE ADJUSTED BETWEEN 22 – 25° FOR OPTIMUM DEVASTATATOR PERFORMANCE. USE THE 5000-455 TO CHECK CORN HEAD ANGLE: - Put the combine on a level surface. Lower corn head to your normal working head height. - Place the magnetic protractor on the stripper plate to get the angle.

  • Page 19: Bearing Replacement / Lockup / Troubleshooting

    BEARING REPLACEMENT Put the bearing housing in a vice, use a pry bar to turn the bearing in the housing parallel with the slots, remove the old bearing, apply anti-seize lubricant to the interior of the bearing housing, insert the new bearing in the slots, & use a pry bar to move back to position.

  • Page 20: 5000-023C

    5000-023C PARTS IDENTIFICATION **PART IDENTIFICATION TABLE ON THE FOLLOWING PAGE**...
  • Page 21 5000-023C PARTS IDENTIFICATION ITEM PART NO. DESCRIPTION 2502-322 5/8-11 X 2 CAP SCREW GRADE 8 2502-325 5/8-11 X 3 CAP SCREW GRADE 5 2502-342 5/8-11 x 8 CAP SCREW GRADE 8 2502-350 ½-13 X 2 CAP SCREW GRADE 8 2502-353 ½-13 X 2.5 CAP SCREW GRADE 8...

  • Page 22: 5000-024C

    5000-024C PARTS IDENTIFICATION **PART IDENTIFICATION TABLE ON THE FOLLOWING PAGE**...
  • Page 23 5000-024C PARTS IDENTIFICATION ITEM PART NO. DESCRIPTION 2502-322 5/8-11 X 2 CAP SCREW GRADE 8 2502-325 5/8-11 X 3 CAP SCREW GRADE 5 2502-342 5/8-11 x 8 CAP SCREW GRADE 8 2502-350 ½-13 X 2 CAP SCREW GRADE 8 2502-353 ½-13 X 2.5 CAP SCREW GRADE 8 2502-365 ½-13 X 3.75 CAP SCREW GRADE 5...

  • Page 24: 5000-035A

    5000-035A PARTS IDENTIFICATION **PART IDENTIFICATION TABLE ON THE FOLLOWING PAGE**...
  • Page 25 5000-035A PARTS IDENTIFICATION ITEM PART NO. DESCRIPTION 2502-311 ½-13 X 1.75 CAP SCREW GRADE 8 2502-325 5/8-11 X 3 CAP SCREW GRADE 5 2502-353 ½-13 X 2.5 CAP SCREW GRADE 8 2502-365 ½-13 X 3.75 CAP SCREW GRADE 5 2502-396 5/8 X 7 CAP SCREW GRADE 8 2510-121 5/8 X 2.25 SHOULDER BOLT ½-13 THREAD...
  • Page 26 5000-039 PARTS IDENTIFICATION...
  • Page 27 5000-039 PARTS IDENTIFICATION ITEM PART NO. DESCRIPTION 2502-311 ½-13 X 1.75 CAP SCREW GRADE 8 2502-325 5/8-11 X 3 CAP SCREW GRADE 5 2502-353 ½-13 X 2.5 CAP SCREW GRADE 8 2502-365 ½-13 X 3.75 CAP SCREW GRADE 5 2502-396 5/8 X 7 CAP SCREW GRADE 8 2510-121 5/8 X 2.25 SHOULDER BOLT ½-13 THREAD...
  • Page 28 2565-784_REV_E  01/2024...
