Labconco Protector Premier 10040 Series User Manual page 45

Original instructions
Item Quantity
8C 1
8D 1
8E 1
10A 1
10B 1
11 1
12A 1
12B 4
13A 1
13B 1
13C 1
13D 1
13E 1
13F 1
13G 1
13H 1
14 2
15A 2
15B 2
15C 1
16 2
17 2
18 4
19 4
20 2
21 1
22 1 9409601, 02, 03, 05
23 1
24A 1
24B 1
24C 1
24D 1
24E 1
25 1
26 1
27 2
Product Service 1-800-522-7658
Appendix A: Protector Premier Components
Part No. Description
LED Light Fixture, 36" – use on 4' Hoods
9945300
LED Light Fixture, 48" – use on 5', 6' Hoods
9945301
LED Light Fixture, 36" Combo – use on 8' Hoods
9945302
1302301 Switch, Rocker
1327500 Switch, Plug (Fills cutout when switch is not used)
9818400 Access Cover
9409800 Side Panel, 24" internal deep hoods
1885308 Screw, Machine #10-24 x .50 Phillips
9436501 Eco-Foil 4'
9436502 Eco-Foil 5'
9436503 Eco-Foil 6'
9436505 Eco-Foil 8'
9436521 PVC Eco-Foil, 4'
9436522 PVC Eco-Foil, 5'
9436523 PVC Eco-Foil, 6'
9436525 PVC Eco-Foil, 8'
1850000 Pulley, Front, 2" Dia. Nylon
Cable, Sash 130" – NOT SHOWN
4949902
9414010 Cable Replacement Kit 24"
9545800 Weight Support Bracket Kit
9709300 Plastic Pulley, (Rear 2")
Bumper, Rubber (lower sash bumper) – NOT SHOWN
9713300
Bronze Bearing, Flanged Rear – NOT SHOWN
1934100
Clamp, Cable Replacement – NOT SHOWN
1920100
Threaded Connector (to attach weight to cable) – NOT SHOWN
9935800
9946300 or 01 Wiring Harness, Main
Front Panel, 4', 5', 6', 8'
1859900 Belt-V 3L380
1209400 Motor, 1/3 HP 4' 115V/230V (all 60 Hz)
1209500 Motor, 1/2 HP 5' & 6' 115V/230V, 60 Hz
1206600 Motor, 1/3 HP EP 4' 115V/230V, 60 Hz
1208200 Motor, 1/2 HP EP 5' & 6' 115V/230V, 60 Hz
1202400 Motor, 1/2 HP 4', 5' & 6' 230V (all 50 Hz)
4862900 Wheel, Blower
4863400 Shaft, Blower
1863000 Bearing, Pillow Block
41
