Dismantle call push-button module cover
During cleaning or replacement, the call push-but-
ton module cover can be dismantled from the front.
„ Lever open the top and bottom of the cover
strips (7) and remove them (Figure 18).
Figure 18: Removing cover strips
„ Use a screwdriver to lever open the push-
button module cover and remove it from the
front (Figure 19).
Figure 19: Dismantling the call push-button module
cover
(18) Call push-button module cover
i
Defective covers can only be replaced by co-
vers with the same number of push-buttons.
„ Remove the module to be replaced and install
the new module in reverse order.
6
Elcom Kommunikation GmbH-Zum Gunterstal-66440 BLIESKASTEL-GERMANY - www.elcom.de -
Replace a module
Dismantle the door station.
„ Remove the connection terminal block (13)
from the video insert.
„ Loosen the screws (18) on the rear base of the
modules (19) using a screwdriver and remove
the base (figure 20).
„ Remove the connecting cable connectors from
the module (12) to be exchanged (figure 2).
(7)
Figure 20: Module base dismantling
(19) Screws
(20) Module base
The video module and the call push-button module
can be removed.
i
Automatic or manual addressing of the module
is required to operate the door station.
(18)
Appendix
Technical data
Operating voltage
Camera standby current consumption
Camera current consumption (operation)
Camera heating current consumption (operation) 100 mA
Current name plate lighting
per call push-button module
(20)
Menu
(19)
setting
Table 2: Switch-on brightness level name plate-
Door release contact T/T potential-free
Door release unlocking time
Camera horiz/vertical aperture angle
Horizontal/vertical rotation angle
Camera resolution
Recommended camera installation height
Camera 1.5 mm hexagon locating screw
Degree of protection
Degree of protection
(degree of impact resistance)
Average degree of humidity f
Operating temperature
Camera heating switch-on
temperature
Storage/transport temperature
Connecting terminals
for conductor diameter
Dimensions:
Small call push-button
Small name plate insert
Medium call push-button
Medium name plate insert
Width of name plate insert
Door station dimensions
(L x H x D)
Backlighting On
Backlighting Off
0
Permanent Off
1
≈ 750 lx
≈ 1600 lx
2
.
3
.
4
.
5
.
6
.
7
.
8
.
9
≈ 60 lx
10
Permanent On
lighting
rom 5% to 75%
without condensation at 25°C,
can vary between 85% and 95%
for 30 days in the year
-20°C ... +55°C
less than about 20°C
-30°C ... +80°C
0.5 ... 0.8 mm
75.8 x 14.5 mm
75.8 x 32.6 mm
72.1 x 30.1 mm
100 x 191 x 29.5 mm
22 ... 24 V=
approx. 8 mA
max. 240 mA
45 mA
.
.
.
.
.
.
.
≈ 110 lx
max. 24 V/1 A
1 ... 10 s
82°/58°
42.5°
500 x 582 px
1.5 m
M2 x 10 mm
IP 54
IK07
72.1 x 12 mm
max. 0.5 mm
