4.4

Cushion

4.4.1 Removing the cushion
The wheelchair has a removable cushion. There are four screws, attached to
the cushion, that hold the cushion in place.
1. Remove the four screws from the attachment points on the backrest.
2. Remove the cushion from the backrest.
4.4.2 Attaching the cushion
1. Put the cushion in place on the backrest.
2. Put the four screws into the attachment points on the backrest and
tighten them by hand.
48 - Adjustments
