3.4.6 Battery indicator
The battery indicator gives an approximate indication if the batteries need to
be charged to prevent unnecessary stops because of discharged batteries.
The LEDs on the battery indicator show the battery status:
• When the batteries are fully charged, the red LED ( ), yellow LEDs ( ), and
green LEDs ( ) are lit.
• When the battery level is critically low, the red LED ( ) flashes and a beep
sounds. This means that you have to charge the batteries immediately to
prevent that the Explorer Mini stops working.
• If all LEDs ( , , and ) flash, there is a problem with the electronics.
Please contact your service provider or Permobil.
3.4.7 Joystick
The joystick is used to control the Explorer Mini. The neutral position is in the
center. Always put the joystick in the neutral position before you turn on or off
your child's wheelchair. This prevents joystick errors.
