Technical Specifications - Permobil Explorer Mini User Manual

3.2

Technical specifications

Product name (P):
Wheelchair class (W):
Height (A)
Width (B)
Length (C)
3.2.1 Dimensions and weight
Height
Overall height in standing position
Stowage height in standing position
Explorer Mini
A
Minimum: 725 mm (28")
Maximum: 920 mm (36")
490 mm (19")
635 mm (25")
Minimum: 725 mm (28")
Maximum: 920 mm (36")
9 steps at 25 mm (1") each.
920 mm (36")
The measurement is done from the test surface to the highest part of
the wheelchair (the backrest) when the table and backrest unit is
adjusted to its highest position.
725 mm (28")
Getting to know your wheelchair - 19
