Permobil Explorer Mini User Manual page 46

CAUTION! Pinch risk
4.2.1 Adjusting the height of the table and backrest unit
1. Loosen the tightening knob ( ).
2. Hold the table in its position ( ) to prevent it from sliding down on the
base module.
3. While you hold the table in its current position, pull out the plunger knob (
).
4. While you continue to pull the plunger knob ( ), move the column up or
down to the new setting.
5. Release the plunger knob ( ). A click signals that the plunger knob ( ) is
locked.
6. Tighten the tightening knob ( ) by hand.
46 - Adjustments
B
C A
