IMPORTANT! KEEP THIS MANUAL FOR FUTURE REFERENCE!
INSTRUCTION MANUAL FOR
USE OF CHILD RESTRAINT SYSTEM
„MAX SAFE"
This child restraint system
is
manufactured
in
compliance with the requirements of Regulation No 129 of the Econom-
ic Commission for Europe of the United Nations (UN/ECE) — Uniform
provisions concerning the approval of enhanced Child Restraint Systems
used on board of motor vehicles (ECRS), the provisions of the Product safety
Directive 2001/95/EU of the European Parliament and The Council as well as
the Consumer Protection Law of Bulgarian Legislation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAX SAFE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Chipolino MAX SAFE

Summary of Contents for Chipolino MAX SAFE

  • Page 1 IMPORTANT! KEEP THIS MANUAL FOR FUTURE REFERENCE! INSTRUCTION MANUAL FOR USE OF CHILD RESTRAINT SYSTEM „MAX SAFE” This child restraint system manufactured compliance with the requirements of Regulation No 129 of the Econom- ic Commission for Europe of the United Nations (UN/ECE) — Uniform...
  • Page 2 Child restrained system “MAX SAFE” is suitable for children with height 40-150 cm, approx. age 0-12 years and weight 0-36 kg. 40 - 105 CM 76 - 105 CM 105 - 150 CM REARWARD facing (R-1234) FORWARD facing (F-1234) FORWARD facing (F-1)
  • Page 3 CAUTION! 1. NEVER INSTALL THE CAR SEAT IN “FORWARD FACING” POSITION BEFORE THE CHILD’S AGE EXCEEDS 15 MONTHS! 2. DO NOT PLACE THE RESTRAINT SYSTEM ON A VEHICLE SEAT EQUIPPED WITH AIR BAG! THIS MAY RESULT IN DEATH OR SERIOUS! Review the instructions of the vehicle for information about airbags and conditions of transportation of children.
  • Page 4  THE LAP BELT MUST BE PLACED LOW DOWN, SO THAT THE PELVIS IS FIRMLY ENGAGED WITHOUT PRESSING!  CAUTION! DO NOT MAKE CHANGES, ADDITIONS OR MODIFICATIONS ON THE CAR SEAT WITHOUT THE APPROVAL OF THE NOTIFYING AUTHORITY ! IT IS DANGEROUS NOT TO KEEP STRICTLY THE INSTRUCTIONS GIVEN BY THE MANUAFACTURER! ...

  • Page 5: Product Features

    PRODUCT FEATURES This is child restrained system “MAX SAFE” is suitable for children with height 40-150 cm, approx. age 0-12 years and weight 0-36 kg.  The child restraint rotates 360 degrees on the base;  Backrest recline;  Headrest height adjustment;...

  • Page 6: Head Support Adjustment

    1. HEAD SUPPORT ADJUSTMENT Using the handle (18), move the head support up or down until you reach position suitable for the child. For height of the child 40-105 cm, suitable positions of head support are from 1 up to 4. For height of the child 105-150 cm, suitable posi- tions of head support are from 5 up to 11, as before adjustment you have to remove the shoulder belts.
  • Page 7 4. SHOULDER BELTS’S LENGTH ADJUSTMENT Loosing Tightening Press the adjuster under the fabric cover (10) and Pull the strap to tighten the belts. at the same time pull the shoulder belts towards you to loose them. IMPORTANT! The belts must snug well child’s body without pressing it and causing discomfort to the child.
  • Page 8 4. Tie both shoulder belts (c) and store them in the department behind the backrest cover (d), and central buckle (7) – in the department under the fabric cover (e). 6. ISOFIX ATTACHMENTS ADJUSTMENT • Install the guides of ISOFIX attachments (21) to the corresponding places in vehicle;...

  • Page 9: Seat Rotation

    8. SEAT ROTATION click Press the lever for seat rotation (14) and rotate the seat. Seat is rotatable in both directions. By fixing in required position (car seat is FORWARD facing or REARWARD facing) you will hear a click sound. 9.
  • Page 10 10. INSTALLATION OF CAR SEAT IN VEHICLE ATTENTION! Before install the car seat in vehicle, please be aware of the information in below table. Small head Fabric Additional Shoulder Crotch pad Central belts support cover triangle buckle and soft support pads 40-60 cm 60-105 cm...
  • Page 11 10-2 INSTALLATION OF CAR SEAT IN POSITION FORWARD FACING Using: ISOFIX + SUPPORT LEG HEIGHT OF CHILD: 76-105 cm click 1. Lift the seat, open the support leg (17) and rotate it at 90°. 2. Place the car seat on vehicle seat, install ISOFIX attachments (15), fix the support leg to the floor and rotate the seat at 90°...

  • Page 12: Fabric Cover

    10-4 HEIGHT OF CHILD: 105-150 cm INSTALLATION OF CAR SEAT IN POSITION FORWARD FACING Using: 3-point vehicle belt diagonal belt lap belt click 1. Store the support leg (17) under the base. 2. Place the child in car seat and set the height of head support according to child’s height. Pull the 3-point belt of vehicle.

  • Page 13: Care And Maintenance

    CARE AND MAINTENANCE  Clean the fabrics, plastic parts and metal parts with damp cotton cloth or sponge and mild soap  Fabric cover and soft pads may be hand washed at 30 ̊ С using mild detergent!  Do not bleach! Do not tumble dry! Do not machine wash! Do not iron! ...
  • Page 14 Bulgaria, Plovdiv, Str. Golyamokonarsko shosse № 1 www.chipolino.com...
