THE SAFETY OF
PRODUCTS AND THE MATERIALS
USED FOR THEIR PRODUCTION IS GUARANTEED AND CERTIFIED
IN TEST LABORATORIES ACCORDING TO EN STANDARDS.
INSTRUCTION MANUAL FOR USE OF
CAR SEAT "VERSO+"
VERSO+
PLEASE, READ THE THIS INSTRUCTION MANUAL CAREFULLY
BEFORE USING THE CAR SEAT AND KEEP IT IN A SAFE PLACE
FOR FUTURE REFERENCE.
Advertisement
Related Manuals for Chipolino VERSO PLUS
Summary of Contents for Chipolino VERSO PLUS
- Page 1 THE SAFETY OF PRODUCTS AND THE MATERIALS USED FOR THEIR PRODUCTION IS GUARANTEED AND CERTIFIED IN TEST LABORATORIES ACCORDING TO EN STANDARDS. INSTRUCTION MANUAL FOR USE OF CAR SEAT “VERSO+” VERSO+ PLEASE, READ THE THIS INSTRUCTION MANUAL CAREFULLY BEFORE USING THE CAR SEAT AND KEEP IT IN A SAFE PLACE FOR FUTURE REFERENCE.
- Page 2 This product represents universal integral child restraint system for use in motor vehicles fitted with approved 3-point car safety belts with retractor. It is suitable for children weighing up to 18 kg. This car seat is approved under No. E13-44R04-5045 for two weight groups: 0+ for children weighing up to 13 kg and group I - for children weighing 9 - 18 kg.
- Page 3 WARNINGS 1. Attention! Never leave the child unattended by an adult! 2. Follow the user instructions thoroughly in order to prevent possible injuries of your child! Make sure you follow this manual correctly. 3. Check the vehicle manual for information about the air bags and the transportation of children.
- Page 4 25. It is recommended to cover the car seat if the vehicle is parked under strong sun shine– extreme sun exposure will make the plastic to deteriorate and the fabric to fade. Please check that the child restraint has not become too hot before placing your child seat. 26.
-
Page 5: Parts Diagram
PARTS DIAGRAM 1. Shoulder strap slots 2. Harnesses cover 3. Safety harness belt 4. Adjustment button 5. Adjustment belt 6. Adjustment plate of seat angle (lever) 7. Buckle 8. Seat fabric cover 9. Metal safety pole 10. Metal safety pole ring buckle 11. - Page 6 INSTALLATION IN THE VEHICLE ACCORDING TO CHILD’S WEIGHT. ROUTING OF THE SEAT BELTS fig. 4 fig. 5 According to child’s weight, install the car seat in rear facing (fig. 4) or forward facing (fig.5) position. ATTENTION! Do not place the child in a sleeping bag, blanket or quilt before putting him in the car seat, because thus the shoulder belts will not snug well and will endanger child’s safety.
- Page 7 ROUTING OF THE SEAT BELT For group I (9-18kg) use fig. 7 Place the car seat in forward facing position on the seat of the car (fig. 7). Adjust the backrest in the described way. To achieve better fixing push the car seat maximum to the vehicle seat backrest.
- Page 8 SAFETY HARNESS SYSTEM LOCKING AND UNLOCKING THE HARNESSES 1. Join the harness buckle’s two sides parts together, slide them into the central part, the buckle is secured after you hear a positive click. See Fig. 9 - a) & b). NOTE: When a child is sitting in the restraint, you must check whether the buckle is still secured.
- Page 9 ADJUSTING THE HEIGHT OF HARNESSES fig. 11 There are 3 harness positions available that you can select according to child’s height. The harness height should be adjusted in such way that the child’s shoulders are at the same level as the harness coming out from the back.
-
Page 10: Cleaning And Maintenance Instructions
CLEANING AND MAINTENANCE INSTRUCTIONS 1. Regularly check the locking and fixing mechanisms, the belts and the upholstery, in order to make sure they are not worn out or damaged. 2. If you find that some part of the car seat has damage, immediately discontinue its use. 3. - Page 11 BULGARIA, Plovdiv 4027, 1 Goliamokonarsko shosse Str.; tel.: + 359 32 600 855; www.chipolino.com DECLARATION FOR COMPLIANCE I, Nina Mitkova – General Manager of Chipolino Ltd with its place of business at: 1 Golyamokonarsko Shosse Str., s. Tzaratzovo, Maritza Municipality, Plovdiv, Bulgaria, as being...
- Page 12 1 Goliamokonarsko shosse, Plovdiv, BULGARIA www.chipolino.com...
