IMPORTANT! KEEP THIS MANUAL FOR FUTURE REFERENCE
INSTRUCTION MANUAL
FOR USE OF CAR SEAT "CAMPO"
CAR SEAT
CAMPO
T h i s
product is designed and manufactured in compliance
with the requirements of Regulation 44 of the United Nations Economic
Commission for Europe concerning the safe transportation of children,
the provisions of the product safety directive 2001/95/EU of the European
Parliament and The Council as well as the Consumer Protection of National
legislation.
Advertisement
Related Manuals for Chipolino Campo
Summary of Contents for Chipolino Campo
- Page 1 IMPORTANT! KEEP THIS MANUAL FOR FUTURE REFERENCE INSTRUCTION MANUAL FOR USE OF CAR SEAT “CAMPO” CAR SEAT CAMPO T h i s product is designed and manufactured in compliance with the requirements of Regulation 44 of the United Nations Economic...
- Page 2 NOTICE 1. This is a “UNIVERSAL/SEMI-UNIVERSAL” CHILD RESTRAINT. It is approved (E8- 44R-0410409) according to Regulation No 44, 04 series of amendments, for general use in vehi- cles. 2. A correct fit is likely if the vehicle manufacturer has declared in the vehicle handbook that the vehicle is capable of accepting a “universal”...
- Page 3 1. Do not place the restraint system “REAR- WARD FACING” on a seat equipped with air bag, which cannot be deactivated! 2. To be used only if 3-point diagonal/lap belt is available and air bag is deactivated. Car seat CAMPO Group Installation way Approval system Universal...
- Page 4 • CAUTION! NEVER LEAVE YOUR CHILD UNATTENDED! • CAUTION! DO NOT USE ANCHOR POINTS OTHER THAN THE ONES DESCRIBED IN THIS MANUAL AND MARKED ON THE RESTRAINT SYSTEM. • CAUTION! NEVER INSTALL THE CHILD RESTRAINT IN THE DIRECTION OF VEHICLE MOVE- MENT AND FACING FORWARD BEFORE THE CHILD WEIGHT REACHES 9 kg! •...
-
Page 5: Main Parts Diagram
MAIN FEATURES OF CAR SEAT Child restraint restraint while traveling in a vehicle designed for children weighing from 0 to 36 kg, classified in weight groups: • 0+ (0-13 kg): universal and semi-universal ISOFIX child restraint system, ISOFIX class D. The restraint system must be installed in direction opposite to the direction of the vehicle and the child is “facing backward”;... -
Page 6: Installation In Vehicle
GUIDELINES FOR CAR SEAT USAGE IMPORTANT! • Follow exactly the instructions and sequence of installation steps and use of the product described in the text and figures of this manual. • Check the security of fixing after each operation! • ALWAYS CHECK THE SECURITY OF FIXING OF THE SAFETY BELTS! •... - Page 7 IMPORTANT! Tighten the belt of the top tether until indicator shows “green color”. If it is not green, install again. 7.2 – INSTALLATION WITH VEHICLE 3-POINT SAFETY BELT ATTENTION! Place the car seat in „REARWARD-FACING” mode! Install the car seat to the ISOFIX attachment of vehicle following steps 1 to 4 art.7-1Secure the car seat ATTENTION! SECURE THE CHILD WITH THE 5-POINT SAFET HARNESS! Group I (9-18kg) 8 - INSTALLATION WITH VEHICLE 3-POINT SAFETY BELT (ADDITIONAL ISOFIX...
- Page 8 too low too high correct 2 - pull 1 - press CLICK Harness release button 1 - pull the hook positions of backrest 2 - pull 2 - move 1 - press pull...
- Page 9 GROUP 0+ (0-13 кg.) 7-1 INSTALLATION OF CAR SEAT WITH ISOFIX ATTACHMENTS AND TOP TETHER step 1 step 2 pull the button 2 - премести move Indicator for most Indicator for most lying 1 - pull lying position position 2 - set in most lying position step 3 Tightly to vehicle seat step 4...
- Page 10 WARNING! MAKE SURE THE VEHICLE BELTS ARE NOT TWISTED AND ARE IN CORRECT POSITION! GROUP I (9-18 кg.) Step 1 Step 2 1 - Pull the button indicator for 2 - move car seat recline 1 - pull 2 - position in middle recline Step 3 Remove the soft pad...
- Page 11 Step 4 - option CLICK ATTENTION! The indicator must be green WARNING! MAKE SURE Step 5 THE VEHICLE BELTS ARE NOT TWISTED AND ARE IN CORRECT POSITION! Group II (15-25kg) and Group III (22-36kg) Step 1 - option CLICK ATTENTION! The indicator must be green...
-
Page 12: Cleaning And Maintenance Instructions
Always store your car seat indoors – on a dry and a clean place. Do not expose to direct environ- ment influence – sun, rain, moisture and high temperature intervals! • Please, contact your authorized dealer for problems connected with the use of repair. Used materials: metal, plastic, textile. STKCA01хххх Bulgaria, Plovdiv, Str. Golyamokonarsko shosse No 1 www.chipolino.com...
