Electric Motorized Projection Screen
AV Spectrum2 Series
Important Safety & Warning Precautions
Make sure to read this user's guide and follow the procedure below.
Caution: The screen's Black Top Drop is already set to its maximum drop distance. There is NO extra
Black Top Drop in the roller. Please be aware of this as it will void your warranty with EliteProAV
Screens. Unapproved changes or modifications (except for cutting the power cord for hardwire
installations) to this unit are prohibited and will void your warranty. For more information, please
contact our Technical Support Department at (877) 511-1211 Ext. 604.
•
Please retain this user's guide for future reference.
•
To avoid damaging the unit, do not use with any unauthorized accessories not recommended by
the manufacturer.
•
Handle the unit carefully during transportation to avoid any damages.
•
To ensure safe and reliable operation, direct connection to a properly grounded power source is
advised.
The power outlet supplying power to the unit should be close to the unit and easily accessible.
•
•
Do not install the unit on uneven or inclined surfaces.
•
Do not put heavy objects on the power cord and position it properly to avoid creating a trip
obstacle.
•
Never overload the power cord to prevent an electric shock or fire due to a loose contact or a
short circuit.
There are not user serviceable parts in this unit. Do not attempt to disassemble this unit by
•
yourself. No one except authorized technicians can open and make repairs to this unit.
•
Make sure the power source this unit is connected to has a continuous power flow.
•
If there is need to use an extension cord, make sure the cord has an equal rating as the appliance
to avoid overheat.
Do not handle the power plug when your hands are wet or your feet are in contact with water.
•
Rev. 11/27/18
User's Guide
eliteproav.com
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Elite ProAV Spectrum2 Series
Summary of Contents for Elite ProAV Spectrum2 Series
- Page 1 Electric Motorized Projection Screen AV Spectrum2 Series User’s Guide Important Safety & Warning Precautions Make sure to read this user’s guide and follow the procedure below. Caution: The screen’s Black Top Drop is already set to its maximum drop distance. There is NO extra Black Top Drop in the roller.
- Page 2 Do not use this unit under the following circumstances. • Disconnect the power cord under the conditions of heavy rain, wind, thunder or lightning. • Avoid direct Sunshine, rain shower and moisture. • Keep away from fire sources and high temperature to prevent this device from overheating. Cut off the power supply first before transportation or maintenance.
- Page 3 Hardware Parts List for the Spectrum2 Series Please make sure all parts listed below are included before proceeding with the installation. Hardware Parts List a. Mounting Bracket b. M4x50 Screw c. M10 Anchor d. Suspended Ceiling Bracket Connector e. M5x15 Screw & Bolt f.
- Page 4 3. Attach the screen to the Mounting Bracket by inserting the top of the case to the first fix plate, and securing the back of the case to the second Fix Plate. Make sure the case slots are securely attached to the Mounting Bracket. Mounting Bracket Mounting Bracket Fix Plate 1...
- Page 5 M10 Anchor Ceiling Mounting Bracket Fix Plate 1 M4x50 Screw Mounting Bracket Fix Plate 2 3. Attach the screen to the Mounting Bracket by inserting the top of the case to the first Fix Plate, and securing the back of the case to the second Fix Plate. Make sure the case slots are securely attached to the Hanging Bracket.
- Page 6 3. Insert chains (not included) through the loop holes of the Suspended Ceiling Bracket Connector (d). Suspended Ceiling Bracket Connector Loop Holes Built in 3 Way Control Switch 1. The PowerMax Series comes with a 3 Way Control Switch attached to the Power Cord, which is 3.5 meters in length.
