Thank you for choosing the Yard Master Pro 2 portable projection screen! Please read through this user guide
before utilizing the screen. Correct usage and maintenance will ensure a long product life.
Care & Use Instructions
◆ Elite ProAV highly recommends two people to assemble the Yard Master Pro 2 screen.
◆ Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of the points
below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the screen
material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or
alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to clean it.
◆After using the screen, disassemble it and store it in the carrying bag provided.
◆To avoid damage and injury, the screen should only be operated by adults.
Product Description
Design: The aluminum frame is designed to be light weight and easily operated making it easy to carry,
assemble and disassemble.
Screen Fabric: The screen fabric is attached to the rectangular frame and held in place by several press stubs,
which ensure an evenly stretched and flat surface. The screen materials are durable and can be folded many times
without causing damage or distortion to the surface.
Correct usage of the projection screen will ensure better viewing results.
For front projection, assemble and view the screen as indicated in Fig.1.
Front rear projection, assemble and view the screen as indicated in Fig. 2.
01282020JA
Indoor/Outdoor Portable Projection Screen
Fig. 1
Yard Master Pro 2 Series
User's Guide
Fig. 2
www.eliteproav.com
Advertisement
Related Manuals for Elite ProAV Yard Master Pro 2 Series
Summary of Contents for Elite ProAV Yard Master Pro 2 Series
- Page 1 Correct usage and maintenance will ensure a long product life. Care & Use Instructions ◆ Elite ProAV highly recommends two people to assemble the Yard Master Pro 2 screen. ◆ Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of the points below to prevent that from occurring: 1.
- Page 2 Hardware and Parts List A. Folding frame x1 B. Left and right folding legs x2 C. Knob Screw (Refer to Chart) D. Projection screen material x2 E. Screen material bag x2 F. Carrying Bag x1 1 x Front projection and 1x Rear projection G.
- Page 3 Note: When unfolding the frame and legs, be sure the latches on the hinges "click" into place. Please also make sure all 4 corners of the frame are at a 90° angle and the hinged support bar is straight and not bent. Screen Material Attachment Take the screen material (D) out of the screen material bag (E) and align the corners of the screen material with the inside corners of the frame.
- Page 4 Leg Attachment Procedure 1. Carefully take the left and right folding legs (B) out of the carrying bag (F) and place it on a flat surface. Unfold the left and right legs leaving the front foot folded as shown below. Make sure the hinges click into place. Warning: The additional support sections, located at the middle section of the legs, may unfold on its own.
- Page 5 Be sure to place folding frame, legs, and smaller parts into the carrying bag first and place the material on top to keep material from creasing or tearing. For more information, technical support or your local Elite ProAV contact, please visit www.eliteproav.com 01282020JA www.eliteproav.com...
