To Load A Stack Of Documents - Microtek ArtixScan DI 3130c Start Here Manual

Position Documents
The scanner supports scanning of document in various materials, such as A4 printouts,
insurance papers, legal documents, postcards, credit cards, business cards, and etc. A
stack of up to 100 sheets can be fed in the scanner's Document Feed Tray. Paper sizes
can range from 2.91" x 2.1" (74 mm x 52 mm) to 8.5" x 65" (216 mm x 1651 mm).

To load a stack of documents

1. Pull out the Feed Tray Extender for
better paper support if needed.
2. Pull out the Output Tray to carry the
scanned documents. Flip up the Output
Tray Extender to carry the longer
documents if needed.
3. Load and center the stack of documents
onto the Document Feed Tray, with the
side to be scanned facing down and
the top edge facing toward the feeder.
Then, slide the two Guide Arms toward
the stacked papers if needed.
Output Tray
Output Tray Extender
Guide Arms
4
Feed Tray Extender
Document Feed Tray
