Install the Document Feed Tray
Before using the Document Feed Tray with your scanner, you need to install it on the
scanner. Follow the instructions and graphs below to correctly install the Document Feed
Tray.
A. Lift up the Release button in the
direction of the arrow shown to open
the scanner cover.
B. Install the Document Feed Tray on the
scanner;
a). insert the four flanges (tabs) of
the feed tray into the holes on the
scanner, indicated in the graphic by
blue circles.
b). push down the two flanges (tabs)
located at the rear of feed tray into
another two holes, indicated in the
graphic by red circles.
Make sure the Document Feed Tray
snaps into place and sits tightly on the
scanner.
C. Close the scanner cover. You would
hear a click sound when the scanner
cover returns to its original position.
