Microtek ArtixScan DI 3130c Start Here Manual page 7

5. Click the Show Preview Window and Show Setting Window tabs in the Scan Setup
interface to display other interfaces which are helpful for your scanning processing.
6. Click the Preview button to perform a preliminary view of the entire image. When
done, a preview image appears in the Preview window.
Do not forget to put the document back on the document feed tray.
7. Go to the "General" panel by clicking the General tab in the Settings window. Specify
the settings for your requirements there.
a) If necessary, specify the image settings for the
front or back side of documents separately by
using the Sides of Material control when Scan
Source is set as "ADF (Duplex)".
b) Select the image type in the Document Type as
your input image type.
– Select Photo to scan color prints.
– Select Text to scan text.
c) If necessary, check "Double Feed" to prevent multiple pages from being fed
together while papers are fed through the ADF.
d) If necessary, check "Remove Blank Page" and "Remove Punch Hole" to enhance
the quality of the scanned images.
8. If necessary, go to the "Image Process" panel by clicking the Image Process tab in
the Settings window. Use the image correction tools presented there to enhance the
image quality according to your specific requirements.
9. Click the OK button to close the Scan Setup interface and return to the Main interface
of ScanWizard DI.
10. In the Main interface, click the File Format menu button to select a file format for the
scanned images.
11. In the Main interface, click the File Name menu button to specify a file naming method
for the scanned images.
12. In the Main interface, select and click the Normal Scan button to start scanning.
When done, the scanned images will be automatically saved into the folder defined in
the File Location menu box. At the same time, the scanned images will be displayed
in thumbnail sizes in the Thumbnail View window and labeled with the file name and
file format specified earlier.
13. Click the Open Folder button to locate the scanned images if you want to view.
NOTE: For more details on other scanning scenarios applicable to your scanner, refer to the scanner's
User's Manual in the Microtek Software CD/DVD.
