Table 1: FEC16 Physical Features Callouts and Descriptions
Callout Physical Feature: Description and References
1 Binary Output (BO) Source Power Selection Jumpers (see
2 Device Address DIP Switch Block (see
3 Mounting Clip
4 Configurable Output (CO) Terminal Blocks (see
5 24 VAC, Class 2 Supply Power Terminal Block (see
6 Cover Lift Tab (One of Two) (see
7 Display Navigation Buttons (see
(FEC1621 model only)
8 LCD Display Area (see
(FEC1621 model only)
9 FC Bus Terminal Block (see
10 Sensor Actuator (SA) Bus Terminal Block (see
11 Sensor Port (Sensor Actuator [SA] Bus, RJ-12 6-pin Modular Jack) (see
12 Binary Inputs (BIs) Terminal Block (see
13 Universal Inputs (UIs) Terminal Blocks (see
14 LED Status Indicators (see
15 Field Controller (FC) Bus Port (RJ-12 6-pin Modular Jack) (see
16 Binary Output (BO) Terminal Block (see
FEC1611 and FEC1621 Field Equipment Controller Installation Instructions
Figure 3: FEC16 Physical Features (FEC1621 Shown)
Figure
Figure 3)
Setting Up an Integral Local
Setting Up an Integral Local
FC Bus Terminal
Table
Table 8)
Table
Binary Output (BO) Source Power Selection
9)
Table 3)
Supply Power Terminal
Display)
Display)
Block)
SA Bus Terminal Block)
3)
Table 3)
Figure
3)
Block)
Figure 6)
6)
Jumpers)
