dossier
Installation Guides
Section:
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
Description:
MODESTY PANEL - END POSITION
ZJSF, ZJPF, ZJDF, ZJRP, ZJRF, ZJUP, ZJUF, ZJBF, ZJBG, ZJBH, ZJBJ,
ZJNF, ZJNJ, ZJNP, ZJNR, ZJEF, ZJEJ, ZJEP, ZJER
A1
D
B
B
PEDESTAL DESK WITH
FULL MODESTY END
POSITION (ZJDF)
SHOWN AS EXAMPLE
Date:
Feb 2023
DOS_003b
Part and Product Identification
A1 - Modesty Panel
A2 - Modzee Clip (AS111) x 4
B - Pedestal x 2
1
C -
" Modular Screw (AS121) x 6
2
D - L Bracket (AS079) x Varies
E - #8 Pan Head Wood Screw
(AS031) x 12
For Customer Support please contact
product.support@teknion.com
1 of 4
Page No:
Rev. No: 1
Advertisement
Table of Contents
Related Manuals for Teknion Dossier ZJSF
Summary of Contents for Teknion Dossier ZJSF
- Page 1 " Modular Screw (AS121) x 6 D - L Bracket (AS079) x Varies E - #8 Pan Head Wood Screw PEDESTAL DESK WITH (AS031) x 12 FULL MODESTY END POSITION (ZJDF) For Customer Support please contact SHOWN AS EXAMPLE product.support@teknion.com...
- Page 2 dossier Installation Guides Section: DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS Date: Feb 2023 Page No: 2 of 4 Description: MODESTY PANEL - END POSITION DOS_003b SCREWS TO PEDESTAL L-BRACKET INSTALL TO MODESTY STEP 2: Fasten L Bracket to Modesty Panel using pilot holes for proper location. UseWood STEP 1: Fasten Modular Screws to pilot holes located on the Pedestal.
- Page 3 dossier Installation Guides Section: DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS Date: Feb 2023 Page No: 3 of 4 Description: MODESTY PANEL - END POSITION DOS_003b ALIGN MODESTY TO GABLE MODESTY PANEL LOCATION STEP 3: Line-up screws to bottom end of cavity STEP 4: Make sure all Modular Screws are inside of cavity.
- Page 4 dossier Installation Guides Section: DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS Date: Feb 2023 Page No: 4 of 4 Description: MODESTY PANEL - END POSITION DOS_003b ELEVATE MODESTY PANEL MODESTY PANEL INSTALL Align Keep Elevated STEP 6: Lower Modesty Panel so that the screws slide to the top of Modzee Clips. Make sure STEP 5: Keep Modesty Panel elevated and insert Pedestal by lining up Modular Screw to Top of Modesty Panel is leveled to the top of Gable.
