SERVICE MANUAL
EN
The following instructions provide the necessary information for the proper
operation and preventive maintenance of the Binks Airless 75 Spray Gun.
Please read and understand all information in this document in order to get the
maximum performance from your new Airless 75 spray gun.
IMPORTANT! DO NOT DESTROY
It is the Customer's responsibility to have all operators and
service personnel read and understand this manual.
READ ALL INSTRUCTIONS BEFORE OPERATING THIS PRODUCT.
77-2950-R7 (6/2023)
AIRLESS 75 SPRAY GUN 7500 PSI
(0811-7500-1, 0811-7500-2, 0811-7500-3)
1 / 16
www.carlisleft.com
Advertisement
Table of Contents
Related Manuals for Carlisle BINKS 0811-7500-1
Summary of Contents for Carlisle BINKS 0811-7500-1
- Page 1 SERVICE MANUAL AIRLESS 75 SPRAY GUN 7500 PSI (0811-7500-1, 0811-7500-2, 0811-7500-3) The following instructions provide the necessary information for the proper operation and preventive maintenance of the Binks Airless 75 Spray Gun. Please read and understand all information in this document in order to get the maximum performance from your new Airless 75 spray gun.
- Page 2 77-2950-R7 (6/2023) 2 / 16 www.carlisleft.com...
- Page 3 77-2950-R7 (6/2023) 3 / 16 www.carlisleft.com...
- Page 4 In this part sheet, the words WARNING, CAUTION and NOTE are used to emphasize important safety information as follows: WARNING CAUTION NOTE Hazards or unsafe Hazards or unsafe practices which could practices which could Important installation, result in severe personal result in minor personal operation or maintenance injury, death or substantial...
-
Page 5: Specifications
BINKS AIRLESS 75 SPRAY GUN 7500 PSI For trained, professional use only! Maximum working pressure: 7500 PSI – 517 BAR – 51.7 Mpa Model 0811-7500-X SAFETY, OPERATING AND MAINTENANCE INSTRUCTIONS INSIDE!! Read all warnings and operating information inside SAVE THIS MANUAL FOR FUTURE REFERENCE Contact your local Binks representative for additional copies of this manual... - Page 6 BINKS AIRLESS 75 SPRAY GUN CAUTION NOTE NOTE TO PHYSICIAN: KEEP CLEAR OF NOZZLE: Do not exceed Injection into the skin is a traumatic injury. maximum working pressure of 7500 PSI It is important to treat the injury as soon as (517 BAR, 51.7 Mpa).
- Page 7 BINKS AIRLESS 75 SPRAY GUN Hold gun firmly against side of container to WARNING ground container and prevent static sparks. Follow the material and solvent manufacturer’s HAZARD: GENERAL – Can cause severe warnings and instructions. injury or property damage. Use extreme caution when using materials with a PREVENTION: flashpoint below 70°...
- Page 8 BINKS AIRLESS 75 SPRAY GUN Do not point gun at anyone or any part of the WARNING body. Do not put your hand or fingers over the spray tip. The following are general WARNINGS related to the setup, use, grounding, Do not stop or deflect leaks with your hand, maintenance and repair of this equipment.
-
Page 9: Grounding And Electric Requirements
BINKS AIRLESS 75 SPRAY GUN SET UP INSTALLATION Route hoses and cables away from traffic areas, sharp edges, moving parts and hot surfaces. WARNING Do not kink or over bend hoses or use hoses to pull equpment. Never attempt to assemble, change, or clean the gun, tip, or tip guard without first Use genuine BINKS hoses. -
Page 10: Gun Operation
BINKS AIRLESS 75 SPRAY GUN CONNECTION TO THE HOSE BINKS Airless 75 PROFESSIONAL AIRLESS SPRAY GUN Attach a properly grounded fluid hose to the fluid 7500 PSI (517 BAR) MODEL 0811-7500-X hose connection fitting (1/4 - 18 NPS thread) on the bottom of the handle of your spray gun. -
Page 11: Troubleshooting
BINKS AIRLESS 75 SPRAY GUN CLEANING AND MAINTENANCE TO REPLACE NEEDLE ASSEMBLY (10) 1. Shut off power supply to pump and release CLEAN DAILY pressure from gun. Remove gun from hose. Maintaining a clean gun is important to ensure 2. Remove screws and rear cap. (12) trouble-free operation and extend the service life of your gun. - Page 12 BINKS AIRLESS 75 SPRAY GUN BINKS AIRLESS 75 SPRAY GUN PARTS LIST ITEM PART NUMBER DESCRIPTION QTY. — TWIST TIP 7500, PSI, SEE CHART 54-7539-K2 TWIST TIP BRACE KIT 1108-75B 7500 PSI TWIST TIP GUARD 54-7511-K DIFFUSER NUT KIT (0811-7500-1, 0811-7500-2) 54-7537-K DIFFUSER NUT KIT (0811-7500-3) 54-2096-K5...
- Page 13 BINKS SPRAY TIP SELECTION CHART PART NUMBER 9-XXX-75 (Tips rated for use at 7500 psi) All of the following tips will have a grey tip handle 4” 6” 8” 10” 12” 14” spray spray spray spray spray spray pattern pattern pattern pattern pattern...
- Page 14 NOTES 77-2950-R7 (6/2023) 14 / 16 www.carlisleft.com...
- Page 15 77-2950-R7 (6/2023) 15 / 16 www.carlisleft.com...
- Page 16 This product is covered by Carlisle Fluid Technologies’ materials and workmanship limited warranty. The use of any parts or accessories, from a source other than Carlisle Fluid Technologies, will void all warranties. Failure to reasonably follow any maintenance guidance provided may invalidate any warranty.
