SERVICE MANUAL
EN
2
1
ITEM
PART
NO.
NO.
DESCRIPTION
1
*
AIR NOZZLE .................................. 1
2
*
FLUID NOZZLE .............................. 1
3
20-3870
FLAT WASHER,
4
47-23
FLUID NEEDLE VALVE STEM ........ 1
5
54-304-5• SPRING .......................................... 1
6
54-335
SCREW .......................................... 1
7
54-710
SCREW .......................................... 1
8
54-738-5• PACKING ....................................... 2
9
2-28-5•
PACKING ....................................... 1
54-747-5
LEATHER PACKING
10
54-765
NUT ............................................... 1
11
54-918-5• GASKET ........................................ 1
12
54-1014-5 PIN ................................................ 1
13
54-1015-5 WASHER ....................................... 1
* When ordering, please specify number stamped on nozzle.
• Indicates parts included in 6-1303 Repair Kit.
To convert 603 Series to 601 or 604 Series,
order 54-2038 Plug and 56-126 Cap.
Standard set-ups available. Optional set-ups,
please order separately.
77-1729-R9 (8/2018)
MODELS 603, 603V CONTINUOUS SPRAY GUNS
(603: 6473-XXXX-X , 603V: 6479-XXXX-X)
22
7
16
11
4.875" (REF. ONLY)
PARTS LIST
When ordering, please specify Part No.
QTY.
... 1
No. 5 (Stainless Steel)
(ALTERNATE)
6
4
9
10
23
19
ITEM
PART
NO.
NO.
DESCRIPTION
14
54-1016-5 WASHER ....................................... 2
15
54-1063
BODY ............................................ 1
16
54-1293
HEAD (
17
54-2012
KNOB ............................................ 1
18
54-2013
SCREW .......................................... 1
19
54-2014
NUT ............................................... 1
20
—
STEM ............................................. 1
21
54-2017
SIDE PORT ASSEMBLY .................. 1
22
—
BODY ............................................ 1
23
54-2168•
SPRING .......................................... 1
24
57-13-1
D.M. NIPPLE ................................. 1
25
OMX-88
BRUSH
603 Gun
6473-2500-7
603 Gun 63ASS-63PB
603V Gun
6479-4909-9
603V Gun 67VT-67PD
1 / 4
12
13
5
21
8
14
15
20
18
17
24
3
QTY.
....................... 1
Stainless Steel)
......................... 1
(Not Shown)
