- Page 1 INSTALLATION MANUAL SCAN-LINE 8 GAS Please leave these instructions behind with the device www.heta.dk DANISH DESIGN . DANISH QUALITY . DANISH PRODUCTION...
-
Page 2: Table Of Contents
12.4 Replacement of parts 12.5 Packaging materials Heta A/S Jupitervej 22, DK-7620 Lemvig Copyright © 2014 Printed in Denmark Phone: +45 9663 0600 Heta is a registered Subject to printing errors 25.05.2022 E-mail: heta@heta.dk trademark of Heta A/S and changes. 0037-1825 Version 1,1... -
Page 3: Before Installation
BEFORE INSTALLATION Heta gas stoves are quality products, therefore, your first impression is very important! We have a good logistics net- work, which transports Heta products with great care for our dealers. Nevertheless, when in transport or handling, damage of the often-heavy stoves can occur. It is important that upon receipt check your Heta product completely and report any damage or defects to your dealer. -
Page 4: With Your New Gas Stove You Should Find
WARNING : SHOULD THE BURNER BE EXTINGUISHED FOR ANY REASON WAIT 3 MINUTES BEFORE RE-IGNITION IS ATTEMPTED WARNUNG: NACH DEM ERLÖSCHEN DER ZÜNDFLAMME IMMER 3 MINUTEN WARTEN BEVOR DAS GERAT NEU GEZUNDET WIRD. Heta A/S, SERIAL/SERIE No:- DK-7620 Lemvig 0359/ Scan-line 8 Gas Denmark PIN: 0359CN1268 ▫ ▫ ▫... -
Page 5: Ce Statement
2 IMPORTANT SAFETY INFORMATION We hereby declare that the design and construction of the HETA gas appliances are complying to the essential The fireplace may only be installed by a qualified installer/ demands and regulations for gas products. dealer, following these installation instructions. We advise... -
Page 6: Warranty
5. In case the installer is not able to fix the problem him- self, a request can be made to HETA to do it for him, as long as the service can be done within the borders of the Benelux. -
Page 7: Remote Control With Full Electronic Ignition
ELECTRONIC IGNITION The unit is operated using a remote control (Fig. 4.1) or the HETA Puck, connected to a receiver (Fig. 4.2). The receiver is powered by 4 pen lite (type AA) batteries or a 6V adapter; 2 penlight batteries (type AAA) are used for the remote control. -
Page 8: Installation Preparation And - Instruction
• IS813 (otherwise known as Concentric Flue) parts as specified • ICP3 by HETA. The HETA specified flue parts have been ap- • IS327 proved with the appliance. If the appliance is installed on • Any other rules in force. -
Page 9: Fire Safe Installation
6 FIRE SAFE INSTALLATION To install a gas fireplace as safely as possible, several installation preparations need to be made. This overview can be used to assure the fire safety of a conversion of a fireplace. 6.1 Fire safety device set-up Install the device such that there are no flammable materi- als around the device (Figure 6.1). -
Page 10: Assembly Regulations With Flammable Materials
6.2 Assembly regulations with a - a’ flammable materials (Figure 6.2 and 6.3) Load-bearing walls and ceilings must be covered in a pro- tective fire resistant plate. Never use flammable materials around the fireplace. The minimal distance between the device and non-flammable materials must be at 120 mm to ensure a convection air flow. -
Page 11: Attention Points Gas Flue
7 ATTENTION POINTS GAS FLUE 8 INSTALLATION CHECK AND FIRST USAGE To guarantee the fire safety regarding you flue gas con- figuration a casing is necessary. For this case non-com- 8.1 Renovation/new construction bustible materials should be used. Make sure to ventilate a shaft and never to insulate it, to make sure the hot air is able to get away. -
Page 12: Electrical Circuit
Android. The app has a user friendly, interactive layout and the de- sign is adjusted for HETA devices. Up to eight devices Figure 9.1 can be used with one app, in the situation that multiple shows a simplified connection circuit for the fireplace. -
Page 13: Maintenance Instruction
10.1 Maintenance The Scan-Line 8 Gas fireplace (Figure 10.1) is easy in maintenance. The front of the fireplace has two doors which can be openend easily. 10.1.1 Electronics and gas parts The bottom door offers room to all the electronics for the fireplace. -
Page 14: How To Open The Door
10.3 HOW TO OPEN THE DOOR Figure 10.2 - Opening the top door... -
Page 15: Decoration Arrangement
11 DECORATION ARRANGEMENT Position the decoration logs as shown on the image Only the decoration ceramics supplied with this appliance below. are to be used. The ceramics must be laid only as shown on this page. Replacement parts are available from your Make sure that the pilot flame area and the second dealer, but should only be installed by a qualified instal- thermocouple are always free of any decorative ma-... -
Page 16: User Instruction
HEPA filtering servicing the appliance. No liability can be accepted by system is used. HETA for injury caused by burning or scolding by a hot Re-fit the firebed arrangement, reseal the appliance and appliance. -
Page 17: Afirst Aid For Malfunction
APPENDICES A FIRST AID FOR MALFUNCTION Below you will find an overview of the possible cause and solution in the event of a failure. Problem Possible Cause Solution No transmission 1 Batteries in the receiver empty Replace the batteries (4x 1.5V AA) (motor will not 2 Batteries hand remote empty Replace the batteries (2x 1.5V AAA) - Page 18 4,5 mV 4,5 mV Figure A-5: interrupter Figure A-4: Testpoint A Figure A-1: Bend pin Figure A-6: Wiring receiver Figure A-2: Antenna Figure A-7: Pilot set Figure A-3: Torx screw...
- Page 19 Problem Possible Cause Solution 1 Insufficient voltage across the thermocouple The pilot light Place the measuring pins of the multimeter on the ground goes on but goes or too much resistance in the thermocouple and black cable of the breaker. This value must be at least circuit out immediately 4.5 mV.
- Page 20 Figure A.8: Second thermocouple Figure A.11: “Double plus”-button on the remote Figure A.9: Button A on “On” Figure A.13: SI-port Figure A.10: RESET-button Figure A.11: Aux-position receiver Figure A.14: Domotica system...
-
Page 21: Berrors Codes Procontrol App
B ERRORS CODES PROCONTROL APP B.1 Messages shown in app Error Message in App Description Possible cause code • • Contact Service. 5 sec. beep from Receiver Microswitch not making contact with cam on motor knob • • Fire is not responding; no ignition Motor wiring is incorrect •... -
Page 22: Messages Shown In Remote
Error Message in App Description Possible cause code • • Contact Service. Fire is not responding Receiver or Wi-Fi Box malfunction • • No electronic control of fire Connection cable from Receiver to Wi-Fi Box defective • • Check Wi-Fi Fire is not responding No Wi-Fi connection to myfire Wi-Fi Box, router and / or smart •... -
Page 23: Cfaults And Error Codes In The Remote
C FAULTS AND ERROR CODES IN THE REMOTE This appendix can be consulted when error messages oc- C 2.4 Frequency cur in the application for smartphone and tablet. By default, most routers use the 2.4 GHz band to broad- cast the Wi-Fi signal. The disadvantage is that this fre- C.1 F41 error quency band is very busy, so that there is quickly inter- ference. -
Page 24: Dlocation Terminal
D LOCATION TERMINAL D.1 Terminal location with vertical D.2 Terminal location with Horizo- exhaust (C11) ntal exhaust (C31) Position terminal dist. Distance Exhaust 1,2 of 3 (mm) At the same roof level > 6 m * Directly below an opening, ventilation stone, At a different roof level >... -
Page 25: Egeneral Rules For Flue Gas Extraction
An R means you have to put in a restrictor plate in your fireplace. shows you where the restrictor plate Figure E.1 is inserted. For the Scan-Line 8 Gas first a plate must be removed by loosening 4 screws. Then the restriction plate can be taken out or changed. -
Page 26: Fcalculation Table Flue Gas Reduction
F CALCULATION TABLE FLUE GAS REDUCTION The calculation table shows when you need to place a Position of the Restrictor flue gas ristrictor Result Action No ristrictor required √ Position the resitrictor No good operation guaranteed * F.1 Horizontal terminal flue diameter 200/130 √... -
Page 27: Gtechnical Data
G TECHNICAL DATA The dataplate specifies for which type of gas, gas pressure and for which country this appliance is intended. The nameplate is attached to a chain. It must remain attached to the chain. Note: Check whether the appliance is suitable for the gas type and gas pressure on site. -
Page 28: Hecodesign
The ecolabel shows which category the fireplace belongs to. H.1 Ecolabels The ecolabels for the different types of gas are indicated below, respectively G20, G25 and G30. HETA A/S Scan-Line 8 Gas | G20 Scan-Line 8 Gas | G25 Scan-Line 8 Gas | G30 ENERGIA ·... -
Page 29: Idimensional Drawings
I DIMENSIONAL DRAWINGS On this page and the following ones you will find dimensional drawings of the Scan-Line 8 Gas with some of the impor- tant dimensions that you have to take into account when installing and installing your fireplace. -
Page 30: Jinstallation Of Flue Collar At Top Outlet
J INSTALLATION OF FLUE COLLAR AT TOP OUTLET... -
Page 31: Kinstallation Of Flue Collar At Back Outlet
K INSTALLATION OF FLUE COLLAR AT BACK OUTLET... -
Page 32: Lplacement Of Interior Glass, Accessory
L PLACEMENT OF INTERIOR GLASS, ACCESSORY... -
Page 33: Eu Declaration Of Conformity
DoC E4-32 Scanline 8 104450111LHD-001 2020 Telephone +45 9663 0600 Product fiche Model identifier Scan-Line 8 Gas G20 (E4-32 Scanline 8) The identified product described above is in Notified body relevant to the assessment and verification of conformity with: constancy of performance The relevant EU harmonized regulations: Intertek Total quality. - Page 34 DoC E4-32 Scanline 8 104450111LHD-001 2020 Telephone +45 9663 0600 Product fiche Model identifier Scan-Line 8 Gas G25 (E4-32 Scanline 8) The identified product described above is in Notified body relevant to the assessment and verification of conformity with: constancy of performance The relevant EU harmonized regulations: Intertek Total quality.
- Page 35 DoC E4-32 Scanline 8 104450111LHD-001 2020 Telephone +45 9663 0600 Product fiche Model identifier Scan-Line 8 Gas G30 (E4-32 Scanline 8) The identified product described above is in Notified body relevant to the assessment and verification of conformity with: constancy of performance The relevant EU harmonized regulations: Intertek Total quality.
