    Congratulations on your new stove. We confident that you will be more than satisfied with your new Heta stove, especially if you follow the advice and instructions we have put together in these operating instructions. Ambition series have been approved per the EN 13240, NS 3058/3059 and 15a B-VG.
  • Page 5: Before Installation

    It is important that upon receipt check your Heta product completely and report any damage or defects to your dealer. The packaging must be disposed of as follows: Wood is untreated and able to burn in the stove.
  • Page 6 With your new wood stove you should find the following: Q.C. check Operating / Instruction manual Data plate Heta glove 8056-0000-DK DOP-Scan-line 1000 -XXXX-2016 Heta A/S Jupitervej 22 7620 Lemvig Denmark 2016 Produk�ons år: DS/EN 13240, AEA, NS 3058/3059, Aus §15A Produkt beskrivelse Produk�onsnummer Scan-Line 1000 brændeovn Afstand �l brændbart materiale - bag ovn...
  • Page 7: Operating Instructions

    The flames Stove door handle must work from the top down. 1.2 first firing Heta wood stoves are, treated with a heat-resi- stant coating, which hardens at a temperature of about 250° C. This curing process will cause some smoke and...
  • Page 8: Emptying The Ash

    emptying the ash It is advantageous to leave a layer of ash in the bottom of the combustion chamber on top of the grate as insulation. Be careful when emptying the ashes out. There can be hot embers left for a long time. Never empty ash into a combustible container.
  • Page 9: Draft Conditions In The Chimney

    Good draft occurs when: • The difference in temperature in the chimney (warmer) and outside temperature (colder) ficiency. Heta wood stoves are constructed so • It is clear weather that it itself provides an optimal blend of com- • The chimney has the right height min 4 meters bustion air.
  • Page 10: Operating Problems

    If the wood is damp and inadequately seasoned, nal association of chimney sweeps) registered a large proportion of the energy in the fuel will be chimney sweep. used to vaporize the water and this will all disap- In the event of smoke or malodorous fumes are pear up the chimney.
  • Page 11: Troubleshooting

    1.15 troubleshooting table - applies to all stove types Fault Cause Troubleshooting Solution Inadequate chimney draft. Lighting problems. When the You can test using a lighter whether Improve the chimney. The chimney only has stove is cold, smoke seeps flame is drawn into the combustion sufficient draft when it is hot.
  • Page 12: Diagram For Maintenance

    1.16 Diagram for the maintenance Qualified Stove Owner Technicia Maintenance / Period Before 60-90 1st Year 2st Year Daily Autum week days days Cleaning the chimney (see. Chimney) Cleaning the chimney and stove Cleaning the stoves firebox Cleaning combustion air intake Cleaning of the firebox Checking / switch, gasket for door Checking / changing, gasket for glass...
  • Page 13: Cleaning/Replacing Bicks After Chimney Sweeping

    1.17 Cleaning after sweeping or before replacing vermiculite stones Note: it may be necessary to clean/vaccum the holes and air ducts behind the rear stone. Order of removing Fire bricks. Replace in reverse order. Starting with Fig. 5.
  • Page 14: Stove Data Table En 13240

    Testing is conducted with the combustion air around 61% open for Ambition 5 and 69% open for Ambition 8. 1.19 Guarantee Heta wood stoves, subjected to a strict quality - Damage caused by improper use. control during production and before delivery to - Transportation costs for warranty repair.
  • Page 15 ambition 5 Parts - inside fire chamber Pos. Name Qty. 1 0023-000103 Back stone top, left 2 0023-002740 Side stone, left 3 0023-002742 Baffle 4 0023-002741 Side stone, right 5 0023-000387 Back stone bottom, left 6 1013-004304 Stiffener 7 0023-004882 Back stone top, right 8 0023-004879 Back stone bottom, right ambition 8 Parts - inside fire chamber Pos.
  • Page 16: Installation Instructions

    installation instructions Contents Installation instructions ..............17 Distance requirements ..............17 Floor ....................17 Chimney connection ................. 17 Combustion air and ventilation ............18 Stovedrawings/measurments ............. 18-20 Connecting direct air - nehind ............20 Clearances for installation EN 13 240 ..........21 Changing to back outlet ..............
  • Page 17: Installation Instructions

    We recommend a minimum of 5 cm to facilitate must be sealed with fireproof material and / or air circulation around the stove. beading. Heta A/S stresses that it is of utmost The minimum distance to combustibles can be importance that this is done correctly with very found on the model plate provided with the sto- tight joints.
  • Page 18: Combustion Air And Ventilation

    For connections to chimneys that are run through • If the vent leads out into the open air, please ceilings, all national and local regulations regar- note that the grille must be fitted with suitable ding distance to flammable material must be fol- wind protection.
  • Page 19 ambition 5 Ø125 ambition 8 ø100 ø125 mm...
  • Page 20: Connecting Direct Air - Nehind

    ambition 8 Ø125 Ø125 2.6 Connecting direct air - behind When installing external air supply, connect the air intake to the direct air pipe using flexi-pipe, Flexi-pipe not included. Ø 100...
  • Page 21: Clearances For Installation En 13 240

    2.7 Clearances for installation en 13 240 ambition Combustible material Non-flammable substrate - Non-flammable substrate Furnitures By flammable floor material the The dimensions are the stove must be mounted on the log minimum dimensions, store base and a non-flammable unless otherwise stated. substrate.
  • Page 22: Changing To Back Outlet

    2.8 Changing to back outlet 1500-001146 4025-0007 DETAIL D SCALE 1 : 1.5...
  • Page 23: Data Plate

    3. Data plate Note your own number here _______________________ 8058 002597-EN 8058 000081-EN Heta A/S Heta A/S Jupitervej 22 . DK-7620 Lemvig . Denmark Jupitervej 22 . DK-7620 Lemvig . Denmark EN 13240:2001/A2:2004 - AEA - NS 3058/3059 EN 13240:2001/A2:2004 - AEA - NS 3058/3059...

This manual is also suitable for:
