Heta Scan-Line Green 300 Instructions Manual

Hide thumbs Also See for Scan-Line Green 300:
Table of Contents

Advertisement

Quick Links

EN
EN
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Scan-Line Green 300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heta Scan-Line Green 300

Summary of Contents for Heta Scan-Line Green 300

  • Page 2 HETAclimate Wi-Fi...

  • Page 3: Table Of Contents

    ENGLISH Contents sYsteM stRUCtURe �������������������������������������������������������������������������� 2 LoCAL AnD ReMote ConneCtIon ����������������������������������������������� 3 HetAclimate MeCHAnICAL sPeCIFICAtIons ������������������������������� 4 HetAclimate BUttons AnD LeDs �������������������������������������������������� 5 InstALLAtIon ��������������������������������������������������������������������������������������� 6 neW MoDULe – Wi-Fi ConFIGURAtIon ����������������������������������������� 7 ConneCt to A ConFIGUReD Wi-Fi MoDULe ������������������������������11 HoMe sCReen ������������������������������������������������������������������������������������13 DeVICe settInGs ������������������������������������������������������������������������������16 DeVICe ContRoL �������������������������������������������������������������������������������17...

  • Page 4: System Structure

    SYSTEM STRUCTURE the structure consists of 3 macro systems: 1. Wi-Fi MODULE: hardware unit that works with the motherboard and communicates via the Wi-Fi router� 2. SERVER IN THE CLOUD: Web server infrastructure that enables data storage and serves as a relay for remote communication� 3.

  • Page 5: Local And Remote Connection

    LOCAL AND REMOTE CONNECTION Local connection the connection between the Wi-Fi module and the app via the local Wi-Fi network (only if both are connected to the same Wi-Fi network)� delay 0 ms Remote connection the connection is remote when the app is no longer connected to the local network� In this case, the app uses your mobile phone’s data connection and communicates with the server.

  • Page 6: Hetaclimate Mechanical Specifications

    MECHANICAL SPECIFICATIONS RS232 CoM port RS485 Power supply Cabinet Cabinet in ABS Working temperature -20° ÷ 60° Attachment Self-tapping 5 mm screws 70 mm 64 mm The device is only guaranteed to function with the cables provided.

  • Page 7: Hetaclimate Buttons And Leds

    BUTTONS AND LEDS (d) HW reset button Power/Error COM connection Wi-Fi communication Configuration button...

  • Page 8: Installation

    INSTALLATION 1. Connect the Wi-Fi module to the power supply: LED (a) must be lit and not flashing. 2. Connect the Wi-Fi module to the pellet stove using the cable provided: LED (b) must be lit and not flashing. If it flashes, there may be communication problems with the pellet stove�...

  • Page 9: New Module - Wi-Fi Configuration

    When you start the app, you can choose the desired language� the steps for configuring the HETA module are explained below: 1� Create an account using a valid email address and password of your choice by filling in the fields.
  • Page 10 • HETAclimate: Press button (e). The blue (c) and red (d) LEDs start flashing alternately • HETA Lite: press button (b), and the blue LED (a) starts flashing 4� Write a name for the device and enter a PIn of you choice�...
  • Page 11 NEW MODULE – Wi-Fi CONFIGURATION 5� once the app and HetAclimate are connected, you will be asked to select the home Wi-Fi system that the HetAclimate device should connect to� 6� Make sure that the smartphone connects to your home Wi-Fi and that the LeDs change and continue in the configuration step.
  • Page 12 NEW MODULE – Wi-Fi CONFIGURATION If the configuration procedure fails, you can reconfigure HETAclimate by pressing and holding the button for 10 seconds. (Only if all three green LEDs don’t flash) And then press button (b) for 10 seconds� The screens and descriptions may vary depending on the device you are configuring. once installation of the HetAclimate device is complete, it is recommended that you close the app and restart it�...

  • Page 13: Connect To A Configured Wi-Fi Module

    CONNECT TO A CONFIGURED Wi-Fi MODULE You can also connect remotely (using your smartphone’s data connection) by entering the login details for a HETAclimate device you have configured. You can also connect remotely (using your smartphone’s data connection) by entering the login details for a HETAclimate device you have configured. Connected to the same Wi-Fi network�...
  • Page 14 • Tap the lower-right button for devices with virtual keys or the lower-left button for devices with fixed keys • Swipe left on the preview of the HETA app to close it The procedure can vary from smartphone to smartphone.

  • Page 15: Home Screen

    HOME SCREEN the home screen shows a list of modules connected to the app� the linked devices are shown on the home screen using their ID name� the status of each device is displayed as follows: operating state oFF operating state BLoCK operating status on not connected or unreachable device Updating required...
  • Page 16 HOME SCREEN tap on this icon to add another Wi-Fi module� this menu displays the device information associated with your app, including the ID and PIn� Account management: this menu allows you to create a new account or log in/out� Restore app: this menu allows you to reset the app to factory settings�...
  • Page 17 HOME SCREEN It allows you to connect to the management applications of the smart thermostats installed in you home system� to connect to the smart thermostats, enter the account credentials you recorded when setting it up�...

  • Page 18: Device Settings

    DEVICE SETTINGS Access to the settings menu on the selected device� Device name: used to change the name of the current device� Icon: change the device’s display icon on the home screen� Remote support enabled: you can activate the option to receive technical support�...

  • Page 19: Device Control

    DEVICE CONTROL Red = OFF: press to Operating status: turn on the pellet stove� displays the status of the pellet stove, which Green = ON: press to function is active and any turn off the pellet stove� error message�� Synchronisation: if the LED is flashing Desired room temperature: it means the app and...

  • Page 20: Timer And 24H Function

    TIMER AND 24H FUNCTION From the Timer menu you can select and change settings in two different modes� Press to change the selected mode and its function� tIMeR function 24H function TIMER When you enter the TIMER function you can set three different time periods� You can further choose from three types of programming: •...
  • Page 21 TIMER AND 24H FUNCTION the 24H function is a guided procedure for controlling home heating by setting times and temperatures to match your daily needs� the guide asks a few simple questions about your daily routine, and will then suggest a weekly schedule�...
  • Page 22 TIMER AND 24H FUNCTION 1. 24H programme control: the drop-down menu at the top of the page shows the programmes you have set� select the cloud to enable the programme� Press on symbol to change the thermostats or powers of each band� 2.
  • Page 23 TIMER AND 24H FUNCTION 3. Delete a time period: press the button to delete a time period, as shown below: Press the button to delete the desired time period� 4. Update changes: Press the button to synchronise 24H mode with the device� Press this button every time you make a change�...
  • Page 24 TIMER AND 24H FUNCTION 5. Copy a time period: press to copy the set time period from one day to one or more other days. Confirm the changes made by tapping confirm at the bottom of the screen� 6. Change a time period: tap on a time period to make changes to it�...

  • Page 25: Graphs

    GRAPHS this menu displays graphs of the values logged on the server by the Wi-Fi Module� two views are available: 1. Daily: the values shown represent the daily operation of the pellet stove� You can see the graphs for two time frames – 00:00 - 12:00 or 12:00 - 00:00� You can also choose to view the operating status of the pellet stove (off / normal / Blocked, etc�) the data is stored for one week�...

  • Page 26: Information Screen

    Denne side viser den information, der er registreret af bundkortet� this menu displays graphs of the values logged on the server by the Wi-Fi Module� two views are available: The button can be used to send a service request to HETA support via email.

  • Page 27: Menu

    MENU on the menu screen you can access: Power control: use this menu to change the power output of the pellet stove� Thermostat control: allows you to choose primary thermostat� List of recent errors: displays a list of the last recorded ‘errors’�...
  • Page 28 Heta A/S Jupitervej 22, DK-7620 Lemvig Phone: +45 9663 0600 E-mail: heta@heta.dk www.heta.dk 21.06.2021 0037-1700 Version 1,0...
