Onlogic HX511 Product Manual page 6

Thermal Standards (Subject to
change through RFI and RFQ
steps)
Extra Chassis Features
Regulatory Certifications
Radio Specifications when equipped with Intel AC 9260 Wi-Fi (device for indoor use)
Frequency Bands
Operating Frequency
Channel spacing /
Bandwidth
RF output power
Type of Modulation
Type of Antenna
System Operating Temperature: 0-50C
Storage Temperature: -10-85C
Operating Humidity: 0% - 90% (non-condensing)
6 Antenna holes
Wall Mount
DIN Rail Mount
VESA Mount
FCC 47 CFR Part 15 Subpart B (Class A)
EN 60950-1 & EN 63268-1
CISPR 32/EN 55032
CISPR 35/EN 55035
Radio Equipment Directive (2014/53/EU)
WEEE Directive (2012/19/EU)
RoHS 3 (2015/863/EU)
IEC 60601-1-2, 4th ed. - EMC Ready
EN 60945, 4th ed.
IEC/UL/EN 62368-1
2.4 GHz and 5 GHz bands
2400 - 2485 MHz
5150 - 5250 MHz, 5250 - 5350 MHz
5470 - 5725 MHz, 5725 - 5878 MHz
2.4GHz: 802.11b/g/n; 5 MHz / BT: 1MHz
Bandwidth: 20 MHz / 40 MHz
5 GHz: 802.11a/n/ac: 20, 40, 80, 160 MHz
20 dBm (2400-2485 MHz) IEEE 802.11b/g/n & BT
10 dBm (2400-2485 MHz) BLE
23 dBm (5150-5725 MHz) IEEE 802.11a/n/ac
13.98 dBm (5725-5875 MHz) IEEE 802.11a/n/ac
2.4 GHz: DSSS/OFDM/FHSS
5 GHz: OFDM
Reference antenna is PIFA type (2 dBi/2 dBi gain)
6
