Product Specifications - Onlogic HX511 Product Manual

1.3 - Product Specifications

Model
System Dimensions
System Weight
Board Dimensions
CPU (on solder side of board)
PCH
Memory
LAN Controller
Expansion
Back I/O
Front I/O
Onboard Headers & Connectors
Voltage Input
Power Input
BIOS
Operating Systems
Special Features
8.86" x 2" x 6.97"
225 x 50.8 x 177 mm
4.94 lbs
2.24 kgs
8.7" x 6.1"
221 x 156 mm
Socket LGA 1700 - Alder Lake PS
PS Integrated
2 x SO-DIMM DDR5 (2 x 32GB max Dual Channel) 64 GB Total
1x Intel i225-LM -with AMT
1x Intel I225-IT
1x M.2 2280/3042/3052 B-Key (PCIe x2, USB 3.2 5Gb/s, SATA III)
1x M.2 2230 E-key (Wi-Fi) (PCIe / USB 2.0)
1x M.2 2280 M-key (PCIe x 4, SATA III)
2x Full size DisplayPort 1.4 2x Gb LAN (2 x Intel)
2x USB 3.2 10 Gb/s
4-pin Terminal Block (12 ~ 24 V input)
Optional dual CAN card
Optional single COM (RS-232/422/485) card
1x Power button with LED indicator
1x 3FF-Sim slot (Mapped to the B-Key)
4x USB 3.2 10Gb/s
Optional 3 COM (RS-232/422/485) add-in card
Optional DIO add-in card
2x Thunderbolt 4 (40 Gb/s) USB Type C
1x Battery on a cable
1x internal power header (5V, 12V)
12~24V
4-pin Terminal Block (supports remote switch)
Insyde
Windows 10 IOT 2021 LTSC, Ubuntu 22.04 LTS, Yocto, Window 11
Watchdog timer
RTC
PTT in BIOS
On-board TPM 2.0
Support for Vision Processing Units
Support for 4G LTE and GPS expansion cards
HX511
