4 - Power Management

4.1 - Wake-Up Events

The Helix platform supports multiple power states. The wake-up events can be configured in the
BIOS. This section describes the supported power management functions and gives information on
protection circuitry for power adapters.
Wake-Up Event
Power Button
LAN
USB
RTC Wake set by BIOS
RTC Wake set by OS

4.2 - Protection Circuitry

Parameter
Nominal operating voltage (Rated DC value of input)
Undervoltage protection trip DC level (system turns off)
Maximum safe DC voltage (system not damaged)
These DC levels specified are the absolute max values for the pins for function and safety of the
system. The protection circuitry allows for brief transient voltages above these levels without the
system turning off or being damaged. A transient voltage suppressor on the power input allows
momentary excursions above stated limits. For input power consumption and current see
Appendix A.
From ACPI State
Deep S5, S5, S3
S5, S3
S3
Deep S5, S5, S3
S3
Comments
Must be enabled in BIOS
Must be enabled in BIOS
Value
12~24V
6.5V
28.4V
