5.3 - Appendix B: BIOS manual and Drivers

For a detailed overview of the BIOS screens and individual settings, as well as instructions for
updating the BIOS, please refer to the OnLogic support site at the link below.
https://support.onlogic.com/documentation/helix-511-technical-resources/

5.4 - Appendix C: System Thermal Results

5.4.1 Test Conditions

● Temperature Range: 0ºC to 50°C
● Step size: 10°C
● i7 Processor loaded @80% PTAT, 1TB SSD, and 64GB DDR5 RAM loaded @ 80% with
BurnInTest 9.2

5.4.2 Test Methodology

Thermal testing of the Helix 511 was completed using a thermal chamber to control ambient
environmental temperature across the rated temperature range of the system. Throughout testing, the
system and its components were being stressed by various softwares to simulate a rigorous constant
workload. Stress testing occurred for two hours in each temperature range. Components were
monitored during testing via their internal sensors. Some components were monitored externally via
thermocouples.
