Industrial Electronic Devices
User Manual
Revision 1.200
English
PROFIBUS Slave / Modbus Master – Converter
(Order Code: HD67561-A1)
for Website information:
www.adfweb.com?Product=HD67561
for Price information:
www.adfweb.com?Price=HD67561
Benefits and Main Features:
Very easy to configure
Wide supply input range
Electrical isolation
Industrial temperature range:
-40°C / 85°C (-40°F / 185°F)
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual PROFIBUS Slave / Modbus Master
Document code: MN67561_ENG
HD67561
For others products see also the following links:
CANopen to Modbus
www.adfweb.com?Product=HD67001
www.adfweb.com?Product=HD67502
www.adfweb.com?Product=HD67004
www.adfweb.com?Product=HD67505
For CAN bus 2.0A and/or CAN bus 2.0B to Modbus
www.adfweb.com?Product=HD67011
www.adfweb.com?Product=HD67012
www.adfweb.com?Product=HD67014
www.adfweb.com?Product=HD67515
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
Revision 1.200
Page 1 of 33
(Modbus RTU Master)
(Modbus RTU Slave)
(Modbus TCP Master)
(Modbus TCP Slave)
(Modbus RTU Slave)
(Modbus RTU Master)
(Modbus TCP Slave)
(Modbus TCP Master)
Advertisement
Table of Contents
Related Manuals for ADF Web HD67561
Summary of Contents for ADF Web HD67561
- Page 1 Revision 1.200 Page 1 of 33 Industrial Electronic Devices User Manual Revision 1.200 English PROFIBUS Slave / Modbus Master – Converter (Order Code: HD67561-A1) for Website information: www.adfweb.com?Product=HD67561 HD67561 for Price information: www.adfweb.com?Price=HD67561 Benefits and Main Features: Very easy to configure...
-
Page 2: Updated Documentation
User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 2 of 33 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX Updated UPDATED DOCUMENTATION... -
Page 3: Security Alert
User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 3 of 33 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation. -
Page 4: Example Of Connection
User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 4 of 33 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso... -
Page 5: Connection Scheme
User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 5 of 33 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67561 ADFweb.com Srl – IT31010 – Mareno – Treviso... - Page 6 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 6 of 33 Industrial Electronic Devices CHARACTERISTICS: The Configurable PROFIBUS Slave to Serial Communication Master Gateway allows the following characteristics: Baud Rate and Parity changeable with software; Mountable on 35mm Rail DIN;...
-
Page 7: Power Supply
POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax HD67561 Consumption at 24V DC: Device W/VA HD67561 Caution: Not reverse the polarity power HD67561... -
Page 8: Function Modes
User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 8 of 33 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the Dip2 of ‘Dip-Switch A’: The first, with Dip2 in Off position (factory setting), is used for the normal working of the device. The second, with Dip2 in On position, is used for upload the Project/Firmware. - Page 9 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 9 of 33 Industrial Electronic Devices LEDS: The device has got three LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode 1: Not used (yellow)
- Page 10 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 10 of 33 Industrial Electronic Devices PROFIBUS: The PROFIBUS uses a 9-pin D-SUB connector. The pin assignment is defined like in the right figure. Here some codes of cables: Belden: p/n 183079A - Continuous Armor DataBus®...
- Page 11 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 11 of 33 Industrial Electronic Devices RS232: The connection from RS232 socket to a serial port (example one from a personal computer), must be made with a Null Modem cable (a serial cable where the pins 2 and 3 are crossed).
- Page 12 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 12 of 33 Industrial Electronic Devices USE OF COMPOSITOR SW67607: To configure the Converter, use the available software that runs with Windows called SW67561. It is downloadable on the site www.adfweb.com and its operation is described in this document.
-
Page 13: New Configuration / Open Configuration
User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 13 of 33 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “PROFINET / CANopen - Converter”... -
Page 14: Software Options
User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 14 of 33 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 15 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 15 of 33 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable some special functions that allows you a simpler interaction with the Compositor Software. ADFweb.com Srl –...
-
Page 16: Set Communication
User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 16 of 33 Industrial Electronic Devices SET COMMUNICATION: This section defines the fundamental communication parameter of two Buses, Serial and PROFIBUS. By Pressing the “Set Communication” button from the main window of SW67561 (Fig. 2) the window “Set Communication”... - Page 17 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 17 of 33 Industrial Electronic Devices If the field “Enable Modbus ony if PROFIBUS is Active” is checked, the converter do the Modbus requests only if PROFIBUS connection is established;...
- Page 18 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 18 of 33 Industrial Electronic Devices If selected “Hardware Type” “Hardware With Ethernet” (available soon): The means of the fields for “Modbus Master” are: In the field “Serial” is possible to select the serial line used for Modbus. The options are RS232 or RS485;...
- Page 19 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 19 of 33 Industrial Electronic Devices In the field “Start Address Byte IN” the starting address where the gateway send to the PROFIBUS master the state of Modbus request (for more info see the chapter “Async Remote Request”).
- Page 20 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 20 of 33 Industrial Electronic Devices MODBUS SET ACCESS (for Hardware without Ethernet): By pressing the “Modbus Set Access” button from the main window for SW67561 (Fig. 2) the window “Set Modbus Access” appears. This window is divided in two parts, the "PROFIBUS In -->...
- Page 21 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 21 of 33 Industrial Electronic Devices Serial Write --> PROFIBUS OUT The means of the fields are: In the field “Slave ID” the address of the Modbus device that you must write is defined; In the field “Type”...
- Page 22 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 22 of 33 Industrial Electronic Devices MODBUS SET ACCESS (for Hardware with Ethernet): By pressing the “Modbus Set Access” button from the main window for SW67561 (Fig. 2) the window “Set Modbus Access” appears. This window is divided in two parts, the "PROFIBUS In -->...
- Page 23 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 23 of 33 Industrial Electronic Devices Serial Write --> PROFIBUS OUT The means of the fields are: In the field “Slave ID” the address of the Modbus device that you must write is defined; In the field “Type”...
- Page 24 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 24 of 33 Industrial Electronic Devices ERROR/DIAGNOSIS By pressing the “Error/Diagnosis” button from the main window for SW67561 (Fig. 2) the window “Error/Diagnosis” appears. In this window is possible to insert all the Modbus devices checked by the converter. The table give the position of the bit that are set if the device is in error in the Diagnosis array in PROFIBUS.
- Page 25 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 25 of 33 Industrial Electronic Devices ASYNC MODBUS REQUEST: With the Async Modbus Request is possible to send an Asynchronous Modbus Request form the PROFIBUS to the Modbus network. To use this feature there are 8 bytes in write where the master PROFIBUS can send the parameters of the request and 4 bytes in read where the result of the Modbus communication is saved.
- Page 26 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 26 of 33 Industrial Electronic Devices The permits values for the “Status_Request” are: • 0 Performing Request • 1 Answer OK • 2 Answer with Exception •...
- Page 27 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 27 of 33 Industrial Electronic Devices UPDATE VIA SERIAL (only for hardware without Ethernet port): By pressing the “Update Device” button it is possible to load the created Configuration into the device, and also the Firmware if is necessary, using the RS232 port.
- Page 28 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 28 of 33 Industrial Electronic Devices UPDATE VIA UDP: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary.
- Page 29 Page 29 of 33 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67561 device. Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67561 device.
-
Page 30: Mechanical Dimensions
User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 30 of 33 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 12: Mechanical dimensions scheme ADFweb.com Srl – IT31010 – Mareno – Treviso... -
Page 31: Ordering Informations
Document code: MN67561_ENG Revision 1.200 Page 31 of 33 Industrial Electronic Devices ORDERING INFORMATIONS: Order Code: HD67561 PROFIBUS Slave / Modbus Master - Converter ACCESSORIES: Order Code: AC34107 Null Modem Cable Fem/Fem DSub 9 Pin 1,5 m Order Code: AC34114... -
Page 32: Other Regulations And Standards
User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 32 of 33 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 33: Warranties And Technical Support
User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.200 Page 33 of 33 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
