13.
USEFUL TIPS
The lid is not only a dust cover but also a resonant structure likely to be excited by and to pass into the plinth the
acoustic energy emanating from your loudspeakers during replay. Therefore, it is recommended to remove the
lid for achieving a better sound quality. The record player should be positioned on a low-resonance surface,
like wood or multiple layer ply board to avoid structural vibrations disturbing replay.
14.
MAINTENANCE AND CLEANING
Your record player requires little or no regular maintenance. Remove dust with a slightly moistened antistatic
cloth. Never use a dry cloth because this will create static electricity which attracts even more dust! Antistatic
cleaning fluids are available at specialized stores but must be applied sparingly to avoid damage to rubber
parts. It is recommended to fit the needle cover before cleaning or maintenance to avoid damage.
If the player is not used over a long period of time, the drive belt should be removed to prevent unequal stretching.
Always disconnect the record player from the mains power supply as a precaution before maintenance!
TECHNICAL SPECIFICATIONS
X1
Pro-Ject 8.6'' Carbon/Alu sandwich tonearm
Nominal speeds
Speed variance
Wow and flutter
Signal to noise
Effective tonearm mass
Effective tonearm length
Overhang
Power consumption
Outboard power supply
Dimensions (W x H x D)
Weight
Technical specifications MM-Cartridge Pro-Ject Pick IT S2 MM
Frequency range
Channel separation
Output voltage
Recommended load impedance
Compliance/stylus type
Recommended tracking force
Weight
33/45/78 r.p.m.
33: ±0.30 % 45: ±0.25 %
33: ±0.15 % 45: ±0.13 %
-68dB
10g
8.6 " (218.5mm)
18mm
5W/ 0.3W standby mode
15V/ 0.8 A DC, universal power supply
415 x 130 x 335mm, dust cover open 462 x 380 x 400mm
7 kg
20-20.000Hz
23dB/1kHz
7mV
47kohms/amplifier connection – MM-input
20µm/mN – elliptical
18mN
7,2g
© Pro-Ject Audio Systems · Pro-Ject X1 · Revision 2019.07.09
